4.2 MAIN MENU

Table 4-1 describes the primary human-machine interface operation.
Key Function
M E
Mode
M E
Enter
M E
Up
M E
Down
1.Xxa
M E
Mode
M E
Mode
M E
Mode
M E
Mode
M E
Mode
M E
Mode
M E
Enter
Table 4-2 describes the operational display values of the human-machine interface system.
ID
THE DISPLAY SHOWS
Display
Switch [M]
Switch [E]
Switch [▲] Previous Menu
Switch [▼] Next Menu
5100-02 First screen at power up-model
VX.Xxx Second screen at power up-version
Warm.XXX Third screen at start up-warm up
0%LEL Normal condition - default display
ALMRSET: Mode Function -Alarms Acknowledge
Banner: Use <M> switch for different menu items. Select <E> to
SSSSSSSS
enter menu item.
0%LEL Default Display
ALMRSET: Mode Function - Alarms Reset
CALIB: Mode Function - Calibrate
SETUP: Mode Function - Set Point Adjustments
MAINT: Mode Function - Maintenance
EXIT-? Exit Mode
0%LEL Apply Selected Mode (Exit)
0%LEL Default Display
Master Menu
Display
STARTING
##%LEL
L ##%LEL
H ##%LEL
HIGH
NO SENSR
C ##%LEL
ACK
Operation Display Values
"S " "S
TART INSTEAD OF TARTING
Page: 16
Model 5100-02-IT Combustible Gas Sensor Module
Description
Table 4-1
Description
Warm-up at start-up
Concentration
Low Alarm
High Alarm
>100% Full Scale
Sensor Failure
Calibration Mode
Acknowledged Function
Table 4-2
,
THE MODULE MUST BE CALIBRATED BEFORE USING IT
