4.3.1 Clear All Button Description

The CLR All Button shown
all the bits in the corresponding register to 0s. This
button is placed to the left of each register that has
write access.

Figure 14. Clear All Button

4.3.2 Write All Button Description

The Write All button shown in
every bit of every register on the current register
screen. This button is located in the bottom right
corner of each register screen.

Figure 15. Write All Button

4.3.3 Read All Button Description

The Read All button shown in
ery bit of every register on the current register
screen. This button is located in the bottom left cor-
ner of each register screen.
DS450DB1
Figure 14 is used to set
Figure 15 writes
Figure 16 reads ev-

Figure 16. Read All Button

4.4 Write Button Description

The Write button shown in
bits of the corresponding register. This button is lo-
cated to the right of every register that allows write
access.

Figure 17. Write Button

4.5 Read Button Description

The Read button shown in
of the corresponding register. This button is located
to the right of every register.

Figure 18. Read Button

4.6 Program Exit Function

To exit any of the register screens simple press the
X in the top right hand corner of each screen. This
CDB61880
Figure 17 writes the
Figure 18 reads the bits
