YUME
Operating Instructions
Image is as of EX-YM*L/SU-YM
Thank you for purchasing this Takara Belmont product.
The instructions contained in this booklet should be thoroughly read and
understood before use.
Using this product before reading this operating instructions may result in an
accident.
This product is an industrial shampoo unit designed for barbers and hair salons.
Only use this product for its intended purpose and do not use it for
non-hairdressing work.
Keep this instruction and refer back to them when required.
For installation and assembly of this product, contact your local Takara Belmont
dealer.
BEGB09D0
Version9
2023.07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YUME and is the answer not in the manual?

Questions and answers

Related Manuals for Takara Belmont YUME

Summary of Contents for Takara Belmont YUME

  • Page 1 Only use this product for its intended purpose and do not use it for non-hairdressing work. Keep this instruction and refer back to them when required. For installation and assembly of this product, contact your local Takara Belmont dealer. BEGB09D0 Version9 2023.07...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. Locations of Warning Labels ........1 2. Dimension and Specifications ......... 2 3. Overall View and Major Components ...... 3 4. Accessories ............5 5. Preparation ............5 6. Operating Instruction ..........7 7. Maintenance ............11 8.

  • Page 3: Locations Of Warning Labels

    1. Locations of Warning Labels Be careful not to pinch a hand and etc. ＣＡＵＴＩＯＮ Drain Outlet Drain Cap The drain cap must be detached from the drain outlet when the product is not in use. Be careful not to pinch a hand and etc.

  • Page 4: Dimension And Specifications

    Water Volume (Shower Head) -------------- Dual function Shower outlet : 10.0 L/min (water and hot water pressure are 0.1 Mpa) shower head Low splash foaming mode : 6.4 L/min YUME shower head Shower outlet : 10.0 L/min Weight ----------------------------------- 156 kg...

  • Page 5: Overall View And Major Components

    3. Overall View and Major Components Main Body ■ Shower head holder Backrest Shampoo basin Seat Maintenance cover Main switch Foot control A sticker of drain hose replacement Neck cushion (Consumable) Head pillow (Consumable) Thermostatic control knob Shower head Body cover Drain cap Mohair tape (inside cover)

  • Page 6: Name Of Parts

    Seat lowering Seat lowering switch switch ■ Shower Head 【OPTION】 Dual Function Shower Head Dual Function Shower Head YUME shower head YUME shower head Protrusion Shower head Selection Shower head switch Shower head plate Shower head plate Low-splash mode water outlet ■...

  • Page 7: Accessories

    Head Pillow ...1set Sponge ...1 Drain Cap ...1 Hair Catcher ...1 Operating Instructions ...1 Installation Instructions ...1 YUME SPA Technical Manual (except for China) ...1 5. Preparation 5-1. Attach the Neck Cushion Neck Cushion Snap Button 1. Attach the neck cushion on metal fittings as shown in figure.
  • Page 8 5. Preparation 5-3. Removing the cover Turn the cover anticlockwise. Cover Turn the cover around 5 degrees. Pinch the front and back of the cover to deform and remove the catch. 【Image】 Catch Do not remove the cover of holder forcibly. Caution Failure to follow the instruction may cause damage the product.

  • Page 9: Operating Instruction

    6. Operating Instruction 6-1 Main Switch Turn on the main switch of EX-YM*L located on the left side of the pump cover and that of EX-YM*R located on the right side of the pump cover. < Main switch > Mark) ( Mark) Caution Turn off...
  • Page 10 (2) Auto Mode Control E. Preset Control Momentarily depress Preset button on the foot control, Preset Auto Return the chair will move to the preset position automatically. (Preset position is set best position of seating shampoo. If adjustment is needed, please refer AUTO MODE POSITION ADJUSTMENT.
  • Page 11 Shower head Water Outlet Low-splash mode water outlet 【OPTION】 YUME shower head YUME shower head Shower head Shower head plate Water ou tl et - Do not discharge a strong water stream when the shower head is in the shower head holder.
  • Page 12 6-6 Adjustment the Water / Hot Water A. Turn the tap to anticlockwise. B. Adjust the water temperature with thermostatic control knob. Open (H) Hot Thermostatic Control Knob C. Press stop button on the thermostatic Stop control knob to release lock for hot water, (C) Cold Stop then turn clockwise.

  • Page 13: Maintenance

    7. Maintenance Notice Do not use the following substances. Thinner, alcohol, gasoline, kerosene or other volatile chemicals; waxes containing abrasives; sponges containing abrasives, etc. Thinner Alcohol Chemicals Gasoline Waxes 7-1. Hair catcher Drain cap Take out the hair catcher under the drain cap and remove Hair catcher hair from the hair catcher.
  • Page 14 7-6. Sponge Cover Sponge is consumable supply. Replace the sponge if degradation causes rubbing sound when the hose is moving. (Available at additional cost) Sponge Remove the cover from the holder. [Page 6] - Remove the sponge from the hose and wash with water. Sponge holder - After washing the sponge with water, squeeze it like press- ing with both hands.
  • Page 15 7-8. Strainer for check valve Clean strainer (built-in check valve) at regular intervals. Remove the water in strainer if freezing is expected in the cold district. A. Raise the chair and turn off the main switch. Maintenance Cover B. Remove 2 screws and open the maintenance cover C.

  • Page 16: Troubleshooting

    Slow drainage Check to make sure that the hair removed from the hair catcher completely. In case other than those listed above, contact your local Takara Belmont dealer. CAUTION If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or similarly qualified person in order to avoid hazard.

  • Page 17: Parts Replaced On A Regular Basis

    9. Parts Replaced on a Regular Basis The following are parts that must be replaced on a regular basis as designated by our company: □Drain hose: Replace every three years ・For the drain hose, there is a possibility that water leaks will occur because cracks are caused due to  deterioration and hardening of the hose from chemical agents in the drain water.

  • Page 18: Consumable Supplies

    10. Consumable Supplies The following parts are "consumable supplies" and wear, degradation, changes in external appearance and damage are expected. Please note that repair or replacement of these parts is not covered by warranty, and a fee will be required. (* The level and period of wear, degradation or damage may differ depending on the environment and conditions that the customer uses this product in.) Inspections or replacement of parts will be required if there is extensive wear, degradation or...
  • Page 19 Memo -17-...
  • Page 20 TAKARA BELMONT CORPORATION 1-1, 2-Chome, Higashi-shinsaibashi,Chuo-ku,Osaka,Japan TEL : +81-6-6213-5945 FAX : +81-6-6212-3680 Printed in Japan -18-...
