Running worker with wheelbarrow
The OPITEC range of projects is not intended as toys for young children. They are tea-
ching aids for young people learning the skills of Craft, Design and Technology. These
projects should only be undertaken and operated with the guidance of a fully quali-
fied adult. The finished projects are not suitable to give to children under 3 years old.
Some parts can be swallowed. Danger of suffocation!
Parts List
Plywood
Wooden Ball
Wooden Wheel
Gear Motor
Battery Holder with Switch
Metal Axle
Gearwheel
Cylinder Head Screw
Cylinder Head Screw
Pan head countersunk-head tapping screw
Distance Rolls
Steering Wheel
Nut
Stop Nut
Washer
1
Please Note!
Quantity
1
1
4
1
1
1
2
2
2
2
2
2
10
2
10
120.830
Tools required:
jigsaw or fine
saw
File
Phillips
Screwdriver
Size (mm):
200x200x5
ø40
ø20
ø3x95
ø32
ø3x35
ø3x20
ø5
ø37
M3
M3
ø3,2/7
pencil
Ruler
Sandpaper
Wood Glue
Spanner
Slot Screwdri-
ver
Description
Base Plate
Head:
Feet
Drive
Power Source
Axis
Gearwheel
Mounting Gear
Fixing Leg/Gear
Guiding Legs
Spacer
Wheels/Wheelbarrow
Bracket
Bracket
Bracket
Soldering Iron
and Solder
ø3
ø4
Drill
Insulated Wire
Strippers
Part No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Opitec Running worker with wheelbarrow
Summary of Contents for Opitec Running worker with wheelbarrow
- Page 1 Drill Please Note! The OPITEC range of projects is not intended as toys for young children. They are tea- ching aids for young people learning the skills of Craft, Design and Technology. These projects should only be undertaken and operated with the guidance of a fully quali-...
- Page 2 Building Instruction 120.830 Running worker with wheelbarrow ø2 ø3 Transfer the template (page 5) to the base plate (1). Drill all holes (ø3, Saw off all parts and clean with sandpaper. ø4mm). Glue together the upper part of the wheelbarrow from the individual From the side edge, measure 8mm on both sides as shown and glue parts (1a, 1b, 1c) as shown.
- Page 3 Building Instruction 120.830 Running worker with wheelbarrow Glue together the wooden parts (1g, 1h, 1k) to the body of the worker Slide the metal axle (5) through the holes in the axle brackets and as shown above. attach a steering wheel (12) from both sides.
- Page 4 Building Instruction 120.830 Running worker with wheelbarrow For better grip, flatten the wooden ball (2) ø40mm with the workshop Glue the two arms (1j) at the marked point on both sides of the body file on one side. Then apply to the top of the body.
- Page 5 Building Instruction 120.830 Running worker with wheelbarrow Template M 1:1...
