Summary of Contents for Microtek 722S
- Page 2 FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.
- Page 3 B prescrites dans le Règlement sur le brouillage radioélectrique édicté par le ministère des Communications du Canada. ” Energy Star Notice As an ENERGY STAR Partner, Microtek International, Inc. has determined that this monitor meets the ENERGY STAR guidelines for energy efficiency.
-
Page 4: Table Of Contents
Product Features ... 1 Unpacking ... 2 Precautions ... 2 Cleaning ... 3 Installation Installing the Monitor ... 4 Connecting the Monitor ... 5 Connecting the Audio cable ... 6 Adjusting the Viewing Angle ... 7 Operating the Monitor How to Use the OSD ... 8 Operating Procedure ... - Page 5 Appendixes A: Specifications ... 19 B: Supported Timing ... 20 C: Troubleshooting ... 21 D: Power Management ... 23 E: DDC (Plug and Play) ... 23 F: For Your Safety ... 24...
-
Page 6: Introduction
Introduction Congratulations on the purchase of your new Microtek LCD monitor! Providing a maximum resolution of 1280 x 1024 pixels with a flicker-free display at up to 75Hz refresh rate, your LCD monitor offers sharp and vibrant color display without the radiation emission and hazards associated with CRT monitors. -
Page 7: Unpacking
Before unpacking your LCD monitor, prepare a stable, level, and clean surface near a wall outlet for your LCD monitor. 1. Set the LCD monitor box in an upright position and open from the top of the box before removing the right/left cushions. -
Page 8: Cleaning
• Do not scratch or rub the screen with a hard object. • Never use any of the following solvents on the LCD monitor: Thinner; spray-type cleaners; benzene; wax; abrasive cleaners; and acid or alkaline solvents. Such harsh chemicals may cause damage to the cabinet and the LCD screen. -
Page 9: Installation
• DO NOT place your LCD monitor near a window as it may be severely damaged if exposed to rain, water, moisture, or sunlight. -
Page 10: Connecting The Monitor
RGB input port, and connect the other end of the cable to the computer’s analog RGB output port. Make sure the cables are securely connected. VGA cable 4. Plug the Power cord into the back of the monitor, and plug the other end into a power source (power surge protector highly recommended). -
Page 11: Connecting The Audio Cable
5. Turn on the LCD monitor. The power LED lights up orange. 6. Turn on your computer. The power LED changes from orange to green when the monitor detects the input signal source from the computer. At the same time, the image to be displayed appears on the screen. -
Page 12: Adjusting The Viewing Angle
NOTE: Do not touch the screen while changing the viewing angle, as this may damage the screen. In addition, make sure your fingers do not get caught in any of the monitor's parts while adjusting the viewing angle. Tilt Angle... -
Page 13: Operating The Monitor
Operating the Monitor The LCD monitor has been preset at the factory with the Timing shown in the section “Appendix B” to achieve optimal display. You can adjust the display to the desired brightness and sharpness by following the instructions. -
Page 14: How To Use The Osd
OSD function menus by pressing the MENU button. Operation Procedure The buttons on the bottom of the monitor are used to navigate the OSD. Follow the sequence below to do the following: toggle through the OSD function menu, select the function item, adjust the setting, save or cancel the setting, and finally exit the OSD menu. -
Page 15: Adjusting Monitor Display
Auto Adjustment allows you to adjust the monitor display automatically. 1. Power ON the LCD monitor and computer. 2. Make sure that your LCD monitor is not in “Adjustment Locked” status by pressing “MENU“ and “Power“ simultaneously. 3. Press the “MENU” button to display the OSD function menu. -
Page 16: Manual Adjustment
NOTE: • It is recommended that automatic adjustment be performed when you set up the monitor the first time or after having changed an aspect of the current system. • In most cases, automatic adjustment is sufficient. •... -
Page 17: Adjustment Lock
Adjustment Lock This function is used to prevent the inadvertent changing of monitor settings. All the control buttons (except “Power”) will be locked when this feature is used. 1. Power OFF the LCD monitor. 2. Press the “MENU” and “Power“ buttons simultaneously until the message “ADJUSTMENT LOCKED”... -
