7.10 APPENDIX J: Menu Key for 5100-02-IT Gas Sensor Module

•
Key M : MODE
•
Key E : ENTER
•
Key ▲ UP (+)
•
Key ▼ DOWN (-)
MAIN MENU
key to access each of the 4 main sections of the menu.
M
Use the
M M
| |
|- ALMRSET: |- CALIB:
ALARM RESET MENU
ALMRSET:
|
E– RESET (Resets current alarm)
CALIB MENU
CALIB:
|
E – CAL-0% (Calibrate Zero)
|
E – Ack (Acknowledges Zero)
|
*50%-SPAN (Last span gas used – initially set at 50%)
| |
| ▲ 25%-SPAN
| ▲ 50%-SPAN (Select Span gas value from below)
| ▲ 75%-SPAN
| ▲ Adj-SPAN (To select an alternate span gas value)
| |
| E 50%-SPAN
| |
| ▲ 51%-SPAN (Change span value to desired, once completed E starts calibration)
|
E C XX%LEL (Reading the value of the calibration gas being applied)
|
|- CAL-OK (if successful) or CAL-FAIL (if unsuccessful)
Model 5100-02-IT Combustible Gas Sensor Module
M M
| |
|- SETUP: |- MAINT:
Page: 36
M
|
|- EXIT?
