1.Notice This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Page 4
The instructions shall state the substance of the following: – there shall be adequate ventilation of the room when the range hood is used at the same time as appliances burning gas or other fuels (not applicable to appliances that only discharge the air back into the room);...
Page 5
– CAUTION: Accessible parts may become hot when used with cooking appliances. The installation instructions shall include the substance of the following: – the air must not be discharged into a flue that is used for exhausting fumes from appliances burning gas or other fuels (not applicable to appliances that only discharge the air back into the room);...
Page 6
discharge of air have to be fulfilled. The installation instructions for range hoods with accessible metallic enclosures of class II construction shall include details that indicate the location and maximum permitted lengths for any fixing or mounting screw or other fixing device that penetrates into the range hood to attach an accessory such as a facia or duct fitting.
substance of the following warning. Warning: Failure to install the screws or fixing device in accordance with these instructions may result in electrical hazards. Feature 1. The cooker hood uses high quality materials, and is made with a streamlined design. 2.
Page 8
If you have an outlet to the outside, your cooker hood can be connected as below picture by means of an extraction duct. (enamel, aluminum, flexible pipe or non-flammable material with an interior diameter of 150mm) 1. Before installation, turn the unit off and unplug it from the outlet. 2.
Page 9
3. For safety, the ceiling should be bear at least 120kgs, and the thickness should be more than 30mm. 4. According to the hanging board, drill 12 holes on the ceiling. Use 12 pcs ST60×40mm screws to fix the hanging board on the wooden ceiling or use 8 pcs concrete anchor to fix the hanging board on the concrete ceiling.
6. Lead one side of the expansion pipe to the outside through the hole of 170 mm in the ceiling. See pic 4. 7. 4pcs ST4*8 big flat screws will be used to connect the inside chimney into the hanging board, then put on the outside chimney, a hook will be used to put up the outside chimney in order to the next installation, see pic 5.
2. It cannot share the same air ventilation tube with other appliance such as gas tube, warmer tube, and hot wind tube. 3. The bending of ventilation tube should be≥120°, parallel or above the start point and should be connected to the external wall. 4.
• Attention! Observe the warning in the instruction sheet concerning the operation of the appliance when air is discharged from the room. • Regarding the instructions for the bulb changing, pls use the same bulb and ILCOS D code for this lamp is DSR-1.5/65-S-64 6.
Page 13
3. The proper function of the cooker hood is conditioned by the regularity of the maintenance operations, in particular, the active carbon filter. 4. The anti-grease filters capture the grease particles suspended in the air, and are therefore subject to clogging according to the frequency of the use of the appliance.
Page 14
Soak them for about 3 minute in hot water (40-50 degrees) with a mild detergent and then brush it gently with a soft brush. Please do not apply too much pressure, avoid damaging it. Note: Do not use abrasive detergent for it will damage the hood; Make sure that the hood is shut off before cleaning.
carrying out any operations on the appliance. When handling bulb, make sure it has completely cooled down before any direct contact to hands. When handling blubs hold with a cloth or gloves to ensure perspiration does not come in contact with the blub as this can reduce the life of the blub.
Page 16
The capacitor damaged Replace capacitor Light on, but motor The motor jammed bearing Replace motor does not work damaged The internal with of motor off or Replace motor a bad smell from the motor Beside the above mentioned, check the following: Light does not work, Light damaged Replace lights...
Page 17
on the environment, electrical and electronic products are potentially dangerous for the environment and human health due to the presence of hazardous substances. For more information, please contact your local or regional authorities. Note: a. In order to reduce the environmental impact (e.g. energy use) of the cooking process, please be sure that your product is installed according to the user manual, keep the operation place ventilated, keep the extraction duct be direct and short as possible as it can be.
