Panasonic WH-ADF0309J3E5CM Service Manual

Table of Contents

Quick Links

Download this manual

This service information is designed for experienced repair technicians only and is not designed for use by the general public.

It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.

Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to

service or repair the products dealt with in this service information by anyone else could result in serious injury or death.

There are special components used in this equipment which are important for safety. These parts are marked by

Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that these critical parts should be

replaced with manufacturer's specified parts to prevent shock, fire or other hazards. Do not modify the original design without permission

of manufacturer.

In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigerant circuit.

R32 REFRIGERANT

– This Air Conditioner contains and operates with refrigerant R32.

THIS PRODUCT MUST ONLY BE INSTALLED OR SERVICED BY QUALIFIED PERSONNEL.

Refer to National, State, Territory and local legislation, regulations, codes, installation & operation manuals, before the installation,

maintenance and/or service of this product.

WH-ADF0309J3E5CM

WARNING

IMPORTANT SAFETY NOTICE

PRECAUTION OF LOW TEMPERATURE

CAUTION

Order No: PAPAMY2203084CE

Air Conditioner

Indoor Unit

CU-2WZ71YBE5

S-71WF3E

Outdoor Unit

Destination

Europe

in the Schematic

Table of Contents

Troubleshooting

Summary of Contents for Panasonic WH-ADF0309J3E5CM

Page 1 – This Air Conditioner contains and operates with refrigerant R32. THIS PRODUCT MUST ONLY BE INSTALLED OR SERVICED BY QUALIFIED PERSONNEL. Refer to National, State, Territory and local legislation, regulations, codes, installation & operation manuals, before the installation, maintenance and/or service of this product. © Panasonic Corporation 2022...
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE PAGE Safety Precautions ..........4 Operation Control (WH-ADF0309J3E5CM) .. ................. 174 Precaution for Using R32 Refrigerant ....8 14.1 Basic Function ......... 174 Specifications ........... 13 ...
Page 3 19.15 Compressor discharge high pressure 28.1 Outdoor Unit Removal Procedure .... 296 protection control ........217 Technical Data (WH-ADF0309J3E5CM) ..299 19.16 Compressor discharge high temperature protection control ........217 29.1 Operation Characteristics ......299 ...
Page 4: Safety Precautions
1. Safety Precautions  Read the following “SAFETY PRECAUTIONS” carefully before installation.  Electrical work must be installed by a licensed electrician. Be sure to use the correct rating of the power plug and main circuit for the model to be installed. ...
Page 5 WARNING Use the attached accessories parts and specified parts for installation. Otherwise, it will cause the set to fall, water leakage, fire or electrical shock. Install at a strong and firm location which is able to withstand weight of the set. If the strength is not enough or installation is not properly done, the set will drop and cause injury.
Page 6 WARNING When Wiring ELECTRICAL SHOCK CAN CAUSE SEVERE PERSONAL INJURY OR DEATH. ONLY A QUALIFIED, EXPERIENCED ELECTRICIAN SHOULD ATTEMPT TO WIRE THIS SYSTEM.  Do not supply power to the unit until all wiring and tubing are completed or reconnected and checked. ...
Page 7 …In laundry rooms Do not install in laundry rooms. Indoor unit is not drip proof. When Connecting Refrigerant Tubing Pay particular attention to refrigerant leakages. WARNING  When performing piping work, do not mix air except for specified refrigerant in refrigeration cycle. It causes capacity down, and risk of explosion and injury due to high tension inside the refrigerant cycle.
Page 8: Precaution For Using R32 Refrigerant
2. Precaution for Using R32 Refrigerant  Pay careful attention to the following precaution points and the installation work procedures. WARNING The appliance shall be stored, installed and operated in a well ventilated room with indoor floor area larger than A ) [refer Table A] and without any continuously operating ignition source.
Page 9 CAUTION General  Must ensure the installation of pipe-work shall be kept to a minimum. Avoid use dented pipe and do not allow acute bending.  Must ensure that pipe-work shall be protected from physical damage.  Must comply with national gas regulations, state municipal rules and legislation. Notify relevant authorities in accordance with all applicable regulations.
Page 10 CAUTION 2-9. Checks to the refrigerating equipment  Where electrical components are being changed, they shall be fit for the purpose and to the correct specification.  At all times the manufacturer’s maintenance and service guidelines shall be followed.  If in doubt consult the manufacturer’s technical department for assistance.
Page 11 CAUTION Detection of flammable refrigerants  Under no circumstances shall potential sources of ignition be used in the searching or detection of refrigerant leaks.  A halide torch (or any other detector using a naked flame) shall not be used. ...
