- Page 1 FGX-OMW0021-B Product Name Vertical Suction Filter Model/Series/Product Number FHIAF-10-MԂG...
-
Page 2: Table Of Contents
FGX-OMW0021-B Contents Safety Instructions 1. Be sure to read before use. 1-1. Handling Precautions 1-2. Installation and Piping 1-3. Maintenance and Inspection Application 3. Specifications 4. How to Order 5. Component name and spare parts list 6. Troubleshooting 7. Replacement of the element 7-1. -
Page 3: Safety Instructions
FGX-OMW0021 Vertical Suction Filter Vertical Suction Filter Vertical Suction Filter Vertical Suction Filter Vertical Suction Filter Vertical Suction Filter Safety Instructions Safety Instructions Safety Instructions Safety Instructions Safety Instructions Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These safety instructions are intended to prevent hazardous situations and/or equipment damage. - Page 4 FGX-OMW0021 Vertical Suction Filter Vertical Suction Filter Vertical Suction Filter Vertical Suction Filter Vertical Suction Filter Vertical Suction Filter Safety Safety Safety Instructions Instructions Instructions Instructions Caution Caution The product is provided for use in manufacturing industries. The product is provided for use in manufacturing industries. The product is provided for use in manufacturing industries.
-
Page 5: Be Sure To Read Before Use
FGX-OMW0021-B 1. Be sure to read before use 1-1. Handling Precautions Caution 1) Check the specifications. This product is designed to filter the suction side of the cutting coolant for machine tools. Do not operate at conditions outside of the specification, as this could cause damage, malfunction or performance reduction. -
Page 6: Installation And Piping
FGX-OMW0021 1-2. Installation and Piping 2. Installation and Piping 2. Installation and Piping 2. Installation and Piping Caution Caution 1) Location 1) Location - Please install the product Please install the product Please install the product in a location where pulsation is unlikely to occur. in a location where pulsation is unlikely to occur. -
Page 7: Maintenance And Inspection
FGX-OMW0021-B 1-3 Maintenance and Inspection Caution (1) Perform maintenance inspection according to the procedures indicated in the operation manual. Incorrect handling can result in unexpected accidents due to fluid leakage. 2) Perform maintenance when the pressure becomes atmospheric pressure (gauge pressure: zero). -
Page 8: Application
FGX-OMW0021-B 2. Application Suction filter used for the inlet side of the pump for machine tools. The purpose is to filter the solid foreign matter contained in the coolant for cutting. 3. Specifications Note 1) Fluid Coolant Operating pressure(kPa) -100to0kPa Note 2) Operating fluid... -
Page 9: Component Name And Spare Parts List
FGX-OMW0021 5. Component name and spare parts list 5. Component name and spare parts list 5. Component name and spare parts list 5. Component name and spare parts list 5. Component name and spare parts list 5. Component name and spare parts list Components Components Replacement part... -
Page 10: Troubleshooting
FGX-OMW0021-B 6. Troubleshooting Failure Possible causes Countermeasures Category Phenomenon Flow Large air resistance Element is clogged. Replace the element. rate reduces flow rate. Fluid Leakage from between "O-ring" is damaged. Replace the “O”-ring. leakage the cover and vessel. Particles are caught in the Remove the dust. -
Page 11: Replacement Of The Element
FGX-OMW0021-B 7 Replacement of the element 7-1 Removal of element 1) Stop the operation of the circuit to ensure the pressure in the filter becomes atmospheric pressure. 2) Loosen the hexagon socket head cap screws (4pcs.) and remove them. Hexagon socket head cap screw 3) Remove the cover by pulling it upward. -
Page 12: Parts Check And Preparation Of The Element
FGX-OMW0021-B 7-2. Parts check and preparation of the element 1) Check the seating surface of the cover and case. Clean them if foreign matter is found. 2) Check the 3 O-rings and replace with new one if any problems are found. Clean the element or prepare new ones. -
Page 13: Cleaning Of The Element
FGX-OMW0021-B 6) Tighten the hand tightened hexagon socket head cap screws diagonally using a hexagon wrench. Tightening torque: 6.2Nm (reference value) Note) Check that no screws are loose. (1)(5) 7) Before actual operation, confirm there is no leakage. If there is leakage, remove the element after stopping the operation following the removal procedure of the element. -
Page 14: Dimensions
FGX-OMW0021 9. Dimensions 9. Dimensions 9. Dimensions Keep a space above the upper part of the filter for maintenance. Keep a space above the upper part of the filter for maintenance. Keep a space above the upper part of the filter for maintenance. Keep a space above the upper part of the filter for maintenance. - Page 15 FGX-OMW0021-B Revision history Added the Element filtration B : Added caution when assembling elements. 4-14-1, Sotokanda, Chiyoda-ku, Tokyo 101-0021 JAPAN Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 URL http://www.smcworld.com NOTE: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. ©...
