To confirm your card is setup correctly to run applications, run the following command and
visually compare the 'Platform' and 'SC Version' entries under Flashable partitions
running on FPGA and Flashable partitions installed in system confirm they
match. See Displaying Card BDF Values
$ sudo /opt/xilinx/xrt/bin/xbmgmt examine --report platform --device
<management BDF>
In the following example output, the platform (xilinx_u250_gen3x16_base_3,
xilinx_u250_gen3x16_xdma_shell_3_1) and SC Version (4.6.11) displayed under Flashable
partitions running on FPGA and Flashable partitions installed in system both match.
Flashable partitions running on FPGA
Platform
SC Version
Platform UUID
Interface UUID
Platform
Logic UUID
Interface UUID
Flashable partitions installed in system
Platform
SC Version
Platform UUID
Platform
Logic UUID
Interface UUID
Under Flashable partitions installed in system it displays available shell
partition(s) available to program on the FPGA. In this example, only one shell partition is available
xilinx_u250_gen3x16_xdma_shell_3_1.
The logic-uuid and interface-uuid are used by the system to ensure compatible base and
shell partitions are used for a given application.
If no shell partitions are displayed under Flashable partitions installed in system
(as shown in the following output), it implies no shell partitions compatible with the base
partition have been installed. Download and install a compatible shell partition from the Getting
Started tab on the respective Alveo card product page:
• Alveo U200 Product Page
• Alveo U250 Product Page
• Alveo U280 Product Page
Flashable partitions running on FPGA
Platform
SC Version
Platform UUID
Interface UUID
UG1301 (v2.2) August 19, 2022
Getting Started with Alveo Accelerator Cards
to obtain the device management BDF.
: xilinx_u250_gen3x16_base_3
: 4.6.11
: 48810C9D-1786-0EF5-3E9E-529E8B14CE39
: 695718EC-21A2-32E4-5E1A-FCB4E558E11F
: xilinx_u250_gen3x16_xdma_shell_3_1
: BD5FB8AB-AB26-6C32-6591-8257B5048E88
: F2F6C5E1-273E-7894-8F2C-4806221462F2
: xilinx_u250_gen3x16_base_3
: 4.6.11
: 48810C9D-1786-0EF5-3E9E-529E8B14CE39
: xilinx_u250_gen3x16_xdma_shell_3_1
: BD5FB8AB-AB26-6C32-6591-8257B5048E88
: 695718EC-21A2-32E4-5E1A-FCB4E558E11F
: xilinx_u250_gen3x16_base_3
: 4.6.11
: 48810C9D-1786-0EF5-3E9E-529E8B14CE39
: 695718EC-21A2-32E4-5E1A-FCB4E558E11F
Chapter 5: Card Bring-Up and Validation
