3. Specifications 4.External dimensions IBG10/Without adjuster IBG11/With adjuster Valve position adjuster Scale setting range: 0 (Fully closed) to 4 (Fully open) Locked: ≈100.3 Unlocked: ≈101.7 25.5 25.5 Rc1/4 Rc1/4 Discharge port Discharge port 84.6 84.6 37.6 37.6 Rc3/8, NPT3/8, G3/8 Rc3/8, NPT3/8, G3/8 Supply port Supply port...
Page 5
4.External dimensions IBG20/Without adjuster IBG21/With adjuster Valve position adjuster Scale setting range Rc1/4 0 (Fully close) to 4 (Fully open) Discharge port 92.5 19.6 19.6 Rc1/4 Protective cover Discharge port ∗1, ∗2 Protective cover 11.7 11.7 removed 75.8 75.8 31.8 31.8 Rc1/4, NPT1/4, G1/4 Rc1/4, NPT1/4, G1/4...
Page 6
4.External dimensions Long nozzle(Option) ≈ + 7 ∗Reference dimension after R thread installation [mm] R1/4 Part no. Nozzle I.D. Connection thread IBG1-12-10-50 IBG1-12-10-100 IBG1-12-10-150 ø10 R1/4 IBG1-12-10-300 IBG1-12-10-600-X1 Width across flats 19 Width across flats 17 IBG1-12-10-1000-X1 1000 Long nozzle with a silencer (Option) Union nut Ferrule...
5. Protective Cover Mounting/Dismounting Method < Dismounting> <Mounting> protective cover Snap fit (Top side) protective cover slot groove Snap fit end plate (Bottom side) By inserting a coin, flat blade Attach the protective cover to the end plate screwdriver, or the like to the slot using the snap fits provided at the top and groove of the protective cover and bottom.
6.How to mount a nozzle How to mount a nozzle to the Impact-Blowgun (Series IBG) Check that the ferrule is mounted inside the Nozzle fitting as shown in figure on the right. Hand-tighten the union nut. Ensure ferrule is Ferrule aligned properly.
Page 9
6.How to mount a nozzle How to mount a silent nozzle to the Impact-Blowgun (Series IBG) Check that the ferrule and element is mounted inside the silent nozzle as shown in figure on the right. Ferrule Element Hand-tighten the union nut. Ensure ferrule is Nozzle:...
Impact blow gun Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
Page 11
Impact blow gun Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
Page 12
Series Specific Product Precautions Be sure to read this before handling the products. Refer to the back cover for safety instructions. For other precautions, refer to the “Handling Precautions for SMC Products” and the “Operation Manual” on the SMC website: https://www.smcworld.com Prior to Use Mounting Warning...
Page 13
Series Specific Product Precautions Be sure to read this before handling the products. Refer to the back cover for safety instructions. For other precautions, refer to the “Handling Precautions for SMC Products” and the “Operation Manual” on the SMC website: https://www.smcworld.com Lubrication Maintenance Warning...