Page 12 CAUTION Decommissioning  Before carrying out this procedure, it is essential that the technician is completely familiar with the equipment and all its details.  It is recommended good practice that all refrigerants are recovered safely.  Prior to the task being carried out, an oil and refrigerant sample shall be taken in case analysis is required prior to re-use of recovered refrigerant.
Page 13: Specifications
3. Specifications Item Unit WH-ADC0309J3E5CM EN 16147 Performance Test Condition EN 14825 Power Supply 1 : Phase (Ø) / Max. Current (A) / Max. Input Power (W) 1 / 21.6 / 4.9k Power Supply 2 : Phase (Ø) / Max. Current (A) / Max. Input Power (W) 1 / 13.0 / 3.00k Condition A7W35...
Page 14 Item Unit WH-ADC0309J3E5CM Protection Device Earth Leakage Circuit Breaker (30 ~ 40) Volume Expansion Vessel Capacity of Integrated Electric Heater / OLP TEMP kW / °C 3.00 / 80 Tank Volume (Spec / Nett) 200 / 185 Max. Tank Water Set Temperature °C Tank Coil Surface Space Heat...
Page 15 ITEM Unit S-71WF3E EN 14511 Performance Test Condition EN 14825 Remote Control *CZ-RTC4, *CZ-RTC5B, *CZ-RTC6 Series (Wired) (Optional part) 7.10 (1.20 ~ 8.10) Cooling Capacity (min. ~max.) BTU/h 24200 (4090 ~ 27600) Cooling EER 3.40 (2.55 ~ 2.47) 7.10 (2.00 ~ 10.20) Heating Capacity (min.
Page 16 Item Unit CU-2WZ71YBE5 EN14511 Performance Test Condition EN14825 7.10 Cooling Capacity BTU/h 24200 Cooling EER 3.40 Pdesign 7.10 SEER 5.60 ERP (Average Climate) Annual Consumption Class 7.10 Heating Capacity BTU/h 24200 Heating COP 3.90 Pdesign 4.80 Tbivalent °C ERP (Average Climate) SCOP 3.90 Annual Consumption...
Page 17 Brushless (4-poles) Rated Output 1.70 Type Propeller Fan Material Motor Type DC (8-poles) Input Power Output Power S-71WF3E WH-ADF0309J3E5CM Fan Speed Cooling: 660 Cooling: - Heating: 600 Heating: 650 Fin material Aluminium (Pre Coat) Fin Type Corrugated Fin Heat Exchanger Row ×...
Page 18 Item Unit Outdoor Unit Ø Single Power Source (Phase, Voltage, Cycle) Condition Cooling Heating Heat Recovery Input Power 2.09 1.82 3.15 Maximum Input Power For Heatpump System 4.90 Starting Current 10.1 Condition Cooling Heating Heat Recovery Running Current 10.1 15.0 Maximum Current For Heatpump System 21.6 Power Factor...
Page 19: Location Of Controls And Components
4. Location of Controls and Components Tank Unit 4.1.1 Remote Controller buttons and display Buttons / Indicator Quick Menu button (For more details, refer to the separate Quick Menu Guide.) Back button Returns to the previous screen LCD Display Main Menu button For function setup ON/OFF button Starts/Stops operation...
Page 20 Display Mode selection HEAT • HEAT operation is either turned TANK • TANK operation is either turned ON or OFF. ON or OFF. • The outdoor unit provides heat to • The outdoor unit provides heat to the system. the water tank. HEAT •...
Page 21 4.1.2 Initialization Before starting to install the various menu settings, please initiate the Remote Controller by selecting the language of operation and installing the date and time correctly. When power is turned on for the first time, it becomes the setting screen automatically. It can also be set from personal setting of the menu.
Page 22 4.1.3 Quick Menu After the initial settings have been completed, you can select a quick menu from the following options and edit the setting. 1 Press to display the quick menu. Force DHW Quiet Force Heater Weekly Timer Force Defrost Error Reset R/C Lock 2 Use...
Page 23 Menu Default Setting Setting Options / Display Holiday timer To save energy, a holiday period may be set to either turn OFF the system or lower the temperature during the period. Holiday start and end. Date and time OFF or lowered temperature •...
Page 24 Menu Default Setting Setting Options / Display 2 System check Energy monitor Historical chart Historical chart of energy consumption, generation. Select and retrieve • For historical chart, the period is selected from 1 day/1 week/1year. • Energy consumption (kWh) of total may be retrieved. •...
Page 25 Menu Default Setting Setting Options / Display Backlight Sets the duration of screen backlight. 1 min Backlight intensity Sets screen backlight brightness. Clock format Sets the type of clock display. Date & Time Sets the present date and time. Year / Month / Day / Hour / Min Language ENGLISH / FRANÇAIS / DEUTSCH / Sets the display language for...
Page 26 4.1.5 Menus (For installer) Menu Default Setting Setting Options / Display 5 Installer setup System setup Optional PCB connectivity To connect to the external PCB required for servicing. • If the external PCB is connected (optional), the system will have following additional functions: Buffer tank connection and control over its function and temperature.
Page 27 Menu Default Setting Setting Options / Display Buffer tank connection To connect tank to the system and if selected YES, to set T temperature. • The optional PCB connectivity must be selected YES to enable the function. Set T for Buffer •...
