Note: Customer is responsible for FEDEX shipping and all local Customs, Tariff, VAT, Taxes and incidental
charges within their delivery [address] Country. Please contact Apache Support
for details regarding your order or shipping charges.
Apache Labs LLC, Inc. - Declarations of Conformity
The ANAN-7000DLE MKII complies with FCC Part 97 rules for the Amateur Radio Service. It has been confirmed
by the relevant authorities that the ANAN-7000DLE MKII DOES NOT require FCC certification. Under rule 97
Amateur radio equipment with the exception of amplifiers and scanning receivers are exempt from certification,
however, must conform to rule 97 which states that harmonic and spurious emissions must be below 43dB of
the transmitted out up to 30MHz and 60dB beyond that.

Apache Labs Products CE and RTTE Certified

CE & EC Radio and telecommunications terminal equipment [RTTE] Certification.
We are pleased to announce that the ANAN series HF & 6M SDR transceivers including the ANAN-7000DLE MKII
is now CE and RTTE certified as per EU trade directives, All ANAN radios are RoHS compliant as well, we ensure
that our products are of the highest quality and meet international standards of quality and compliance.
Important Operation tips
Do not cover rear or bottom ventilation holes. Proper air circulation throughout the ANAN Transceiver is
necessary to prevent possible overheating and failure.
Calibrate power output to 100W using a suitable 50 ohm Dummy Load. Operating at higher levels will
damage the radio. Please review CCW and ICAS specifications on this page.
Data/AM/FM and other continuous duty modes must be operated at 30W or less to remain within the
operational limits of the radio.
Input voltage must be 13.8vdc +/- 5%, well regulated at 30A Peak and proper POLARITY must be
observed.
DISCONNECT the Antenna during Thunderstorms or when not in use.
Please ensure that you select the correct model during software setup.
Install the supplied rubber feet on the bottom of the case for proper cooling.

Heat Dissipation

The ANAN-7000DLE MKII uses a heavy duty Aluminum heat sink to dissipate heat with temperature controlled
internal and optional external fan.
ICAS [100W] operation
SSB, CW and all ICAS modes [Intermittent Commercial/Amateur Service] 100W PEP
The Power Amplifier MOSFET transistor has characteristics that far exceed the needs of normal Transceiver
operation.
