Pin No. Mnemonic
68 AVDD
69 AGND
70 AGND
71 AVDD
72 AUXOUT1L
73 AUXOUT1R
74 AUXOUT2L
75 AUXOUT2R
76 AUXIN2L
77 AUXIN2R
78 AUXIN1L
79 AUXIN1R
80 ISET
Description
DAC Supply (3.3 V).
DAC Ground.
DAC Ground.
DAC Supply (3.3 V).
Left Auxiliary Output 1.
Right Auxiliary Output 1.
Left Auxiliary Output 2.
Right Auxiliary Output 2.
Left Auxiliary Input 2.
Right Auxiliary Input 2.
Left Auxiliary Input 1.
Right Auxiliary Input 1.
ADC Current Setting.