Page 28 Menu Default Setting Setting Options / Display Yes Auto To select a bivalent connection to allow an additional heat Set outdoor source such as a boiler to heat- temperature for up the buffer tank and domestic -5 °C turn ON Bivalent hot water tank when heatpump connection.
Page 29 Menu Default Setting Setting Options / Display Delay timer to stop the bivalent heat 0:30 source (in hour and minutes). Control pattern Advanced parallel DHW Yes • DHW Tank is activated only after selecting “Yes”. Delay timer to start the bivalent heat 0:30 source (in hour and minutes).
Page 30 Menu Default Setting Setting Options / Display Yes After selecting the tank T ON temperature Set T OFF 5 °C temperature Yes After selecting the tank T ON temperature T OFF temperature Set Antifreeze 5 °C temperature Yes After selecting the tank T ON temperature T OFF temperature After setting the antifreeze temperature...
Page 31 Menu Default Setting Setting Options / Display Force heater 5.15 To turn on Force heater either manually (by default) or automatically. Manual Defrost signal 5.16 To turn on defrost signal to stop fan coil during defrost operation. (If defrost signal set to yes, bivalent function will not available to use) Pump flowrate...
Page 32 Menu Default Setting Setting Options / Display 6 Installer setup Operation setup To access to the two major 2 main modes functions or modes. Heat / Tank Heat To set various water & ambient Water temp. for heating ON / temperatures for heating.
Page 33 Menu Default Setting Setting Options / Display Outdoor temp. for heating OFF Temperature for 24 °C heating OFF T for heating ON Set T for heating * This setting will not 5 °C available to set when pump flowrate set to Max.
Page 34 Menu Default Setting Setting Options / Display Tank Setting functions for the tank. Floor operation time (max) / Tank heat up time (max) / Tank re-heat temp. / Sterilization • The display will show 3 functions at a time. Floor operation time (max) Maximum time for 8:00 floor operation...
Page 35 Menu Default Setting Setting Options / Display Sterilization: Ope. time (max) Set sterilizing time 0:10 (in hours and minutes) Force DHW:Start Temp. Set auto Force DHW 35 °C activate temperature 7 Installer setup Service setup Pump maximum speed To set the maximum speed of Setting the flow rate, max.
Page 36 Menu Default Setting Setting Options / Display Service contact To set up to 2 contact names Service engineer’s name and contact number. and numbers for the User. Contact 1 / Contact 2 Contact 1 / Contact 2 Contact name or number. Name / phone icon Input name and number Contact name: alphabet a ~ z.
Page 37 4.1.6 Main Components Remote Controller Magnetic Water Filter Set Front Plate Water Pump Heater Assembly Top Plate Control Board Cover 3-Way Valve Right Plate Control Board Overload Protector (Not Visible) Left Plate Main PCB Expansion Vessel Rear Plate Single Phase RCCB/ELCB Air Purge Valve Tank Sensor (Not Visible) (Main Power)
Page 38: Dimensions
5. Dimensions WH-ADF0309J3E5CM Dimension Diagram Tube Position Diagram FRONT VIEW SIDE VIEW 75 100 Adjustable Feet position BOTTOM VIEW TOP VIEW Tube Connector Function Connector Size Water Inlet (From Space Heating) R 1¼" Water Outlet (To Space Heating) R 1¼"...
Page 39: S-71Wf3E
S-71WF3E Wired remote control (Optional) 1067 CZ-RTC4 1000 750=P150X5 Wired remote control (Optional) CZ-RTC5B Wired remote control (Optional) CZ-RTC6 Series Unit : mm...
Page 40: Cu-2Wz71Ybe5
CU-2WZ71YBE5 <Top View> 100 mm 100 mm 1000 mm Anchor Bolt Pitch 620 x 380.5 107.7 <Side View> <Front View> <Side View> 67.7 Unit: mm...
Page 41: Refrigeration Cycle Diagram
6. Refrigeration Cycle Diagram...
Page 42: Block Diagram
7. Block Diagram WH-ADF0309J3E5CM...
Page 43: S-71Wf3E
S-71WF3E FUSE...
Page 44: Cu-2Wz71Ybe5
CU-2WZ71YBE5...
Page 45: Wiring Connection Diagram
8. Wiring Connection Diagram WH-ADF0309J3E5CM EXTERNAL COMP. SW HEAT/COOL SWITCH SG SIGNAL SOLAR TEMP. SENSOR DEMAND SIGNAL WATER TEMP. ZONE 1 WATER TEMP. ZONE 2 POOL TEMP. SENSOR BUFFER TANK SENSOR ROOM TEMP. ZONE 1 ROOM TEMP. ZONE 2...
Page 46: S-71Wf3E
S-71WF3E CN069 (WHT) REACTOR REACTOR FUSE F301 T5.0A L250V NOISE RECTIFICATION FILTER CIRCUIT CN067 CIRCUIT ACIN (BLK) FAN MOTOR CN141 DCM (WHT) TERMINAL 1 2 3 CN309 ELECTRONIC BOARD NANOE-X (WHT) OP1 (YEL) (WHT) CONTROLLER CN076 GENERATOR (MAIN) NANO (WHT) HIGH VOLTAGE POWER SUPPLY TO OUTDOOR UNIT...
Page 47: Cu-2Wz71Ybe5
CU-2WZ71YBE5...
Page 48: Electronic Circuit Diagram
9. Electronic Circuit Diagram WH-ADF0309J3E5CM EXTERNAL COMP. SW HEAT/COOL SWITCH SG SIGNAL SOLAR TEMP. SENSOR DEMAND SIGNAL WATER TEMP. ZONE 1 WATER TEMP. ZONE 2 POOL TEMP. SENSOR BUFFER TANK SENSOR ROOM TEMP. ZONE 1 ROOM TEMP. ZONE 2...
Page 49: S-71Wf3E
S-71WF3E CN069 (WHT) REACTOR REACTOR FUSE F301 T5.0A L250V NOISE RECTIFICATION FILTER CIRCUIT CN067 *R149 CIRCUIT ACIN (BLK) FAN MOTOR 1.1k 1/4W Q041 CN141 B 10K PC003 *R155 TERMINAL 1 2 3 CN309 BOARD 3.3k OP1 (YEL) FB150 1/4W *R143 1/10W *R158 TO OUTDOOR UNIT...
Page 50: Cu-2Wz71Ybe5
CU-2WZ71YBE5...
Page 51: Printed Circuit Board
10. Printed Circuit Board 10.1 WH-ADF0309J3E5CM 10.1.1 Main Printed Circuit Board HT1-L3 CN-OLP1 AC2-N2 AC2-N3 AC2-L3 CN-PWR CN-PWR2 CN-PWR3 DATA AC1-N CN-PUMP1 AC1-L3 CN-FLWSEN CN-PWR4 CN-TH2 CN-TH1 CN-TH3 CN-CNT...
