OSD Main Menu

To access the OSD main menu, press the OSD Menu button (the first
Function button on your LCD Monitor). To scroll between the OSD
main menu options, use the second Function button on your LCD
Monitor. The highlighted option is the one that is currently selected.
Analog or digital mode is automatically detected by the Monitor.
A. Analog Mode
Each main menu and submenu item is covered below.
Pressing the OSD Menu button causes the following screen to
appear (an example):
The Monitor Control Option
Figure 2-1: The OSD Main Menu
The Monitor Control option allows you to adjust the
display characteristics of the LCD Monitor.
AUTO-ADJUST : Use this option to apply automatic
monitor settings.
H-POSITION: Use this option to move the LCD
monitor's display left or right on a horizontal plane.
V- POSITION: Use this option to move the LCD
monitor's display up or down on a vertical plane.
