Page 2: Operating Instructions
FCC RADIO FREQUENCY INTERFERENCE STATEMENT WARNING: (FOR FCC CERTIFIED MODELS) This monitor has been tested and found compliant with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide proper protection against harmful interference to a residential installation. -
Page 3: Table Of Contents
Safety Precautions... Care and Maintenance... First Step... Quick Installation... Screen Position Adjustment... Front Panel Control... Using OSD Functions... Technical Information... Power Management System... Troubleshooting... Contents... -
Page 4: Safety Precautions
This monitor should be operated only at the correct power sources indicated on the label at the rear end of the monitor. If you are unsure of the power supply in your residence, consult your local dealer or power company. -
Page 5: Care And Maintenance
Avoid exposing your monitor directly to sunlight or other heat sources. Place your monitor away from the sun to reduce glare. Put your monitor in a well-ventilated area. Do not place anything heavy on top of your monitor. Make certain that your monitor is installed in a clean and moisture-free area. -
Page 6: First Step
VGA, SVGA, XGA,SXGA (non-interlaced), and most Macintosh-compatible color video cards. •The monitor is able to properly function even in case of upgraded video cards or software because of the wide auto-scanning compatibility range. •The internal microprocessor digitally controls auto-scanning for horizontal scan frequencies between 31.5 KHz and 91.1 KHz, and for vertical scan frequencies... - Page 7 This monitor package comes with: LCD Monitor Video cable AC Power cord AC to DC Adapter Audio cable User’s manual Floppy Disk (for test pattern and set up)
-
Page 8: Quick Installation
Connect the video cable to the computer first, then to the monitor. 4. Connect the power cord. Connect the power cord to the monitor through the AC/DC adapter, then to a properly grounded AC outlet. 5. Connect the Audio cable. -
Page 9: Screen Position Adjustment
In order to optimize the best viewing position, you can adjust the tilt of the monitor by using both of your hands to hold the edges of the monitor as shown in the figure below. The monitor can be adjusted to 30 degrees up or 5 degrees down as indicated by the... -
Page 10: Front Panel Control
Front Panel Control 1. Power Switch: To turn power ON or OFF. 2. Power LED: Lights up to indicate that power is turned ON. 3. To increase the value of the parameter in the OSD you have selected for adjustment. MUTE: Audio Mute hot key without OSD 4. -
Page 11: Using Osd Functions
Using OSD Functions BRIGHTNESS CONTRAST ANALOG CONTRAST AUTO CONTRAST 1280 x 1024 FV: 84.8Hz AUTO ADJUST LEFT/RIGHY UP/DOWN H.SIZE FINE 1280 x 1024 FV: 84.8Hz STATURATION FLESH TONE 1280 x 1024 FV: 84.8Hz VOLUME TREBLE BASS BALANCE 1280 x 1024 FV: 84.8Hz NO SIGNAL INPUT COLOR TEMPERATURE... - Page 12 Standard OSD Operation 1. Press any front panel key to activate the OSD menu. 2. Use the Select Up or Down keys to move up or down through the menu. The para - meter will be highlighted when selected. 3. Use + or - to increase or decrease the value of the parameter, or to select among different options.
- Page 13 Press + to turn on this function. The Auto-Adjust will autom- atically adjust the V-Position, H-Position, Clock, and Clock- Phase, with the whole process taking about 5 seconds. (Please install the attached LCD monitor utility disk for Auto- Adjust) Recal Returns the monitor to its default settings.
-
Page 14: Technical Information
Technical Information Specifications: LCD Display Display Type Display Area (H x W) Contrast Ratio Viewing Angle Operational Features Display Colors Resolution Brightness Response Time Interface Input Connector Multimedia Two Internal Speakers Users Controls Front Panel Controls OSD Controls Physical Specification Dimension (H x W x D) Net Weight Power... - Page 15 When none of the mode is matched, the users can store their preferred modes in the user modes. The monitor is capable of storing up to 9 use modes. The only condition to store as a user mode is the new display information must have 1 KHz difference for horizontal frequency or 1 Hz for vertical frequency or the sync signal polarities are different from the default modes.
-
Page 16: Power Management System
Note: The monitor automatically goes to the Power Management System (PMS) when it is idle. To release the monitor from the PMS condition, press any key on the keyboard or move the mouse. -
Page 17: Troubleshooting
Troubleshooting Before sending your LCD monitor for servicing, please check the troubleshooting list below to see if you can self-diagnose the problem. Problems Current Status LED ON Picture LED OFF LED displays amber color Abnormal Unstable Picture Picture Display is missing,...
