PowerSDR mRX PS IP address

Note: Make sure you have selected the proper radio model from the selections on the LEFT side of the
Hardware Configuration box. Failure to do so will result in an improper set of menu options and displays.
The Static IP Addresses are available to assign your instance of PowerSDR to a particular Apache Transceiver.
There may be several Transceivers on your LAN and the Static IP address makes it convenient for assigning this
software to a particular unit – where each unit has it's own IP address.
Setup ---> General tab ---> Hardware Config tab, the Radio Model should have ANAN-7000DLE selected.
In the "Region", select the Country in which you reside.
The IP address and Firmware version number in the box highlighted above will be assigned automatically by
your network router DHCP server, or if connected directly to your PC, the IP address will be assigned by the
"APIPA" process – WHICH MAY TAKE UP TO SEVERAL MINUTES TO ASSIGN AN IP ADDRESS.
If your LAN is properly configured, the ANAN Transceiver board IP ADDRESS and MAC ADDRESS should be
automatically detected and assigned. The correct default value is 169.254.1XX.XXX. PowerSDR will display
the currently assigned IP address and MAC address of the ANAN Transceiver Hermes board if the LAN
connection is properly connected and configured. If the ANAN Transceiver IP ADDRESS remains 0.0.0.0 then
you must determine if PowerSDR and your PC network connection is operating correctly. Some typical
problems could be that the Ethernet connection to your PC or LAN connector is disabled in Windows. The
Ethernet connector may not be properly seated in your PC or Router. DHCP addressing must be properly
enabled on your router. The new HPSDRProgrammer V2 utility allows you to assign a STATIC IP ADDRESS if
you wish.
Please see the APIPA appendix of this document for more information.
