iTero Element 2 and iTero Element Flex User Manual
3.5.1

Scanner toolbar

The following toolbar is displayed on the top of each of the scanner windows:
The 4 center buttons indicate the current status of the scan process.
30
Tap to return to the home screen.
Displays the current stage in the scanning process, also indicated by the relevant
highlighted button in the toolbar.
Tap to return to the New Scan window to view the Rx, as described in section 4.1.
Tap to move to Scan mode to scan the patient, described in section 4.2.
Tap to move to View mode to view the scanned model, described in section 4.3.
Tap to send the scanned model to the lab, described in section 0.
Tap to view the remaining charge on the iTero external battery.
A battery indicator will appear, showing the percentage of battery charge remaining. When
the battery icon displays a lightning bolt symbol, the battery is charging.

Figure 36: Remaining battery charge

Tap to adjust the preferences for your iTero scanner, for example, for wand configuration,
localization, user settings, and more.
For more information on the Settings preferences, see section 3.6.
