IMPORTANT SAFETY INFORMATION
Please carefully read all instructions before attempting installation. If you do
not understand the instructions or have any concerns or questions, please
contact our customer service at supportus@perlesmith.com.
CAUTION: Avoid potential personal injuries and property damage!
• Do not use this product for any purpose that is not explicitly specified in this
manual. Do not exceed weight capacity. We are not liable for damage or injury
caused by improper mounting, incorrect assembly or inappropriate use.
• This product is designed for use in wood stud, solid concrete, concrete
block and brick walls. - DO NOT install into drywall alone.
• The wall must be capable of supporting five times the weight of the TV and
mount combined.

Weight Restrictions

132 lbs /
60 kg
If your TV weighs more, this
mount is NOT compatible.
Check the VESA Pattern of TV before the Installation
Minimum VESA pattern: 200mm / 7.9" (W) x 100mm / 3.9" (H)
If your TV VESA is greater than 600 x 400mm / 23.6 x 15.7" or less
than VESA 200 x 100mm / 7.9 x 3.9", this mount is NOT compatible.
DO NOT exceed the maximum weight indicated.
This mounting system is intended for use only
within the maximum weights indicated. Use with
products heavier than the maximum weights
indicated may result in failure of the mount and
its accessories, causing damage and or injury.
3 . 6 "
m / 2
6 0 0 m
M A X :
WARNING
100mm ≈ 3.9"
200mm ≈ 7.9"
400mm ≈ 15.7"
600mm ≈ 23.6"
01
