Xilinx Alveo U200 Getting Started page 21

IMPORTANT! N'entrez pas Ctrl + c dans le terminal lorsque le micrologiciel clignote, car cela pourrait
rendre la carte inutilisable.
IMPORTANT! Geben Sie im Terminal nicht Strg + c ein, während die Firmware blinkt, da dies dazu
führen kann, dass die Karte nicht mehr funktioniert.
Successfully flashing a new card results in a message similar to the following. If the command
returns Card Not Found, perform a cold boot, and retry. Otherwise, see
Troubleshooting.
[0000:03:00.0] : Updating base (e.g., shell) flash image...
Bitstream guard installed on flash @0x1002000
Extracting bitstream from MCS data:
..................................
Extracted 34746164 bytes from bitstream @0x1002000
Writing bitstream to flash 0:
..................................
Bitstream guard removed from flash
INFO : Base flash image has been programmed successfully.
----------------------------------------------------
Report
[0000:03:00.0] : Satellite Controller (SC) is either up-to-date,
fixed, or not installed. No actions taken.
[0000:03:00.0] : Successfully flashed the base (e.g., shell) image
Device flashed successfully.
****************************************************
Cold reboot machine to load the new image on device.
****************************************************
If the card has been flashed with the current platform firmware, you will see a message
similar to the following:
Device(s) up-to-date and do not need to be flashed.
10. Cold boot your machine to load the new base firmware image on the FPGA.
IMPORTANT! Be sure to fully power OFF the machine and then power it ON again. The image will
not boot from flash if the machine is only rebooted.
IMPORTANT! Assurez-vous d'éteindre complètement la machine, puis de la rallumer. L'image flash ne
démarrera pas si la machine n'est pas redémarrée.
WICHTIG! Schalten Sie das Gerät vollständig aus und wieder ein. Das Image startet nicht von Flash,
wenn der Computer nur neu gestartet wird.
11. Update the SC firmware on the card. Run the following command to update the SC firmware
on the card. It is the identical command used to flash the platform firmware on the card.
$ sudo /opt/xilinx/xrt/bin/xbmgmt program --base --device <management
BDF>
Where management BDF is the card requiring SC firmware update. See
Values to obtain the device management BDF.
UG1301 (v2.2) August 19, 2022
Getting Started with Alveo Accelerator Cards
Chapter 4: Installing the Deployment Software
Displaying Card BDF
Send Feedback
Chapter 7:
www.xilinx.com
21
