Simple Network Setup

The Apache-Labs ANAN Transceivers are designed to work via Ethernet cabling on [a] "Local Area Network" or
[b] directly connected to your PC. Ethernet simplifies the installation, and configuration of hardware and
software, making the installation basically "plug and play". No sound card interface wiring, no Firewire
cards or drivers, no USB ports or drivers are needed. It just works!
For the most basic network, you don't need any external hardware other than an Ethernet cable
between your Windows PC LAN port and your Transceiver's LAN port.
The ANAN Transceiver will query for a "DHCP" network address or an APIPA address [discussed in
Appendix below]
Hardware Requirements
13.8vdc minimum, 30A [Recommended]
Note: some switching DC supplies create objectionable EMI/RFI which may degrade performance of the
ANAN transceiver.
Ham band resonant 50 ohm HF antenna for normal Ham Radio operation.
Suitable 100W Dummy Load (or greater) required for PA calibration.
PC condenser or dynamic microphone terminated in 6.25mm Front/ 3.25mm Back Panel
CW key terminated in 6 .25mm Front/ 3.25mm Back Panel , for CW operation.
A set of stereo speakers or stereo headphones with 6.25mm Front/ 3.25mm Back Panel.
6.25mm Front/ 3.25mm Back Panel
Note: the Front Panel connections to the 7000DLE MKII are 6.25mm stereo jacks.

Recommended Software

Windows 7, 8, or 10 recommended.
Microsoft .NET 2.0 & 4.0 Framework required.
OpenHPSDR PowerSDR mRX PS (multi-receiver with PureSignal)
OpenHPSDR and download information
