Summary of Contents for Microtek C588
-
Page 2: Operation Instructions
FCC RADIO FREQUENCY INTERFERENCE STATEMENT WARNING: (FOR FCC CERTIFIED MODELS) This monitor has been tested and found compliant with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide proper protection against harmful interference to a residential installation. -
Page 3: Table Of Contents
Safety Precautions Care and Maintenance First Step Front Panel Control Installation Using OSD Functions Timing Modes Technical Information Contents... -
Page 4: Safety Precautions
This monitor should be operated only at the correct power sources indicated on the label at the rear end of the monitor. If you are unsure of the power supply in your residence, consult your local dealer or power company. -
Page 5: Care And Maintenance
Avoid exposing your monitor directly to sunlight or other heat sources. Place your monitor away from the sun to reduce glare. Put your monitor in a well ventilated area. Do not place anything heavy on top of your monitor. Make certain that your monitor is installed in a clean and moisture-free area. -
Page 6: First Step
First Step Thank you for purchasing this high performance monitor ! This monitor package comes with: Video cable with 15 pin D-SUB connector. Power cable. User’s manual Quick Installation 1. Connect video cable Make sure both the monitor and com- puter are powered OFF. -
Page 7: Front Panel Control
Front Panel Control OSD ON/OFF SCROLL DOWN SCROLL UP Installation POWER INPUT (AC INPUT) SINGAL INPUT (VGA 15PIN D-SUB) ENTER POWER INDICATOR POWER ON/OFF... -
Page 8: Using Osd Functions
Using the OSD Functions MAIN MENU (example) EXIT SELECT Auto Adjust: For auto adjusting the horizontal position, vertical position, Clock and phase. H. Position: For adjusting the horizontal position of the picture. V. Position: For adjusting the vertical position of the picture. Brightness: For adjusting the brightness or the back-light current . -
Page 9: Timing Modes
Hot Key functions: When no OSD appears, press: button to turn the OSD on/off, ‘ ’ button to have the monitor auto-adjust and save all settings, ‘ ’ button to adjust the contrast, ‘ ’ button to adjust the brightness, ‘ ’... -
Page 10: Technical Information
Technical Information Technical Specifications LCD Panel Power Management Displayable Resolution Pixel Dimension LCD Display Color Active Display Area Viewing Angle Tilt Contrast Ratio Brightness Response Time Active Display Area Temperature Compliance Power 15.0 TFT Energy Star compliant VESA DPMS compatible <5W XGA 1024x768max.
