Summary of Contents for Microtek C788
-
Page 2: Operation Instructions
FCC RADIO FREQUENCY INTERFERENCE STATEMENT WARNING: (FOR FCC CERTIFIED MODELS) This monitor has been tested and found compliant with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide proper protection against harmful interference to a residential installation. -
Page 3: Table Of Contents
Safety Precautions Care and Maintenance First Step Front Panel Control Using OSD Functions Supporting Timing modes Technical Information Contents... -
Page 4: Safety Precautions
This monitor should be operated only at the correct power sources indicated on the label at the rear end of the monitor. If you are unsure of the power supply in your residence, consult your local dealer or power company. -
Page 5: Care And Maintenance
Avoid exposing your monitor directly to sunlight or other heat sources. Place your monitor away from the sun to reduce glare. Put your monitor in a well ventilated area. Do not place anything heavy on top of your monitor. Make certain that your monitor is installed in a clean and moisture-free area. -
Page 6: First Step
First Step Congratulation for purchasing this high-performance monitor! Please check all accessories listed in the packing list. Quick Installation 1. Connect video cable Make sure both the monitor and com- puter are powered OFF. Connect the video cable to the computer, then to the monitor. -
Page 7: Front Panel Control
Front Panel Control ACTIVATE EXIT OSD SCROLL DOWN SCROLL UP INCREASE AC INPUT VGA INPUT AUDIO INPUT EARPHONE SELECT DESIRED FUNCTION DECREASE LED INDICATER POWER ON... -
Page 8: Using Osd Functions
Using OSD Functions 1. Press the button to display the main menu shown below. 2. Press the or▼button to scroll to the desired menu option. 3. Press the button to select the menu option. 4. Press the or▼ button to select submenu option. 5. - Page 9 NOTE: Auto tune works with most common video cards. If using this function does not work on your monitor, lower the video refresh rate to 60 Hz and try again (See computer or graphic card user guide to adjust refresh rate.) The panel may be manually tuned using the horizontal and vertical phase controls shown below.
- Page 10 Color Temp Color Temperature Select User Color 1 Exit Color Temperature : provides four preset color adjustments:9300K, 6500K, 5400K, 5000K for improved brightness and color saturation. Press button preset color. 9300K--Adds blue to screen image for cooler white. 6500K--Adds to screen image for warmer white and richer red. 5400K--Adds green to screen image for a darker color.
- Page 11 Setup Menu Language Select OSD Position OSD Temeout 1 Exit Language Select : allows the user to choose from available languages. OSD Position : Press the Horizontal OSD Position horizontally repositions all OSD screens. moves OSD right, ▼moves OSD left. Vertical OSD Position vertically repositions all OSD screen.
-
Page 12: Supporting Timing Modes
VESA VESA Warning : Do not set the graphic card in your computer to exceed these maximum refresh rates. Doing so may result in permanent damage to your monitor. 640 x 480 @ 60HZ 640 x 480 @ 72HZ 640 x 480 @75HZ... -
Page 13: Technical Information
Technical Information LCD Type Color filter Glass surf. Input Signal Analog Compatibility Power Audio LCD Display Color Viewing Angle Dimensions Contrast Ratio Brightness Response Time Active Display Area Operating Conditions Compliance Power Saving LED modes *All specifications are subject to change without notice. 17.0”...
