4.2.3 Minimum and Maximum Current Settings
The ASTAT XL's minimum and maximum full load current settings depend on the model:
Model
QLxxB0023D
QLxxB0043D
QLxxB0050D
QLxxB0053D
QLxxB0076D
QLxxB0097D
QLxxB0100D
QLxxB0105D
QLxxB0145D
QLxxB0170D
QLxxB0200D
QLxxB0220D
QLxxB0255D
QLxxX0255D
QLxxB0350D
QLxxX0360D
QLxxX0380D
QLxxB0425D
QLxxX0430D
QLxxB0500D
QLxxB0580D
QLxxX0620D
QLxxX0650D
QLxxB0700D
QLxxX0790D
QLxxB0820D
QLxxB0920D
QLxxX0930D
QLxxB1000D
QLxxX1200D
QLxxX1410D
QLxxX1600D
ASTAT XL User Manual
In-line connection
Minimum Maximum
5 A 23 A
9 A 43 A
10 A 50 A
11 A 53 A
15 A 76 A
19 A 97 A
20 A 100 A
21 A 105 A
29 A 145 A
34 A 170 A
40 A 200 A
44 A 220 A
51 A 255 A
51 A 255 A
70 A 350 A
72 A 360 A
76 A 380 A
85 A 425 A
86 A 430 A
100 A 500 A
116 A 580 A
124 A 620 A
130 A 650 A
140 A 700 A
158 A 790 A
164 A 820 A
184 A 920 A
186 A 930 A
200 A 1000 A
240 A 1200 A
282 A 1410 A
320 A 1600 A
DET-812
Fout! Stijl niet gedefinieerd.
Inside delta connection
Minimum Maximum
5 A 34 A
9 A 64 A
10 A 75 A
11 A 79 A
15 A 114 A
19 A 145 A
20 A 150 A
21 A 157 A
29 A 217 A
34 A 255 A
40 A 300 A
44 A 330 A
51 A 382 A
51 A 382 A
70 A 525 A
72 A 540 A
76 A 570 A
85 A 638 A
86 A 645 A
100 A 750 A
116 A 870 A
124 A 930 A
130 A 975 A
140 A 1050 A
158 A 1185 A
164 A 1230 A
184 A 1380 A
186 A 1395 A
200 A 1500 A
240 A 1800 A
282 A 2115 A
320 A 2400 A
