Description:
15G – Brake Torque
Range:
Description:
15H – Brake Time
Range:
Description:
<
NOTE
Parameter 15H is used in conjunction with parameter 2I. See Brake for details.
15I – Brake Torque-2
Range:
Description:
15J – Brake Time-2
Range:
Description:
8.4.12 16 Protection Action
CAUTION
Defeating the protection may compromise the starter and motor, and should only be done in
the case of emergency.
16A~16M – Protection Action
Options:
Description:
8.5

Adjustment Lock

You can lock the Programming Menu to prevent users from altering parameter settings. The
adjustment lock can be turned on and off using parameter 15B.
To lock the programming menu:
1. Open the Programming Menu.
2. Open the Extended Menu.
3. Select 'Restricted'.
4. Enter the Access Code.
5. Select parameter 15B Adjustment Lock
6. Select and store 'Read Only'.
54
ASTAT XL User Manual
Sets the current limit for jog operation.
20% - 100%
Sets the amount of brake torque the ASTAT XL will use to slow the motor.
1 - 30 (seconds)
Sets the duration for DC injection during a braking stop.
20% - 100%
Sets the amount of brake torque the ASTAT XL will use to slow the motor.
1 - 30 (seconds)
Sets the duration for DC injection during a braking stop.
Trip Starter (default)
Warn and Log
Log Only
Selects the soft starter's response to each protection.
16A Motor Overload
•
16B Current Imbalance
•
16C Undercurrent
•
16D Instantaneous Overcurrent
•
16E Input A Trip
•
• 16F Frequency
16G Motor Thermistor
•
16H Excess Start Time
•
• 16I Starter Communication
16J Heatsink Overtemperature
•
16K Battery/Clock
•
16L Network Communication
•
16M Low Control Volts
•
DET-812
Fout! Stijl niet gedefinieerd.
Default: 20%
Default: 1 second
Default: 20%
Default: 1 second
