CSETF10xx-205
YES (On)
•
The media converter has selected 10 Mb/s operation for the fiber
link. If this is not the correct speed, disconnect and reconnect the
fiber cable to restart the initialization process.
•
Go to step 6.
NO
•
Contact Tech Support: 1-800-260-1312, Int'l: 00-1-952-941-7600.
6.
Is the TX-ACT LED illuminated?
NO
•
Check the 10/100Base-TX (copper) cables for proper connection.
•
Contact Tech Support: 1-800-260-1312, Int'l: 00-1-952-941-7600.
YES
•
Go to step 7.
7.
Is the TX-ACT LED flashing?
NO
•
If there is no activity on the copper port, go to step 8.
•
If there is activity on the copper port, disconnect and reconnect the
copper cable to restart the initialization process.
•
Restart the workstation to restart the initialization process.
•
Contact Tech Support: 1-800-260-1312, Int'l: 00-1-952-941-7600.
YES
•
Go to step 8.
8.
Is the TX-100 LED illuminated?
YES (Flashing)
•
The media converter is selecting between 10 Mb/s and 100 Mb/s
speed for the copper link or one or both of the links is down. If
persistent, disconnect and reconnect either cable to restart the
initialization process.
•
Go to step 9.
YES (On)
•
The media converter has selected 100 Mb/s operation for the copper
link. If this is not the correct speed, disconnect and reconnect the
copper cable to restart the initialization process.
•
Go to step 9.
NO
•
Go to step 9.
9.
Is the TX-10 LED illuminated?
YES (Flashing)
•
The media converter is selecting between 10 Mb/s and 100 Mb/s
speed for the copper link or one or both of the links is down. If
persistent, disconnect and reconnect either cable to restart the
initialization process.
YES
•
The media converter has selected 10 Mb/s operation for the fiber
link. If this is not the correct speed, disconnect and reconnect the
copper cable to restart the initialization process.
•
Contact Tech Support: 1-800-260-1312, Int'l: 00-1-952-941-7600.
NO
•
Contact Tech Support: 1-800-260-1312, Int'l: 00-1-952-941-7600.
10
24-Hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Contact Us
Technical Support
Technical support is available 24 hours a day.
US and Canada:
1-800-260-1312
International:
00-1-952-941-7600
Transition Now
Chat live via the Web with Transition Networks Technical Support.
Log onto www.transition.com and click the Transition Now link.
Web-Based Seminars
Transition Networks provides seminars via live web-based training.
Log onto www.transition.com and click the Learning Center link.
E-Mail
Ask a question anytime by sending an e-mail to our technical support staff.
techsupport@transition.com
Address
Transition Networks
6475 City West Parkway
Minneapolis, MN 55344, U.S.A.
telephone:
952-941-7600
toll free:
800-526-9267
fax:
952-941-2322
Declaration of Conformity
Name of Mfg:
Transition Networks
6475 City West Parkway, Minneapolis MN 55344 U.S.A.
Model:
CSETF10xx-205 Series Media Converters
Part Number(s):
CSETF1011-205, CSETF1013-205
Regulation:
EMC Directive 89/336/EEC
Purpose: To declare that the CSETF10xx-205 t o which this declaration refers is in
conformity with the following standards.
EN55022:1994 + A1:1995 + A2:1997; EN 55024:1998
I, the undersigned, hereby declare that the equipment specified above conforms to the above
Directive(s) and Standard(s).
Stephen Anderson, Vice-President of Engineering
techsupport@transition.com -- Click the "Transition Now" link for a live Web chat.
July, 2007____
Date
