  • Page 3 The Federal Communications Commission warns that changes or modifications of the unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. CE mark for Class B ITE (Following European standard EN55022/1998; EN61000-3-2/1995;...

  • Page 4: Table Of Contents

    Table of Contents Your New LCD Monitor Unpacking Identifying Components Hot Keys for Quick Adjustment of Monitor Settings Adjusting the Viewing Angle Connecting AC Power Connecting Video Connecting the Stereo Speakers Power Management System The LCD Monitor’s Display Controls Adjusting the Monitor’s Display...

  • Page 5: The Lcd Monitor

    LCD Monitor’s small footprint allows you more room in your workspace for other peripherals. Lightweight and compact, the LCD Monitor is the perfect solution for users on the go. You can use the LCD Monitor for everything from making business presentations to playing computer games.

  • Page 6: Identifying Components

    The Internet also has information on this and other subjects. After unpacking your LCD Monitor; make sure the following items are included in the box and are in good condition: LCD Monitor...

  • Page 7: The Lcd Monitor - Front View

    The LCD Monitor — Front View Figure 1-1: The LCD Monitor Panel and Controls LCD Screen The LCD Monitor Screen is a 19” TFT 1280 x 1024 SXGA screen. Function Control Buttons /OSD Menu Button The 1 button allows you to display the OSD (On-Screen Display) Menu and to select the function group.

  • Page 8: Hot Keys For Quick Adjustment Of Monitor Settings

    The Monitor Stand supports the LCD Panel. Loop the VGA signal cable through the hole on the Monitor Stand. Stereo Speakers You can connect your PC’s Audio out port to the LCD Monitor’s Audio in port and listen to your PC’s audio output with these speakers.
  • Page 9 Connect the AC adapter cable to this jack. Audio Line-in Connect your PC’s line-out to this jack to listen the PC’s audio on the LCD monitor’s stereo speakers. (You can also connect your CD-ROM’s line-out to this jack.) VGA Cable Connector This 15-pin D-Sub VGA connector is used to connect to your PC’s...

  • Page 10: Adjusting The Viewing Angle

    Adjustsing the Viewing Angle Your LCD Monitor is designed to allow you to adjust it to a comfortable viewing angle. The LCD Monitor’s vertical angle setting range is from -5 to 20 . Please see Figure 1-3 . When positioning the equipment, make sure that the main ports and sockets are easily accessible.

  • Page 11: Connecting Ac Power

    Figure 1-5: The AC Adapter 2. Connect the power connector of the adapter into the jack of the LCD Monitor. The DC power jack is located at the rear of the Monitor near the USB Hub connector. Please refer to Figure 1-5 .

  • Page 12: Connecting Video

    Figure 1-7: Connecting the LCD Monitor to the PC 4. Make sure the signal cable heads are securely connected to the VGA port (or DVI port) of your PC and Monitor. Tighten the connecting screws to ensure a secure connection.

  • Page 13: Connecting The Stereo Speakers

    Monitor’s stereo speakers. 1. Connect the sound cable to the Line Out of your PC’s audio card. 2. Connect the other end of the sound cable to the LCD Monitor’s line-in jack. Please refer to Figure 1-7 . Figure 1-8: Connecting the Stereo Speakers 3.

  • Page 14: The Lcd Monitor's Display Controls

    You can also adjust the stereo speaker volume and set OSD parameters. Please read this chapter carefully to get the most out of your LCD Monitor. Adjusting the Monitor’s Display The LCD Monitor features an intuitive, menu-driven, On-Screen Display (OSD).

  • Page 15: Osd Main Menu

    OSD Main Menu To access the OSD main menu, press the OSD Menu button (the first Function button on your LCD Monitor). To scroll between the OSD main menu options, use the second Function button on your LCD Monitor. The highlighted option is the one that is currently selected.
  • Page 16 Position, Phase and Clock parameters. PORT-SELECT: Use this option to change input between the VGA port and DVI digital port. EXIT: Use this option to exit the Monitor Control submenu. The OSD Control option lets you adjust the position of the OSD on the screen.
  • Page 17 LCD monitor’s display screen. The Brightness level should be adjusted in conjunction with the Contrast item. COLOR: Use this option to select the LCD monitor’s color display. The available options are 9300, 6500 and User. The 9300 and 6500 options let you set the Color Temperature to CIE coordinates 9300°...

  • Page 18: Digital Mode

    The OSD Exit option lets you close the OSD Program. Take note that the OSD will close by itself if left inactive. The Monitor Control option allows you to adjust the LCD monitor’s display characteristics. PORT-SELECT: Use this option to change input between VGA port and DVI digital port.
  • Page 19 LCD monitor’s display screen. BRIGHTNESS: Use this option to adjust the light level on the LCD monitor’s display screen. It should be adjusted in conjunction with the Contrast item. RESET: Use this option to reset Contrast, Bright- ness and Color parameters.
  • Page 20 OSD Exit Option Use the OSD Exit item to close the OSD program. Note: 1.NO VIDEO When the monitor is ON and no Video signal is being received, the “NO VIDEO” message will be displayed. 2.Signal out of monitor’s supported range When the frequency range is out of the monitor’s specifications, or the incoming resolu...

  • Page 21: Lcd Monitor Specifications

    LCD Monitor Specifications LCD Panel Control Functions Power On-Screen Main Menu Display (OSD) Display Area (mm) Display Colors Video Interface Analog port: VGA Compatible Analog RGB (15-pin D-Sub) Digital port: DDWG compliant Single Link Tmds Digital Appendix A 19” SXGA...
  • Page 22 Input Detection Scanning Frequency H/V, Hz (Analog mode) Scanning Frequency H/V, Hz (Digital mode) Power Management Power Consumption (ON/OFF, W) Dimensions WxHxD mm Net Weight (Kg) (Approx.) Power Supply Environment Audio (Two 1 Watt speakers with amplifier) Regulatory AUTO-detection and OSD item for manual selection Meets VESA DPMS ON :46W max.

  • Page 23: Supported Timing

    Supported Timing Item Standards Resolution 640x400 PC98 640x400 PC98 MAC 13” 640x480 mode MAC 16” 832x624 mode MAC 17” 1024x768 mode 640x350 640x400 640x480 VESA 640x480 VESA 640x480 VESA 800x600 SVGA 800x600 VESA 800x600 VESA 800x600 720x400 1024x768 VESA 1024x768 VESA 1024x768 1024x768...

  • Page 24: Troubleshooting Procedures

    Troubleshooting Procedures This LCD Monitor was pre-adjusted in the factory with standard VGA timing. Due to output timing differences among various VGA cards, you may initially experience an unstable or unclear display when a new display mode or new VGA card is selected.
  • Page 25 PROBLEM: There is no LCD Display If there is no display on the LCD, please perform the following steps: 1. Make sure that the power indicator on the LCD Monitor is lit, all connections are secure, and the system is running on the correct timing.
