Features

3 Features
The STM32F0DISCOVERY kit offers the following features:
STM32F051R8T6 microcontroller featuring 64 KB Flash, 8 KB RAM in an LQFP64
●
package
On-board ST-LINK/V2 with selection mode switch to use the kit as a standalone
●
ST-LINK/V2 (with SWD connector for programming and debugging)
Board power supply: through USB bus or from an external 5 V supply voltage
●
External application power supply: 3 V and 5 V
●
Four LEDs:
●
–
–
–
–
Two push buttons (user and reset)
●
Extension header for LQFP64 I/Os for quick connection to prototyping board and easy
●
probing.
An additional board is provided with the kit which can be connected to the extension
●
connector for even easier prototyping and probing.
A large number of free ready-to-run application firmware examples are available on
●
www.st.com/stm32f0discovery
8/41
LD1 (red) for 3.3 V power on
LD2 (red/green) for USB communication
LD3 (green) for PC9 output
LD4 (blue) for PC8 output
Doc ID 022910 Rev 2
to support quick evaluation and development.
