UG-782

BILL OF MATERIALS

Table 3. Bill of Materials
Quantity Reference
1 B1
2 C1, C7
2 C2, C8
1 C3
2 C4, C5
1 C6
1 J1
1 J2
1 J3
1 J4
1 J5
1 J6
1 J7
1 J8
1 J9
1 L1
1 R1
1 R2
1 R3
1 R4
1 R5
2 R6, R11
3 R7, R12, R15
1 R8
1 R9
1 R10
1 R13
2 R14, R22
5 R16, R17, R20, R21, R23
1 R18
1 R19
1 TP1
1 TP2
1 TP3
1 TP4
2 TP5, TP6
1 U1
1 U2
Description
CR2032 holder
0.1 µF capacitors, C0603
4.7 µF, 10 V capacitors, C0603
Supercapacitor, 12 × 12
1 µF,10 V capacitors, C0603
10 nF capacitor, C0603
DIS_SW jumper, SIP2
VOUT jumper, SIP14_dual
INPUT jumper, SIP10_BtoB
OUTPUT jumper, SIP8_2rows
INPUT1 jumper, PV_INPUT
GND jumper, SIP3
OUTPUT jumper, SIP10
VIN jumper, SIP3
INPUT2 jumper, PV_INPUT
22 µH inductor, 3 × 3
2 MΩ resistor, R0603
2.32 MΩ resistor, R0603
1.4 MΩ resistor, R0603
1.02 MΩ resistor, R0603
5.9 MΩ resistor, R0603
4.99 MΩ resistors, R0603
4.7 MΩ resistors, R0603
4.7 Ω resistor, R0805
3.3 kΩ resistor, R0603
4.02 MΩ resistor, R0603
20 kΩ resistor, R0603
1 MΩ resistors, R0603
NC (no connect) resistors, R0603
18 MΩ resistor, R0603
0 Ω resistor, R0603
PGOOD test point, SIP1
BAT test point, SIP1
BATT test point, SIP1
VOUT test points, SIP1
GND test points, SIP1
ADP5090 16-lead LFCSP
ADP161 5-lead SOT-23
Rev. A | Page 8 of 9
ADP5090-2-EVALZ User Guide
Part Number
BC2032-F1
GRM188R71H104KA93
GRM21BR61A475KA73
PB-5R0H104-R
GRM185R61A105KE36
GRM188R71H103KA01
61304011121
61001421121
61301011021
61300821021
Not applicable
61304011121
613010143121
61304011121
Not Applicable
EPL3015-223ML, 744025220
CRCW06032M00FKEA
CRCW06032M320FKEA
CRCW06031M40FKEA
CRCW06031M02FKEA
CRCW06035M90FKEA
CRCW06034M99FKEA
CRCW06034M70FKEA
CRCW08054R70JNEAIF
CRCW06033K3FKEA
CRCW06034M02FKEA
CRCW060320K0FKEA
CRCW06031M00FKEA
Not Applicable
RK73B1JTTD186J
CRCW06030000FKEA
61304011121
61304011121
61304011121
61304011121
61304011121
ADP5090ACPZ-1-R7
ADP161AUJZ-R7
Vendor
Memory Protection Devices
Murata
Murata
Cooper Bussmann
Murata
Murata
Würth Elektronik
Würth Elektronik
Würth Elektronik
Würth Elektronik
Alta Devices
Würth Elektronik
Würth Elektronik
Würth Elektronik
Alta Devices
Coilcraft®, Würth Elektronik
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Vishay Dale
Not Applicable
KOA
Vishay Dale
Würth Elektronik
Würth Elektronik
Würth Elektronik
Würth Elektronik
Würth Elektronik
Analog Devices
Analog Devices
