Perlesmith PSLTK1 Instruction Manual page 4

05
Washers
M4 / M5
[B1] x 4
M6 / M8
[B2] x 4
07
M4
M6
M8
Supplied Parts and Hardware for Step 2 and 3
Right Wall Plate
NOTE: The spacers shown are actual size.
TV Bolts
[Only one size of the bolt fits your TV]
NOTE: The bolts shown are actual size.
M4 x 12mm
[C1] x 4
M6 x 15mm
[D1] x 4
M8 x 15mm
[E1] x 4
01 x 1
Left Wall Plate
06
Spacers
[F1] [F2]
x 8
L2.5mm L10mm
02
03
[if needed]
[F3]
x 4
L22mm
M4 x 30mm
[C2] x 4
M6 x 35mm
[D2] x 4
M8 x 35mm
[E2] x 4
M8 x 50mm
[E3] x 4
Level
x 1 08
x 4
x 1
