Connecting modules on the prototyping board
5.2
ST MEMS "adapter boards", standard DIL24 socket
STMicroelectronics has defined a standard DIL24 connector to easily evaluate its MEMS
sensors connected to a microcontroller through SPI or I2C communications.
Table 9
is one solution for connecting the DIL24 boards to the STM32F0DISCOVERY, this
solution is used in different examples and available at www.st.com/stm32f0discovery.
Table 9.
P01 VDD Power supply
P02 Vdd_IO Power supply for I/O pins
P03 NC
P04 NC
P05 NC
P06 NC
P07 NC
P08 NC
P09 NC
P10 NC
P11 NC
P12 NC
P13 GND 0V supply
P14 INT1 Inertial interrupt 1
P15 INT2 inertial interrupt 2
P16 NC
P17 NC
P18 NC
P19 CS - 0:SPI enabled 1:I2C mode
SCL (I2C serial clock)
P20
SPC (SPI serial clock)
SDA I2C Serial Data
P21
SDI SPI Serial Data Input
SDO SPI Serial Data Output
P22
I2C less significant bit of the device address
P23 NC
P24 NC
30/41
Connecting with a DIL24 board
ST MEMS DIL24 Eval board
Doc ID 022910 Rev 2
STM32F0DISCOVERY
3V
VDD
3V
VDD
GND
GND
PB12
GPIO INPUT EXTI (5V tolerant)
PB11
GPIO INPUT EXTI (5V tolerant)
PA11
GPIO OUTPUT (5V tolerant)
PB6
I2C1_SCL
PB3
SPI1_SCK
PB7
I2C1_SDA
PB5
SPI1_MOSI
PB4
SPI1_MISO
UM1525
