Danfoss ET4200 Operator's Manual page 40

1. Insert the fitting in the correct position. Position the fitting within
the crimping surfaces and at least 2 - 4 mm away from the end
of the crimping die.
2. Press the
dies are tight to the crimped sleeve.
3. Disconnect the machine from power supply and secure it against
unintentional restart.
4. Loosen the clamping lever (4).
5. Push the sleeve (2) towards the fitting.
6 Tighten the clamping lever (4) securely.
7. Switch on the machine.
8. Activate the illuminated foot pedal
automatically when the workpiece is pressed against the depth
stop.
9. Form the work piece.
10. Press the
11. Check the work piece.
12. If the work piece meets the requirements: produce other identi-
cal work pieces.
13. If the dimension is not reached: Adjust difference on the control
unit, form again and check the work piece.
Activate automatic opening in the control for series production.
button to close the crimping tool until the crimping
button to open the tool.
. The machine is closed
