Summary of Contents for Cookology BUGL520BK
- Page 1 BUGL520BK & BUGL520WH Cooker hood Instruction manual 52cm...
-
Page 2: Table Of Contents
CONTENT 1……………………………………….Notice 2……………………………………….Feature 3………………………………………..Installation 4………………………………………..Notice of installation 5………………………………………..Safety Warning 6…………………………………………Speed adjustment 7…………………………………………Maintenance 8………………………………………….. Abnormity and Solution... -
Page 3: Notice
1.Notice This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. - Page 4 The instructions shall state the substance of the following: – there shall be adequate ventilation of the room when the range hood is used at the same time as appliances burning gas or other fuels (not applicable to appliances that only discharge the air back into the room);...
- Page 5 – CAUTION: Accessible parts may become hot when used with cooking appliances. The installation instructions shall include the substance of the following: – the air must not be discharged into a flue that is used for exhausting fumes from appliances burning gas or other fuels (not applicable to appliances that only discharge the air back into the room);...
- Page 6 discharge of air have to be fulfilled. The installation instructions for range hoods with accessible metallic enclosures of class II construction shall include details that indicate the location and maximum permitted lengths for any fixing or mounting screw or other fixing device that penetrates into the range hood to attach an accessory such as a facia or duct fitting.
-
Page 7: Feature
substance of the following warning. Warning: Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards Feature 1. The cooker hood uses high quality materials, and is made with a streamlined design. 2. -
Page 8: Notice Of Installation
Pic 1 3. Put the hood into the cabinet, tighten up the screws by screwdriver, and make sure the hood was fixed. Pic 2. 4. Notice of installation 1. Before installation, please ensure the area is clean to avoid suction of the remaining bits of broken wood and dust. -
Page 9: Speed Adjustment
for their safety. Do not touch the light bulbs when/after appliance use. • Do not check the status of the filters while the cooker hood is • operating Flame cooking is prohibited underneath the cooker hood • Your cooker hood is for domestic use only, not suitable for barbecue, •... -
Page 10: Maintenance
1. Press the “Power” button, the button control the “on” & “off ” of the hood. 2. Press the button “Speed” time after time, the motor runs as low / mid / high / low / mid…, the speed runs circularly; and the LED display will indicate as 1-2-3-1-2…... - Page 11 Attention! Please do not use abrasive detergent or alcohol as it will damage the body. Attention! Keep the motor and other spare parts free from water, as this will cause damage to the appliance. Attention! Before cleaning the appliance please remember to cut off the power.
- Page 12 Activated carbon filter can be used to trap odors. Normally the activated carbon filter should be changed at three or six months according to your cooking habit. The installation procedure of activated carbon filter is as below. 1. Before installing or replacing the carbon filters, please remove power to the unit.
- Page 13 gloves to ensure perspiration does not come in contact with the globe as this can reduce the life of the globe. Note: Before changing the lights, make sure that the appliance is plugged off. Protect against danger when changing lights, such as wearing gloves. ...
-
Page 14: Abnormity And Solution
Abnormity and Solution Fault Cause Solution The leaf blocked Get rid of the blocking The capacitor damaged Replace capacitor Light on, but motor does not work The motor jammed bearing Replace motor damaged The internal with of motor off or Replace motor a bad smell from the motor Beside the above mentioned, check the following:... - Page 15 Insufficient suction The distance between the Readjust the distance body and the gas top too long Too much ventilation from Choose a new place and open doors or windows resemble the machine The machine inclines The fixing screw not tight Tighten the hanging enough screw and make it...
