- Page 1 18" HIGH RESOLUTION WITH SUPER- WIDE VIEWING ANGLE USER'S MANUAL www.microtek.com...
-
Page 2: Table Of Contents
Canadian DOC Notice Chapter 1 Introduction Precautions Product Features Unpacking Specifications Supported Timing Cleaning Chapter 2 Installing the Monitoe Connecting the Monitor Adjusting the Viewing Angle Chapter 3 Operating the Monitor How to Use the OSD Structure of OSD Menus Operating Procedure... - Page 3 Menu Table Troubleshooting Procedures For Your Safety...
-
Page 4: Fcc Warning
FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. this device may not cause harmful interference, and 2. this device must accept any interference received, including interference that may cause undesired operation. FCC WARNING This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 5: Ce Mark For Class B Ite
• Consult the dealer or an experienced radio/TV technician for help. Caution: To comply with the limits for an FCC Class B computing device, always use the shielded signal cord supplied with this unit. The Federal Communications Commission warns that changes or modifications of the unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. -
Page 6: Energy Star
Canadian Doc Notice For Class B Computing Devices This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the Radio Interference Regulation of the Canadian Department of Communications. “Le présent appareil numérique n’èmet pas de bruits radioélectriques dépassant les limites applicables aux appareils numériques de la class B prescrites dans le Règlement sur le brouillage radioélectrique édicté... -
Page 7: Introduction
Follow all warning and instructions on the product. Do not cover or block the vent holes in the case. Do not insert sharp objects or spill liquid into the LCD monitor through the cabinet slots; this may cause accidental fire, electric shock or failure. -
Page 8: Unpacking
Before unpacking your LCD Monitor, prepare a stable, level, and clean surface near a wall outlet for your LCD Monitor. Set the LCD Monitor box in an upright position and open from the top of the box before removing the right/left cushions. -
Page 9: Specifications
Specifications LCD type Display Area Input signal Dot pitch Scanning frequency Resolution Display color Luminance Contrast ratio Response time Viewing angle Control type Plug & Play Dimension (H x W x D) Weight Tilt Wall mount AC input Power management Power Consumption Regulatory compliance 18”... -
Page 10: Supported Timing
Supported Timing Display Mode SVGA VESA SXGA Macintosh MS-DOS Horizontal Frequency 31.5 KHz 640 x 480 37.5 KHz 720 x 400 31.5 KHz 35.2 KHz 37.9 KHz 800 x 600 46.9 KHz 48.1 KHz 48.4 KHz 56.5 KHz 1024 x 768 60.0 KHz 63.98 KHz 1280 x 1024... -
Page 11: Cleaning
Cleaning ARNING If you dropped any material or liquid such as water onto the monitor when cleaning, unplug the power cable immediately and contact your dealer or the nearest service center. Always make sure your hands are dry when unplugging the power cable. -
Page 12: Installing The Monitor
DO NOT place your LCD Monitor near a window as it may be severely damaged if exposed to rain, water, moisture, or sunlight. -
Page 13: Connecting The Monitor
1. Turn off your PC and the LCD Monitor before connecting your LCD monitor to the PC. 2. Use VGA cable to connect the VGA connector of the LCD Monitor to the VGA port of the PC system. Make sure the cable head is securely connected. -
Page 14: Adjusting The Viewing Angle
LCD Monitor. Sudden peaks of electricity may cause damage to the Monitor. Adjusting the Viewing Angle Your LCD Monitor is designed to allow you to adjust it to an optimal viewing angle. NOTE Do not touch the screen while changing the viewing angle. It may damage the screen. -
Page 15: Operating The Monitor
Pop up OSD Menu or Enter into sub menu Indicating the cursor movement or OSD manual selection in incremental values Exit OSD Menu and user setting saving Power ON/OFF the monitor/ Green – Normal operation Amber – Power Management... -
Page 16: How To Use The Osd
Structure of OSD Menus Operating Procedure Use the buttons on the right side control panel to adjust the OSD 1. Power on the LCD monitor. 2. Press “MENU” button to pop up the OSD menu. 3. Press “ ” or “... -
Page 17: Menu Table
Menu Table Main Function Name Situation/Option Menu Menu All Reset Auto Adjust Reset Color Reset OSD Brightness RGB Adjust Temperature Recall the all factory default settings. Automatically adjust image Clock, Phase, H-Position, V-Position settings Recall the color default settings Recall the OSD default settings Select Analog signal input (Dual model use Analog only) - Page 18 Clock Adjust To correct flickering text or lines. Phase Adjust To correct flickering text or lines. H-Position Adjust screen horizontal position. V-Position Adjust screen vertical position. Set the length of time an OSD screen is OSD Time Out displayed Allow you to move the OSD Menu on the OSD Position screen Accept And Exit User setting is saved and exit...
-
Page 19: Troubleshooting Procedures
Troubleshooting Procedures If the LCD monitor fails to function correctly, please follow the following steps for a possible solution. Perform the adjustments according to Operating the Monitor. Refer to the following items if you cannot find a proper item listed in the Operating the Monitor or if the problem remains. - Page 20 Display is too dark or If the video output level of the computer is within the spec. too bright. Display is not in the center. If the signal timing of the computer is within the spec. If the power voltage is within the spec. Display is shaking.
-
Page 21: For Your Safety
PROTECT and CORRECTLY USE THE CABLE Do not pull or bend the power cable and signal cable or place the monitor or any heavy objects on the cables. If the cables are damaged, they may cause fire or electric shock. - Page 22 THERS ERGONOMICS RECOMMENDATIONS Do not operate the monitor in a dark room or against a bright background. For optimal viewing comfort, the monitor should be just below eye level and 30-60 cm (16-24 inches) away from your eyes. When using the monitor over a...
-
Page 23: Special Notes On Lcd Monitors
The following are normal with LCD monitors and do not indicate a problem. When first turning on the LCD monitor, if the picture does not fit in the display area, it is because of the type of computer that is used. In such case, adjust the picture position to its correct position.(See Operating the Monitor)
