Appendix

Apache Schematics

The ANAN-7000DLE schematic are available by request from Apache Labs LLC.
Balanced Audio Input is not implemented in the current Apache Labs Transceivers.
The LEFT LINE level input is currently selectable in PowerSDR as an alternative to the mic input.
Balanced audio is not supported by the CODEC hardware used in the ANAN radios. If a balanced input is
required then an external balanced to unbalanced transformer [or active electronic equivalent] will be required.

Independent versions of PowerSDR software

Multiple independent .xml databases

Go to the Properties of the shortcut.
At the end of the Target you can add the new directory path using the
command line argument –datapath:<"directory path">
To create a new directory for the ANAN-7000DLE radio I use the name PowerSDR
ANAN_7K like this:
start -datapath:"%appdata%\FlexRadio Systems\PowerSDR ANAN_7K\"
My new Target will look like this:
"C:\Program Files [x86]\OpenHPSDR\PowerSDR mRX PS\PowerSDR.exe"
-datapath:"%appdata%\FlexRadio Systems\PowerSDR_7K\"
When you start PowerSDR using the modified shortcut you will receive
this message the first time.
Ensure the directory path is correct. The click on Yes.
You will then get the normal startup with a new wisdom file and database
created in the new folder.