Page 18: Osd Function Menus
OSD Function Menus SCREEN Menu Press the “MENU” button once to display the SCREEN menu. Four available options can be adjusted: CLOCK, PHASE, H-POS, and V-POS. Function Description CLOCK Adjusts the number of pixels from the source video PHASE Adjust the phase relative to the video H-sync signal H-POS Moves the screen horizontally (left/right) V-POS... -
Page 19: Screen Menu
COLOR Menu Press the “MENU” button three times to display the COLOR menu. Press “ ” or “ ” to select 9300, 6500, 5000, or USER. When USER is selected, three options are available for further adjustments: R-CONTRAST, G-CONTRAST, and B-CONTRAST. Function Description R-CONTRAST... -
Page 20: Other Related Settings
Other Adjustments Adjusting the Backlight This function allows you to adjust the brightness of the backlight. 1. Press either the “ ” or “ ” to display the VOLUME/ BACKLIGHT screen when the OSD menu is not displayed on the screen. VOL UME BAC K LI GHT SELECT ¡¿/MODE... -
Page 21: Setting Gamma
Setting GAMMA This function allows you to adjust the color tone or brightness with one command. 1. Press the “ / MODE” button to display the GAMMA function menu when the OSD menu is not displayed on the screen. The GAMMA function menu — GAMMA1 appears the first time. -
Page 22: Installing The Arm
Installing the Arm A VESA-compliant arm allows you to mount your monitor on the wall. The accepted arm specifications for the monitor are: • Compatibility with the VESA standard • Required gap of 100mm x 100mm between the screw holes... - Page 23 5. Loosen the six stand-fixing screws, then remove the stand from the monitor. 6. Install the arm to the monitor with four arm-fixing screws. NOTE: • The stand preattached to the monitor is specially designed for use with this monitor. Once the stand is removed from the monitor, do not try to attach the stand to other devices.
-
Page 24: Appendixes A: Specifications
Appendix A: Specifications LCD type Display area Input signal Dot pitch Scanning frequency Resolution Display color Luminance Contrast ratio Response time Viewing angle Control type Plug and Play Speaker Dimensions (H x W x D) Gross/Net weight Tilt Swivel Height adjustment Wall mount AC input Power management... -
Page 25: B: Supported Timing
If you connect the monitor to the Apple Power Macintosh series, a conversion adapter (not supplied) is required. • If a timing signal not supported by the monitor is received, the message [OUT OF TIMING] will appear. Follow your computer’s instruction manual to set the timing so that it is compatible with the monitor. -
Page 26: C: Troubleshooting
Appendix C: Troubleshooting If the LCD monitor fails to function correctly, please follow the following steps for a possible solution. 1. Perform the adjustments according to the section, “Operating the Monitor. ” 2. Refer to the rest of this section if you cannot find a proper item listed in “Operating the Monitor”... - Page 27 • Make sure the signal timing of the computer is within the specifications of the monitor. • Check to see if the monitor is on power management mode, and touch the keyboard or the mouse. Problem 2: The displayed image is distorted Solution: •...
-
Page 28: D: Power Management
PC. You can use this function if your PC is DDC compliant and if it is set so that it can detect the Plug & Play monitor. There are many types of DDC, depending on the system. This... -
Page 29: F: For Your Safety
PROTECT AND USE THE CABLE CORRECTLY Do not pull or bend the power cable and VGA cable or place the monitor or any heavy objects on the cables. If the cables are damaged, they may cause fire or electric shock. - Page 30 THERS ERGONOMIC RECOMMENDATIONS Do not operate the monitor in a dark room or against a bright background. For optimal viewing comfort, the monitor should be just below eye level and 16-24 inches (40-60 cm) away from your eyes. When using the monitor over a prolonged period of...
-
Page 31: Special Notes On Lcd Monitors
The following conditions are normal with LCD monitors and do not indicate a problem. • When turning on the LCD monitor for the first time, the picture may not fit in the display area. This is because of the type of computer being used. In this case, adjust the picture position to its correct position.