Page 52 10.1.2 Sub Printed Circuit Board (Optional) CN208 CN209 CN201 CN-205 CN-PWR204 CN202 CN-CNT CN204 CN-COMM CN-PWR202 CN207 CN203 CN206 CN210...
Page 53: S-71Wf3E
10.2 S-71WF3E 10.2.1 Main Printed Circuit Board CN073 CN073 CN074 CN081 CN601 Q081 C610 CN082 EXCT CN011 C609 R110 C047 C608 R109 CN032 C607 R181 Q067 R182 C606 FAN DRIVE R183 C125 R184 IC080 Q059 Q060 R185 IC008 D033 R186 CN066 R187 R092...
Page 54 10.2.2 nanoe X Printed Circuit Board...
Page 55: Cu-2Wz71Ybe5
10.3 CU-2WZ71YBE5 10.3.1 Main Printed Circuit Board CN-PSW1 CN-DISP1 CN-101 CN-102 CN-DISP2 CN-HOT2 CN-HOT1 CN-HT CN-STM1 CN-DATA1 CN-HPS CN-STM2 CN-TH3 CN-TH1 CN-STM3 CN-TANK CN-DISP3 CN-TH2 CN-DATA2 CN-TH4 CN-TH5 CN-FM1...
Page 56 10.3.2 Noise Filter Printed Circuit Board CN-COM CN-DATA CN-WHT CN-BLK 10.3.3 Display Printed Circuit Board CN-NMODE1 CN-DISP1...
Page 57: Installation Instruction (Wh-Adf0309J3E5Cm)
11. Installation Instruction (WH-ADF0309J3E5CM) 11.1 Indoor Floor Area Requirement  If the total refrigerant charge in the system is <1.84 kg, no additional minimum floor area is required.  If the total refrigerant charge in the system is ≥1.84 kg, additional minimum floor area requirements is...
Page 58 Table I - Maximum refrigerant charge allowed in a  For intermediate m values, the value that room corresponds to the higher m value from the table is considered. Maximum refrigerant charge in a room Example: ) (kg) If m = 1.85 kg, the value that corresponds to room H=1.64m...
Page 59 Attached accessories Optional Accessories Accessory part Qty. Accessory part Qty. Accessories part Qty. Adjustable Feet Remote Controller Optional PCB (CZ-NS4P) Cover Network Adaptor (CZ-TAW1) and Drain Elbow Extension Cable (CZ-TAW1-CBL) Packing Network Adaptor (CZ-TAW1) Field Supply Accessories (Optional) Part Model Specifications Maker Wired...
Page 60: Indoor Unit
11.2 Indoor Unit 11.2.1 Select the Best Location 11.2.1.2 Transport and Handling Before choosing the installation site, obtain user  Be careful during transportating the unit so that it approval. is not damaged by impact.  Install the Tank Unit in indoors with frost free ...
Page 61 This Tank Unit is designed for combination with 11.2.3.1 Water Quality Requirement Panasonic Multi Split Heat Pump Outdoor Unit. If Outdoor Unit from other manufacturer are being used in combination with Panasonic Tank Unit, optimum Must use water that complies with European water quality operation and reliability of the system is not standard 98/83 EC.
Page 62 Apply neutral cure  If non-brass metallic piping is used for installation, (Alkoxy type) and make sure to insulate the pipes to prevent ammonia-free silicone galvanic corrosion. sealant along the circumference  Do not connect galvanised pipes, this will cause galvanic corrosion.
Page 63 Model Rated Flow Rate (l/min) Tank Unit Outdoor Unit Heat Discharge below fixed grating 22.9 ADF0309J3E5CM 2WZ71YBE5 Fixed grating (B) Domestic Hot Water Tank Pipework  It’s strongly recommended to install an expansion Trapped gulley vessel (field supply) in the Domestic Hot Water Possible wall Illustration of guide Tank circuit.
Page 64 Please take extra precaution when open the control board cover ③ and control board ④ for unit installation and servicing. Failure to do so may cause injury. 11.2.4.1 Wiring System Diagram TANK UNIT (WH-ADF0309J3E5CM) Power Supply 2 RCCB/ELCB Single Phase (L1)
Page 65 3 x min 4.0 mm 30/40A 30mA, 2P, type S WH-ADF0309J3E5CM CU-2WZ71YBE5 3 x min 1.5 mm 30mA, 2P, type AC To avoid the cable and cord being damaged by sharp edges, the cable and cord must be passed through a bushing (located at the bottom of Control Board) before terminal board.
Page 66  For Space Heating 11.2.5 Charging and Discharging the Turn the plug on the Air Purge Valve ⑫ outlet Water anticlockwise by one complete turn from fully closed position.  Make sure all the piping installations are properly done before carry out below steps. Plug (turn anticlockwise by one complete turn)
Page 67 11.2.6 Reconfirmation 11.2.7 Installation of Remote Controller as Room Thermostat  Remote Controller ① mounted to the Tank Unit WARNING can be moved to the room and serve as Room Be sure to switch off all power supply before performing each Thermostat.
Page 68 11.2.7.3 Remove The Remote Controller For embedded type Preparation: Make 2 holes for screws using a driver. From Tank Unit Remove the top case from the bottom case. Mount the bottom case to the wall. Mount the top case. • •...
Page 69 Press from front to fix the Remote controller 11.2.8.2 Reset Overload Protector ⑩ □ cover 5 on the front plate. Overload Protector ⑩ a serves the safety purpose to prevent the water over heating. When the Overload Protector ⑩ a trip at high water temperature, take ⑯...
Page 70 11.2.9.2 Maintenance for Pressure Relief Valve ⑬  It is strongly recommended to operate the valve by turning the lever up & release it down a few times to ensure free water ﬂow through discharge hose at regular intervals to ensure it is not blocked and to remove lime deposit.
