GE ASTAT XL User Manual page 24

6.1.5 Inside delta installation, internally bypassed
K1
CAUTION
When connecting the ASTAT XL in inside delta configuration, always install a main contactor or
shunt trip circuit breaker.
6.1.6 Inside delta installation, externally bypassed
Non-bypassed models have dedicated bypass terminals, which allow the ASTAT XL to continue
providing protection and monitoring functions even when bypassed via an external bypass contactor.
The bypass contactor must be connected to the bypass terminals and controlled by a programmable
output configured to Run (see parameters 7A~7I).
K1
1/L1
L1B
3/L2
L2B
5/L3
L3B
NOTE
The bypass terminals on QLxxX0255D are T1B, T2B, T3B. The bypass terminals on
QLxxX0360D ~ QLxxX1600D are L1B, L2B, L3B.
The fuses can be installed on the input side if required.
CAUTION
When connecting the ASTAT XL in inside delta configuration, always install a main contactor or
shunt trip circuit breaker.
24
ASTAT XL User Manual
F1
1/L1 2/T1
3/L2 4/T2
5/L3 6/T3
E
K2
F1
2/T1
*
4/T2
*
6/T3
*
E
13
14
K1
21
24
K2
K1
F1
U1(1) U2(4)
M
V1(2) V2(5)
3
W1(3) W2(6)
13
14
K1
K1
K2
F1
U1(1) U2(4)
M
V1(2)
V2(5)
3
W1(3) W2(6)
DET-812
Fout! Stijl niet gedefinieerd.
Main contactor (strongly
recommended)
Semiconductor fuses
(optional)
Main contactor (strongly
recommended)
Bypass contactor
(external)
Semiconductor fuses
(optional)
