|----▼ 4-20mA (Verifies 4mA or 20mA output and selects condition of output during calibration)
|
|
|
▼ -------or--------------- E Calib
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
▼ -------or--------------- E CalibOut (Adjust 4-20mA output during Calibration)
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
▼ -------or--------------- E Tbl Out (Adjust 4-20mA output during Trouble condition)
|
|
|
|
|
|
|
|
|
|
|----▼ RS-485 (Select RS-485 address and baud rate)
|
|
|
| - Address
|
|
|
▼ | -------or--------------- E Addr:016 (Use (▲ or ▼ and E to select module address – 016 to 254)
|
|
|
|- Baud --------------- E *38400 (Use |▲ or ▼ and E to select baud rate, * = current selection)
MAINT MENU
MAINT::
|
E – V2.00aB (Software version installed on module)
|
E – CCC001 (Configuration number)
Model 5100-02-IT Combustible Gas Sensor Module
|
|- Out: 4mA
|
▼ --or—E (To calibrate analog output 4mA, |▲ or ▼ to adjust level,
|
then E t o accept)
|- Out: 20mA
▼ --or--E (To calibrate analog output 20mA, |▲ or ▼ to adjust level,
|
then E to accept)
|- In: 4mA
▼ --or—E (To calibrate analog input 4mA, |▲ or ▼ to adjust level,
|
then E to accept)
|- In: 20mA
▼--or--E (To calibrate analog input 20mA, |▲ or ▼ to adjust level,
then E to accept)
|
|- Track: (▲ or ▼ (To adjust action/mA value during calibration
Track = mA value tracks Gas value
Hold = holds mA value existing prior to calibration
C1.50mA = 1.50 mA during calibration
C4.00 mA = 4.00 mA during calibration
User mA = |▲ or ▼ to adjust to desired mA value
|
|- T2.50mA: (▲ or ▼ (To select 2.50mA or User mA, * = current value)
User mA = |▲ or ▼ to adjust to desired mA value