Page 71: Appendix
11.3 Appendix 11.3.1 Variation of System This section introduces variation of various systems using Air-To-Water Heatpump and actual setting method. 11.3.1.1 Introduce Application Related to Temperature Setting 11.3.1.1.1 Temperature Setting Variation for Heating 1. Remote Controller Indoor Setting of remote controller Installer setting Outdoor System setup...
Page 72 Connect floor heating or radiator directly to Tank Unit. Remote controller is installed on Tank Unit. Install separate external room thermistor (specified by Panasonic) in the room where floor heating is installed. This is an application that uses external room thermistor.
Page 73 Connect floor heating to 2 circuits through buffer tank as shown in the figure. Install mixing valves, pumps and thermistors (specified by Panasonic) on both circuits. Remove remote controller from Tank Unit, install it in one of the circuit and use it as Room Thermostat.
Page 74 Connects pool heat exchanger directly to Tank Unit without using buffer tank. Install pool pump and pool sensor (specified by Panasonic) at secondary side of the pool heat exchanger. Remove remote controller from Tank Unit and install in room where floor heating is installed.
Page 75 Built-in pump from Tank Unit served as a pump in zone 1. Install mixing valve, pump and thermistor (specified by Panasonic) on zone 2 circuit. Please be sure to assign high temperature side to zone 1 as temperature of zone 1 cannot be adjusted.
Page 76 (It must connect to buffer tank especially when select Advanced Parallel setting.) WARNING Panasonic is NOT responsible for incorrect or unsafe situation of the boiler system. CAUTION Make sure the boiler and its integration in the system complies with applicable legislation.
Page 77 11.3.2 How to Fix Cable 11.3.2.1 Connecting with External Device (Optional)  All connections shall follow to the local national wiring standard.  It is strongly recommended to use manufacturer-recommended parts and accessories for installation.  For connection to main PCB ⑤ Room thermostat cable must be (4 or 3 x min 0.5 mm ), of type designation 60245 IEC 57 or heavier cord, or similarly double insulation sheathed cable.
Page 78 □  For connection to Optional PCB By connecting Optional PCB, 2 Zone temperature control can be achieved. Please connect mixing valves, water pumps and thermistors in zone 1 and zone 2 to each terminals in Optional PCB. Temperature of each zone can be controlled independently by remote controller. Pump zone 1 and zone 2 cable shall be (2 x min 1.5 mm ), of type designation 60245 IEC 57 or heavier.
Page 79 11.3.2.2 Guide Optional Cables and Power Supply Cords to Bushings ■ D-1 and D-2 Bushings are for: CAUTION • • External control cable Water sensor zone 1 cable • • Remote controller cable Water sensor zone 2 cable Wire guiding shall be free from hot surfaces. •...
Page 80 11.3.2.4 Connection of the Main PCB Zone 1 room sensor External control Remote controller Boiler contact / Defrost Signal Extra pump C O N H C N L 3-way Optional Thermostat 1 valve  Signal inputs L N =AC230V, Heat, Cool=Thermostat heat, Cool terminal Optional Thermostat It does not function when using the Optional PCB Dry contact Open=not operate, Short=operate...
Page 81 Recommended External Device 6.523 0.186 Specification  8.044 0.236 This section explains about the external devices (optional) recommended by Panasonic. Please 9.980 0.302 always ensure to use the correct external device during system installation. 12.443 0.390  For optional sensor.
Page 82  2. Insert a flat head screwdriver into the slot on For optional mixing valve. the top of the adaptor and remove the cover. Power supply: AC230V/50Hz (input open/output Connect the other end of the CN-CNT cable close) connector to the connector inside the adaptor. Operating time: 30s~120s Recommended part: 167032: made by Caleffi Slot...
Page 83 11.3.3 System Installation 11.3.3.1 Remote Controller Outline Name Function A: Main screen Display information B: Menu Open/Close main menu C: Triangle (Move) Select or change item D: Operate Start/Stop operation E: Back Back to previous item F: Quick Menu Open/Close Quick menu G: OK Conﬁrm 12:00am,Mon...
Page 84 First time of power ON (Start of installation) Initialization 12:00am,Mon When power is ON, ﬁrstly initialization screen appears (10 sec) Initializing. 12:00am,Mon When initialization screen ends, it turns to normal screen. Start Language 12:00am,Mon ENGLISH When any button is pressed, language FRANÇAIS setting screen appears.
Page 85 11.3.3.2 Installer Setup System setup Optional PCB connectivity Yes/No Only when the selection for Optional PCB is Yes Zone & Sensor 1 Zone system / 2 Zone system Zone settings Heater capacity Capacity select Anti freezing Yes/No DHW Capacity Variable/Standard Only when the selection for Optional PCB is Yes Buffer Tank connection Yes/No...
