PowerSDR MRX PS Instructions

3.

Hardware Setup

The ANAN transceiver should be carefully placed to allow unobstructed airflow around and beneath the
housing. Damage can occur if the ventilation openings on the bottom or chassis of the ANAN
Transceiver are blocked. Allow room for airflow between the housing and other equipment.
Connect the supplied 13.8VDC cable to the rear panel power connector and to a filtered 13.8VDC +/-
5%, power supply capable of providing up to 30A. observe proper polarity
Connect a suitable ground cable to the rear panel ground terminal to your station RF ground, in
accordance with good amateur practices.
Connect a 50 ohm transmission line between the rear panel ANT1 SO-239 connection and a 50 ohm
dummy load.
Connect powered stereo speakers or a stereo headset to the front panel 1/8" (3.5mm) stereo jack.
For Phone operation connect a condenser or dynamic microphone equipped with a 1/8"(3.5mm) plug
into the front panel jack. Note that the wiring of this jack is software controlled in the Setup menu of
PowerSDR.
For CW operation, connect your favorite paddles to the CW KEY jack on the front panel.
Connect an Ethernet cable between the front panel RJ45 LAN jack and your router, Gigabit switch, or
PC Ethernet port. Note: the Automatic Private IP (IP) Assignment (APIPA) feature is incorporated in the
firmware of the ANAN-7000DLE MKII.
Copyright Apache Labs ©
Refer to the Front and Back Panel illustrations
page 20
26 February 2019
