General Specifications:

Architecture: Direct Sampling DDC/DUC Transceiver
Interface: Ethernet
Phase Noise (Clock): -149dB @ 10Khz
TCXO Stability (Typical): /- .1 PPM
Modes: CW, SSB, NFM, AM, Digital
Antenna Ports: 3 - BNC 50 ohm Software Configurable Ports, 2 - BNC ADC1 receive only
antenna ports, 1 – BNC Transverter receive only port, 1 - BNC for ADC2
Frequency Resolution: 1 Hz

Electrical Specifications:

13.8v DC @ 30A, 3A Receive/30A Transmit

Mechanical Specifications:

10 Kg (approx. Weight)
Dimensions: 384MM (L) x 110MM (H) x 310MM (W) (Not including extrusions)
Rugged Steel Chassis with Temperature controlled internal/External (Optional)
Fan.

Receiver Specifications:

Receiver Architecture: Direct Down Conversion
Dual 16 bit Phase Synchronous ADCs
Independent filter banks for each ADC
6M LNAs
Frequency Coverage: 9Khz to 60Mhz
Attenuator: 1-30dB step attenuator
Reciprocal Mixing Dynamic Range (RMDR): 116dB @ 2Khz offset
Receiver Phase noise: -149dB @ 10Khz
Image rejection: 90dB
Hardware support for 7 independent receivers assignable to either ADC

Transmitter Specifications:

Transmitter Architecture: Direct Up Conversion
DAC Resolution: 16 bit
RF Output Power: 100W SSB, CW, FM, RTTY, Digital; 1-30W AM
IMD3 typically -68dB below PEP @ 100W output on 20M
Harmonics: Typically better than -43dBc on HF and -60dBc on 6M
Carrier and Opposite Sideband Suppression: Better than -80dBc
Transverter IF Output: 0db to 15dB