Page 86 Compensation Operation setup Heat Water temp. for heating ON Compensation curve curve setup Direct Direct temp. setup Outdoor temp. for heating OFF Heating OFF Temp. setup ∆T for heating ON ∆T for heating setup Heater ON/OFF O/D temp for heater ON setup Heater ON Delay Time ∆T of target temperature for Heater ON ∆T of target temperature for Heater OFF...
Page 87 11.3.3.3 System Setup System setup 12:00am,Mon 1. Optional PCB connectivity Initial setting: No Optional PCB connectivity If function below is necessary, please purchase and install Optional PCB. Zone & Sensor Please select Yes after installing Optional PCB. Heater capacity • 2-zone control •...
Page 88 12:00am,Mon System setup 6. Buffer Tank connection Initial setting: No Heater capacity Select whether it is connected to buffer tank for heating or not. Anti freezing If buffer tank is used, please set Yes. Tank connection Connect buffer tank thermistor and set, ∆T (∆T use to increase primary side temp against secondary side target temp).
Page 89 Alternative mode Parallel mode operate boiler only operate heat pump only operate boiler and heat operate heat pump only pump simultaneously Outdoor temp. Outdoor temp. -10°C (setting from remote controller) -10°C (setting from remote controller) Advanced Parallel mode For heating For DHW tank operate boiler and heat operate heat pump only...
Page 90 System setup 12:00am,Mon 12. SG ready Initial setting: No Solar connection Switch operation of heat pump by open-short of 2 terminals. External error signal Setting belows are possible Demand control SG signal Working pattern Vcc-bit1 Vcc-bit2 SG ready Open Open Normal Short Open...
Page 91 System setup 12:00am,Mon 17. Pump flowrate Initial setting: ∆T Force heater If pump ﬂowrate setting is ∆T, unit adjust pump duty to get different of water inlet Force defrost and outlet base on setting on * ∆T for heating ON and * ∆T for cooling ON in Defrost signal operation setup menu during room side operation.
Page 92 23. Heater ON/OFF a. Outdoor temp. for heater ON Initial setting: 0°C Set outdoor temp when back-up heater starts to operate. Setting range is -20°C ~ 15°C 0°C User shall set whether to use or not to use heater. Heater ON b.
Page 93 27. Sterilization Initial setting: 65°C 10min ② Set timer to perform sterilization. ① Set operating day & time. (Weekly timer format) ② Sterilization temp (55~75°C If use back-up heater, it is 65°C) ③ Operation time (Time to run sterilization when it reached setting temp ① ③...
Page 94: Service And Maintenance
11.4 Service and Maintenance Custom menu If forget Password and cannot operate remote controller Setting method of Custom menu Press for 5 sec. Password unlock screen appears, press Conﬁrm and it shall Custom menu 12:00am,Mon reset. Password will become 0000. Please reset it again. Back-up heater (NOTE) Only display when it is locked by password.
Page 95: Installation Instruction (S-71Wf3E)
12. Installation Instruction (S-71WF3E) 12.1 Indoor Unit Installation 12.1.1 General This booklet briefly outlines where and how to install the air conditioning system. Please read over the entire set of instructions for the indoor and outdoor units and make sure all accessory parts listed are with the system before beginning.
Page 96 Part Name Figure Q’ty Remarks Operating Instructions Installation Instructions For vertical installation Short-circuit (Located on the back connection of the electrical component box lid.)  Use M10 for suspension bolts.  Field supply for suspension bolts and nuts. 12.1.1.3 Type of Copper Tube and Insulation Material If you wish to purchase these materials separately from a local source, you will need: 1.
Page 97 < Horizontal installation > 12.1.2 Selecting the Installation Site 12.1.2.1 Indoor Unit 20 mm AVOID: 350 mm  areas where leakage of flammable gas may be 650 mm expected.  250 mm places where large amounts of oil mist exist. 350 mm 20 mm * ...
Page 98 12.1.3 How to Install the Indoor Unit  Middle Static Pressure Duct Type (Type F3) 12.1.3.1 Required Minimum Space for Installation and Maintenance Services < Horizontal installation >  This air conditioner is usually installed above the ceiling so that the indoor unit and ducts are not visible. Only the air intake and air outlet ports are visible from below.
Page 99 Max. 10 Max. 10 Grille * Min. 650 Grille * Min. 250 Min. 20 Min. 300 Unit: mm * Make it possible to open / close for maintenance services.  It is recommended that space be provided (450 × 450 mm) for checking and servicing the electrical system. Detailed dimensions of indoor unit Unit: mm Type...
Page 100 12.1.3.2 Preparation Before Installation 12.1.3.2.1 Main Types of Installation Case A (Standard installation) Case B Horizontal installation in the ceiling, rear side air Horizontal installation in the ceiling, lower side air intake intake Rear side air intake Lower side air intake Case C Case D Vertical installation on the sidewall, lower side air...
Page 101 Case B and Case D are shown below. For Case B, replace the cover plates in the procedure shown in the figure. Type 71 1. Remove the cover plate. Cover plate 2. Attach the cover plate and the support plate removed in step 1 and filters (accessories) in the direction shown in the figure below.
