The Intatherm thermostatic basin tap is designed for
installing on one hole basins.
The IT1007CP tap is supplied with two 350mm long
copper tails ready to be fitted to the tap. Each tail is
supplied ready to connect to the compression
connector with integral check valve and filter (12).
Screw the threaded rod (9) into the threaded hole in
the base of the body taking care not to over tighten.
The cold supply must be connected to the
right hand side and the hot to the left hand
side of the mixer when viewed from the
front.
7
Ensure that the 'O' ring seal (7) is located in the
8
base of the tap prior to fitting the mixer to the basin.
9
Once in place using the horse shoe retaining plate
(8) secure in position, taking care not to over tighten
the retaining nut (10).
10
Connect the connectors (12) to the tails and to the
hot and cold supplies remembering which was
connected to the hot inlet and ensure all joints are
water tight.
For optimum mixing performance where the hot and
cold pressures are not equal, regulating
valves should be installed directly upstream of the
tap so that the water supply pressures can be
regulated and equalised.
