Opitec Wind Machine Manual page 3

Instructions 100.803
Wind Machine
7
2b
2b
B
Glue the cardboard connectors (2b) to the cork part (B) with the superglue as shown. Glue a metal eyelet (5) in the cardboard part (3e), glue the cork
walls around the cardboard part (3e) and connect them together. To finish, insert a metal eyelet (5) from above into the cork part (C) and glue on
centered.
8
Glue the finished upper part of the tower between the round bars as
shown.
10
Then glue diagonal sticks between the horizontal sticks as shown
above.
Note: Gradually adjust lengths.
3
2b
2b
C
5
5
3e
9
9
Glue the craft sticks (9) horizontally to the rods according to the
dimensions shown.
Note: Gradually adjust lenghts.
11
To finish the tower, glue on more sticks rotated by 90°.
