Opitec Wind Machine Manual page 2

Instructions 100.803
Wind Machine
1
B
A
A
Carefully remove the pre-stamped parts (a-G) from the cork board (1).
3
A
A
Glue the cardboard connectors (2a) to the cork base part (A) with the
superglue. Connect them together as shown.
5
Shorten 2 rods (3) to a length of 250 mm. Then glue them into the
corners of the base with the superglue as shown. Note: The rod tip
faces up.
2
F
G
A
E
B
A
D
C
A
A
A
A
2
Cut out the carboard connectors (2a+2b) and carefully scratch the fold
lines with the tip of the scissors.
4
A
A
2a
Glue the finished base centered on the cardboard part (3g).
6
3
Remove the pre-stamped parts (3a-3f) from the cardboard sheet.
2
2b
3g
3c
3g 3b
3a
2a
3d
3e
3f
