• Shell partition firmware (DFX-2RP platforms only)
$ sudo apt install ./xilinx-sc-fw-<version>.deb ./xilinx-cmc-
<cmc_version>.deb ./xilinx-u250-<base_version>.deb ./xilinx-u250-
<validate_version>.deb ./xilinx-u250-<shell_version>.deb
For additional details related to the deployment platforms for your Alveo card, see the Alveo
Data Center Accelerator Card Platforms User Guide (UG1120).
7. Flash the base partition to the Alveo card. After installing the deployment packages in the
previous step, the following message is displayed:
Partition package installed successfully.
Please flash card manually by running below command:
$ sudo /opt/xilinx/xrt/bin/xbmgmt flash --update --shell <base_name> --
card <card_bdf>
With XRT 2021.1 or greater, it is necessary to use the following new command to flash the
card rather than the one displayed in the above message. It assumes only one deployment
platform is installed on the card. If more than one platform is installed the --image option
needs to be added. See
IMPORTANT! If you have multiple cards installed in the system the following xbmgmt program
command must be ran separately for each card.
$ sudo /opt/xilinx/xrt/bin/xbmgmt program --base --device <management
BDF>
Where management BDF is the card to be programmed. See
obtain the device management BDF.
8. You will be asked to confirm the update, as follows. Type y and press the Enter key.
Actions to perform:
[0000:03:00.0] : Program base (FLASH) image
[0000:03:00.0] : Program Satellite Controller (SC) image
----------------------------------------------------
Are you sure you wish to proceed? [Y/n]: y
Flashing can take several minutes.
IMPORTANT! Do not enter Ctrl + c in the terminal while the firmware is flashing as this can cause the
card to become inoperable.
IMPORTANT! N'entrez pas Ctrl + c dans le terminal lorsque le micrologiciel clignote, car cela pourrait
rendre la carte inutilisable.
IMPORTANT! Geben Sie im Terminal nicht Strg + c ein, während die Firmware blinkt, da dies dazu
führen kann, dass die Karte nicht mehr funktioniert.