Page 102 (3) Thread the 3 hexagonal nuts and 2 washers (field 12.1.3.3 Fix the Indoor Unit supply) onto each of the 4 suspension bolts. Use 1 nut and 1 washer for the upper part, and 2 nuts and 1 washer for the lower part, so that the unit 12.1.3.3.1 Horizontal Installation will not fall off the suspension lugs.
Page 103 12.1.3.3.2 Vertical Installation  To prevent overturning, fasten the unit to the wall securely.  Check to make sure the wall can endure 5 times of weight of the unit. Ensure to fix the unit.  In order to suppress vibrations, provide the spacer between the unit and the wall. ...
Page 104 Drain insulator (supplied) 12.1.3.4 Installing the Drain Pipe (1) Prepare standard hard PVC pipe (O.D. 26 mm) for Hose band (supplied) the drain and use the supplied hose band to prevent water leaks. Drain insulator (supplied) The PVC pipe must be purchased separately. The transparent drain part on the unit allows you to check drainage.
Page 105  12.1.3.4.2 Vertical Installation Replace the connectors  Replace the drain cap When installing the unit vertically, disconnect the connectors of the drain pump (3-pin) and the float switch (2-pin) from the PCB. Float switch Upper drain port connector (Not used) (2-pin) Drain pump connector (3-pin)
Page 106 How to make drain pump ineffective and changing 3. Select the “Code no.” by pressing the heating intake temperature button. Operating the High-spec Wired Remote Controller Change the “Code no.” to “3F” by pressing the (CZ-RTC5B) button (or keeping it pressed). Detailed settings 20:30 (THU) 20:30 (THU)
Page 107 Operating the Timer Remote Controller (CZ-RTC4) Setting Item Code “ ” and “ ” 1. Press and hold down the buttons simultaneously for 4 or more seconds. , the unit no., item code and detailed data will blink on the LCD display.) 2.
Page 108 Make sure the drain pipe has a downward gradient (1/100 or more) and that there are no water traps. CAUTION  Do not install an air bleeder as this may cause water to spray from the drain pipe outlet. Air bleeder Prohibited Upper drain port Downward slant :...
Page 109 12.1.3.5 Checking the Drainage 12.1.3.5.1 Horizontal Installation Only After wiring and drain piping are completed, use the following procedure to check that the water will drain smoothly. For this, prepare a bucket and wiping cloth to catch and wipe up spilled water. (1) Connect power to the power terminal board (L/1, N/2 terminals) inside the electrical component box.
Page 110 12.1.4 Electrical Wiring 12.1.4.1 General Precautions on Wiring (1) Before wiring, confirm the rated voltage of the unit as shown on its nameplate, then carry out the wiring closely following the wiring diagram. WARNING (2) This equipment is strongly recommended to be installed with Earth Leakage Circuit Breaker (ELCB) or Residual Current Device (RCD).
Page 111 12.1.4.2 Recommended Wire Length and Wire Diameter for Power Supply System The terminal block of the outdoor unit is as shown in the figure below. Wire the indoor unit to the terminal block of unit C. Connection cable between outdoor and indoor unit Indoor unit (Type of 3-line connection [1, 2 and 3 with indoor and outdoor units) Connection cable between outdoor and indoor unit...
Page 112 12.1.4.3 Wiring System Diagrams  Wiring System Diagram For Multi Split Indoor Unit * Single model connections Outdoor unit (single-phase) Indoor unit (Unit C) (Unit A) Remote controller Integrated control system Indoor unit wiring sample Earth wiring: Use this screw when connecting the shield Make the earth wiring 25 - 30 mm longer than for the Inter-unit control wiring to ground.
Page 113 After all of the wires are connected, close the lid of the electrical component box. ② Remote control wiring / Make the distance between two cables (① and ②) Integrated control wiring as shown in the figure to the right. ①...
Page 114 How to connect wiring to the terminal   For stranded wiring Examples of shield wires (1) Cut the wire end with cutting pliers, then strip the (1) Remove cable coat not to scratch braided shield. insulation to expose the stranded wiring about 10 mm and tightly twist the wire ends.
Page 115 12.1.5 How to Process Tubing Must ensure mechanical connections be accessible for maintenance purposes. 12.1.5.1 Connecting the Refrigerant Tubing Use of the Flaring Method Many of conventional split system air conditioners employ the flaring method to connect refrigerant tubes that run between indoor and outdoor units.
Page 116 12.1.5.2 Connecting Tubing Between Indoor and Outdoor Units (1) Tightly connect the indoor-side refrigerant tubing extended from the wall with the outdoor-side tubing. Indoor Unit Tubing Connection Unit : mm Indoor unit type S-71WF3E Gas tube Ø12.7 Liquid tube Ø6.35 (2) To fasten the flare nuts, apply specified torque.
Page 117 12.1.5.3 Insulating the Refrigerant Tubing Tubing Insulation Must ensure that pipe-work shall be protected from physical damage. Two tubes arranged together  Thermal insulation must be applied to all units tubing, including distribution joint (field supply). Liquid tube Gas tube * For gas tubing, the insulation material must be heat resistant to 120ºC or above.
