Xilinx Alveo U200 Getting Started page 13

IMPORTANT! Ne débranchez pas le connecteur auxiliaire d'alimentation des cartes Alveo™ pendant
qu'elles sont sous-tension ("hot-plug" n'est pas autorisé).
WICHTIG! Trennen Sie den Alveo™-Stromanschluss-Stecker nicht im eingeschalteten Zustand (Hot-Plug
ist nicht zulässig).
The following procedure is a guide for the Xilinx
installation. Consult your computer documentation for additional information.
If you encounter any issues during installation, see
1. Host power supply must be disconnected.
2. For enclosed computers, open your computer by removing the casing.
3. If necessary, remove the two adjacent PCIe
in which you are installing the Alveo card.
4. Plug the Alveo card in the PCIe x16 slot on the motherboard.
5. Connect the AUX power connector to the Alveo card, ensure the plug is mechanically fixed
(with the click).
IMPORTANT! Operation of the Alveo cards only with AUX power connector is not allowed.
IMPORTANT! Le fonctionnement des cartes Alveo uniquement avec le connecteur auxiliaire n'est pas
autorisé.
WICHTIG! Der Betrieb von Alveo-Karten nur mit AUX Connector ist nicht zulässig.
The Alveo card has an 8-pin receptacle PCIe AUX power connector. Depending on your
server or computer, an additional PCI Express auxiliary power cable or adapter may be
needed. Consult your computer documentation for additional information.
For actively cooled cards, connect the power cable to the AUX power connector at top of the
card as shown in the following figure.
UG1301 (v2.2) August 19, 2022
Getting Started with Alveo Accelerator Cards
Chapter 3: Card Installation Procedures
® Alveo™ data center accelerator card
Chapter 7: Troubleshooting.
® slot covers corresponding to the PCIe x16 slot
