- Page 2 Copyright © 2005 Microtek International,Inc. Microtek® is a registered trademark of Microtek International, Inc. All other trademarks or registered trademarks are the property of their respective holders. Specifications, software and hardware bundles are subject to change without notice. Delivery of technical support services subject to change without notice. Not responsible for typographical errors.
- Page 3 CE mark for Class B ITE (Following European standard EN55022/ 1998; EN61000-3-2/1995; EN61000-3-3/1995, EN55024/1998, EN60950/1992+A1+A2+A3+A4+A11) Radio Frequency Interference Statement Warning: This is a Class B product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. Canadian Doc Notice For Class B Computing Devices This digital apparatus does not exceed the Class B limits for radio noise emissions...
-
Page 4: Table Of Contents
Connecting the Monitor ... 6 Adjusting the Viewing Angle ... 7 Operating the Monitor ... 8 A. The LCD Monitor’s Control Panel ... 8 B. Adjusting the Monitor’s Display ... 9 The Menu Table ... 10 TFT LCD Monitor Specifications ... 1 1 Supported Timing ... -
Page 5: Introduction
Introduction Congratulations on the purchase of your new Microtek LCD monitor! With a 19" TFT active matrix color crystal display and offering a maximum resolution of 1280 x 1024 pixels, your LCD monitor offers sharp and vibrant color display with low radiation emission. -
Page 6: Unpacking
Before unpacking your LCD monitor, prepare a stable, level, and clean surface near a wall outlet for your LCD monitor. 1. Set the LCD monitor box in an upright position and open from the top of the box before removing the right/left cushions. -
Page 7: Cleaning
• Do not scratch or rub the screen with a hard object. • Never use any of the following solvents on the LCD monitor: Thinner; spray-type cleaners; benzene; wax; abrasive cleaners; and acid or alkaline solvents. Such harsh chemicals may cause damage to the cabinet and the LCD screen. -
Page 8: Installation
Installation Installing the Base Pedestal STEP 1 STEP 2... -
Page 9: Vesa Mount Setup
(STEP 2) Note: • To meet safety requirements, the monitor must be mounted to an arm that guarantees the monitor's stability. • The LCD monitor should only be used with an approved arm. STEP 1 STEP 2... -
Page 10: Connecting The Monitor
• Usage of incorrect voltage will cause malfunction and may cause fire or electric shock. • Do not pull or bend the power cable or place the monitor or any heavy objects on the cables. If the cables are damaged, they may cause fire or electric shock. -
Page 11: Adjusting The Viewing Angle
Adjusting the Viewing Angle For optimal viewing, the viewing angle of the monitor can be adjusted 35 degrees up and 5 degrees down. Down: 3° Up: 35° Figure-2: Tilting the LCD Monitor... -
Page 12: Operating The Monitor
OSD setting. Power switch: Turns power for the LCD monitor ON or OFF . 6. Power LED: Indicates various status levels for the monitor, such as Green (Normal operation) or Orange (Power management), depending on the monitor’s operating mode. -
Page 13: Adjusting The Monitor's Display
B. Adjusting the Monitor’s Display 1. Pressing the OSD Menu button causes the screen below (Figure 4) to appear. 2. Press the + or — button to select a menu item. 3. Press the OSD Menu button again to enter the selected submenu. -
Page 14: The Menu Table
Resets all of the DISPLAY ADJUST settings to their default values. Returns to the previous menu. Adjusts the colors in the LCD monitor to a warmer or cooler shade, depending on the selected color temperature. Changes the OSD language, including English, Spanish, German, Italian, French, and Chinese. -
Page 15: Tft Lcd Monitor Specifications 1
TFT LCD Monitor Specifications LCD Type Display Area Input Signal Dot Pitch Scanning Frequency Resolution Display Color Contrast Ratio Brightness Contrast Ratio Response Time Viewing Angle Plug and Play Audio Dimensions (H x W x D) Gross/Net Weight Tilt Swivel... -
Page 16: Supported Timing
Supported Timing... -
Page 17: Troubleshooting
PROBLEM: There is no LCD display If there is no display on the LCD, refer to the following: 1. Make sure that the power indicator on the LCD monitor is lit, that all connections are secure, and that the system is running on the correct timing.
