CBFTF10xx-15x

Cable Specifications

The physical characteristics must meet or exceed IEEE 802.3™ specifications.
Fiber Cable
Bit Error Rate:
Single mode fiber (recommended):
Multimode fiber (recommended):
Multimode fiber (optional):
CBFTF1011-155, CBFTF1013-155
Fiber Optic Transmitter Power:
Fiber Optic Receiver Sensitivity:
Link Budget:
CBFTF1014-155
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
CBFTF1015-155
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
CBFTF1018-155
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
CBFTF1029-155, CBFTF1029-156
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
CBFTF1029-157, CBFTF1029-158
Fiber-optic Transmitter Power:
Fiber-optic Receiver Sensitivity:
Link Budget:
Copper Cable
Maximum Cable Distance: 100 meters
Category 3: (Minimum requirement for 10 Mb/s operation)
Gauge
Attenuation
Category 5: (Minimum requirement for 100 Mb/s operation)
Gauge
Attenuation
• Straight-through (MDI) or crossover (MDI-X) twisted-pair cable must be used.
• Shielded twisted-pair (STP) or unshielded twisted-pair (UTP) may be used.
• Pins 1&2 and 3&6 are the two active pairs in an Ethernet network .
• Use only dedicated wire pairs for the active pins:
(e.g., blue/white & white/blue, orange/white & white/orange, etc.)
• Do not use flat or silver satin wire.
Straight-Through Cable
1
1
Twisted Pair #1
2
2
3 3
Twisted Pair #2
6
6
8
24-hour Technical Support: 1-200-260-1312 -- International: 00-1-952-941-7600
<10-9
9 μm
62.5/125 μm
100/140, 85/140, 50/125 μm
multimode
min: -19.0 dBm max: -14.0 dBm
min: -30.0 dBm max: -14.0 dBm
11.0 dB
single mode
min: -15.0 dBm max: -8.0 dBm
min: -31.0 dBm max: -8.0 dBm
16.0 dB
single mode
min: -8.0 dBm max: -2.0 dBm
min: -34.0 dBm max: -7.0 dBm
26.0 dB
multimode
min: -19.0 dBm max: -14.0 dBm
min: -33.5 dBm max: -14.0 dBm
14.5 dB
single mode
min: -13.0 dBm max: -6.0 dBm
min: -32.0 dBm max: -3.0 dBm
19.0 dB
single mode
min: -8.0 dBm max: -3.0 dBm
min: -33.0 dBm max: -3.0 dBm
25.0 dB
24 to 22 AWG
11.5 dB/100m @ 5-10 MHz
24 to 22 AWG
22.0 dB /100m @ 100 MHz
Crossover Cable
1 1
Twisted Pair #1
2
2
3 3
Twisted Pair #2
6
6

Technical Specifications

For use with Transition Networks Model CBFTF10xx-15x or equivalent.
IEEE 802.3™
Standards
10 Mb/s, 100 Mb/s
Data Rate:
Dimensions 3.4" x 4.7" x 0.87" (86 mm x 119 mm x 22 mm)
4 oz. (114 g) (approximate)
Weight
Power Consumption: 4.0 W
MTBF 629,000 hours (MIL217F2 V5.0) (MIL-HDBK-217F)
1,630,000 hours (Bellcore7 V5.0)
Unicast MAC address: 128K bytes (1 Mbit)
Packet Size:
Maximum packet size: 1522 bytes
Memory: 1K bytes
Environment Tmra*:
Storage Temp:
Humidity
Altitude
Warranty Lifetime
*Manufacturer's rated ambient temperature: Tmra range for this slide-in-module
depends on the physical characteristics and the installation configuration of the
Transition Networks PointSystem™ chassis in which this slide-in-module will be
installed.
The information in this user's guide is subject to change. For the most up-to-date
information on the CBFTF10xx-15x media converter, view the user's guide on-line at:
www.transition.com.
Product is certified by the manufacturer to comply with DHHS Rule 21/CFR,
Subchapter J applicable at the date of manufacture.
CAUTION: Visible and invisible laser radiation when open. Do not stare into beam
or view directly with optical instruments.
CAUTION: Use of controls, adjustments or the performance of procedures other than
those specified herein may result in hazardous radiation exposure.
The fiber optic transmitters on this device meet Class I Laser safety requirements per
IEC-825/CDRH standards and comply with 21 CFR1040.10 and 21CFR1040.11.
