9
Logs Menu
The Logs Menu provides information on events, trips and starter performance.
Press the ALARM LOGS button to open the Logs Menu.
To navigate through the Logs Menu:
• to open a log, press the ENTER button.
• to scroll through the entries in each log, press the
• to view details of a log entry, press the ENTER button.
• to return to the previous level, press the EXIT button.
• to close the Logs Menu, press ALARM LOGS.
9.1
Trip Log
The Trip Log stores details of the eight most recent trips, including the date and time the trip happened.
Trip 1 is the most recent and trip 8 is the oldest stored trip.
To open the Trip Log:
1.
Open the Logs Menu.
2.
Scroll to Trip Log and press ENTER.
3.
Use the
and
To close the log and return to the main display, press ALARM LOGS.
9.2
Event Log
The Event Log stores time-stamped details of the starter's 99 most recent events (actions, warnings
and trips), including the date and time of the event. Event 1 is the most recent and event 99 is the
oldest stored event.
To open the Event Log:
1.
Open the Logs Menu.
2.
Scroll to Event Log and press ENTER.
3.
Use the
and
To close the log and return to the main display, press ALARM LOGS.
9.3
Performance Counters
The performance counters store statistics on the starter's operation:
• Hours run (lifetime and since counter last reset)
• Number of starts (lifetime and since counter last reset)
• Motor kWh (lifetime and since counter last reset)
• Number of times the thermal model has been reset
To view the counters:
1.
Open the Logs Menu.
2.
Scroll to counters and press ENTER.
3.
Use the
and
4.
To reset a counter, press ENTER then use the
Press ENTER to confirm the action.
To close the counter and return to the Logs Menu, press ENTER.
NOTE
The reset counters function is protected by the access code.
58
ASTAT XL User Manual
buttons to select a trip to view, and press ENTER to display details.
buttons to select an event to view, and press ENTER to display details.
buttons to scroll through the counters. Press ENTER to view details.
DET-812
Fout! Stijl niet gedefinieerd.
and
buttons.
and
buttons to select Reset/Do Not Reset.
