NOTE
Screens shown here are with the default settings.
7.3.1 Starter Status
The starter status screen shows details of the starter's operating status, motor temperature and motor
power.
Ready
M1 000%
7.3.2 Programmable screen
The ASTAT XL's user-programmable screen can be configured to show the most important information
for the particular application. Use parameters 10B to 10E to select which information to display.
Ready
0000 hrs
7.3.3 Motor Temperature
The temperature screen shows which motor data set is in use, and the temperature of both motors as
a percentage of total thermal capacity. If the ASTAT XL is configured for use on one motor, the
temperature for the secondary motor (M2) will always show 0%.
Primary Motor Set
M1 000%
7.3.4 Current
The current screen shows real-time line current on each phase.
Phase Currents
000.0A 000.0A
7.3.5 Motor Power
The motor power screen shows motor power (kW, HP and kVA) and power factor.
000.0kW
0000kVA
7.3.6 Last Start Information
The last start information screen shows details of the most recent successful start:
• start duration (seconds)
• maximum start current drawn (as a percentage of motor full load current)
• calculated rise in motor temperature
Last start
350 % FLC Δ Temp 5%
7.3.7 Date and Time
The date/time screen shows the current system date and time (24 hour format).
setting the date and time, see Set Date and Time on page 56.
7.3.8 SCR Conduction Bargraph
The SCR conduction bargraph shows the level of conduction on each phase.
L1 Cond
L2 Cond
L3 Cond
7.3.9 Graphs
The ASTAT XL can display real-time performance information for:
• current
• motor temperature
• motor kW
• motor kVA
• motor power factor
The newest information is displayed at the right hand edge of the screen. Older data is not stored.
28
ASTAT XL User Manual
000.0kW
M2 000%
000.0A
0000HP
-. - - pf
010 s
DET-812
Fout! Stijl niet gedefinieerd.
For details on
