5.1.3 Extended Operation ("Analog Control Mode")

 In order to be able to control the pump with external signals (PLC) the mode "Analog Control
Mode" has to be set with the display buttons. The "UP" and "Down" buttons have to be pressed
simultaneously during 5 seconds. The display should feedback the change by blinking between
the stored speed value and "An". The chosen mode is then stored in the EEPROM of the
controller.
 The system and levitation can be enabled/disabled with the digital input on the "USER
INTERFACE" connector (see Table 13). When disabling the running system, the speed is
automatically reduced to 0 rpm and the impeller is smoothly touched down without grinding the
wall.
 The speed can be set with an analog signal on the "USER INTERFACE" connector according to
Table 13. It is strongly recommended to use galvanic separated signal values
 For monitoring purposes a digital output on the "USER INTERFACE" connector (see Table 13)
indicates an error. In case of an error the codes described in Table 15 are displayed (blinking
between "An" and the according code number)

5.1.4 Error Display on the Integrated Panel

Error
Errors
Source
Motor No Motor
Motor Motor cable (power wires) not connected to controller
Motor Motor cable (sensor wires) not connected to controller
Motor No Rotor
Controller Short circuit
Controller Over current in the bearing coils
Controller Over current in the drive coils
DC-link voltage error < 90 VDC or > 378 VDC
(Corresponds to supply voltage of < 64 VAC or > 267 VAC)
Controller
If the voltage is out of range the system starts to reduce the speed to 0 rpm and the controller
goes into an error state.
Controller Communication problems EEPROM Controller
Motor Communication problems EEPROM Motor
Controller Controller temp. over 80°C or more than 10 minutes above 70°C
Motor Motor temp. over 100°Cor more than 10 minutes above 90°C
Dry running of pump circuit:
 Pump keeps running on reduced speed (5000 rpm)
Pump
 The system accelerates to the original speed value when the pump is refilled with liquid
 Note that the speed is only reduced during dry running if the pump speed was ≥ 6000 rpm.
Table 15: Errors and warnings with indication on display of LPC-2000.1
- In case of an error the system can only be restarted with a reset or a power supply restart
- Standard firmware is E1.25 for "High Flow" and E2.25 for "High Pressure" systems
- For other configurations of error codes refer to alternate controller or firmware documentation
PL-4021-00, Rev03, DCO# 15-235
User Manual for BPS-2000
www.levitronix.com
Error Code
on Display
Er 01
Er 02
Er 03
Er 04
Er 05
Er 06
Er 07
Er 08
Er 09
Er 10
Er 11
Er 12
Blinking
dots on
display