Page 118 12.1.5.4 Taping the Tubes (1) At this time, the refrigerant tubes (and electrical wiring if local codes permit) should be taped together with armoring tape in 1 bundle. To prevent condensation from overflowing the drain Clamp pan, keep the drain hose separate from the Insulated tubes Drain hose refrigerant tubing.
Page 119 12.1.8 Test Run 12.1.8.1 Precautions  Request that the customer be present when the test run is performed. At this time, explain the operation manual and have the customer perform the actual steps.  Check that the 230 VAC power is not connected to the inter-unit control wiring connector terminal. * If 230 VAC is accidentally applied, the indoor unit control PCB fuse will blow in order to protect the PCB.
Page 120 12.1.8.3 Items to Check Before the Test Run (1) Turn the remote power switch ON at least 5 hours in advance in order to energize. (2) Fully open the closed valves on the liquid tubing and gas tubing sides. (3) Separate the power supply in accordance with the types of system. 12.1.8.4 Address Setting : 3-LINE CONNECTION The displays of the earth is omitted.
Page 121 12.1.8.5 Auto Address Setting Using the Remote Controller Auto Address Setting from the High-spec Wired Remote Controller (CZ-RTC5B) (1) Keep pressing the buttons simultaneously for 4 or more seconds. The “Maintenance func” screen appears on the 20:30 (THU) LCD display. (2) Press the button to see each menu.
Page 122 12.1.8.6 Checking the Indoor Unit Addresses Use the remote controller to check the indoor unit address. CZ-RTC5B (High-spec wired remote controller) (1) Keep pressing the buttons simultaneously for 4 or more seconds. 20:30 (THU) The “Maintenance func” screen appears on the LCD display.
Page 123 CZ-RTC4 (Timer remote controller) <If 1 indoor unit is connected to 1 remote controller> Number changes to indicate which (1) Press and hold the button and button indoor unit is currently selected. for 4 seconds or longer (simple settings mode). (2) The address is displayed for the indoor unit that is connected to the remote controller.
Page 124 (3) Press the button. “TEST” will be displayed (4) Press the button. Test run will be started. on the LCD display. Test run setting mode screen appears on the LCD display. 20:30 (THU) 20:30 (THU) TEST TEST MODE FAN SPEED COOL FLAP CZ-RTC4 (Timer remote controller)
Page 125 12.1.9 Checklist after Installation Work Work List Content Possibility of Failure & Checkpoint Check Are the indoor units installed following the There is a possibility of light injure or loss of Installation content of the section “12.1.2. SELECTING property. THE INSTALLATION SITE”? Is the earth leakage circuit breaker (all-pole switching function provided) installed? Is there any wrong installation of optional parts...
Page 126 12.1.10 External Static Pressure Setting For middle static pressure duct type indoor units, the ventilating resistance so-called “external static pressure” becomes greatly different depending on the connected duct length, shape, number of air outlet ports and types of filters. When installing this unit, be sure to carry out the external static pressure setting in order to operate in the rated airflow volume.
Page 127 Flow of External Static Pressure Start external static pressure Finish the ducting and electrical wiring and prepare it for use. (Note (1)) setting External static pressure should be set during initial operations after installation (before the cooling and heating test run). Line A (set at shipment) on the PQ diagram was designed and installed.
Page 128 2) If multiple air outlets and air inlets are included, adjust the airflow volume ratio of all of them until they meet the design airflow ratio. 3) Make sure the address setting has been completed. (2) The operation check will be completed in approximately three minutes if the settings have been made correctly. The settings will be modified if they are out of the range of use (maximum 30 minutes).
Page 129 12.1.10.1 How to Set on Indoor Unit Control PCB 1. Turn off the power breaker to halt the supply of electricity to the indoor unit control PCB. 2. Open the electrical component box cover, then check the indoor unit control PCB. (Fig. 10-1) 3.
Page 130 3. Select the “Code no.” by pressing the 12.1.10.2 Operating the High-spec Wired Remote Controller (CZ-RTC5B) button. Change the “Code no.” to “B0” by pressing the button (or keeping it pressed). 20:30 (THU) Detailed settings 20:30 (THU) Unit no. Code no. Set data START -001...
Page 131 Change the display from “OFF” to “ON” by 5. Select the “Unit no.” by pressing the pressing the button. Then press button and press the button. The “Exit detailed settings and restart?” button. (Detailed setting-end) screen appears on the LCD display.
Page 132 The fan motor will be activated, the auto external 3. Specify the “ ” item code by pressing the static pressure setting operation and setting-check buttons for the temperature setting buttons operation will be performed for about 3 to 30 and confirm the values.
Page 133 5. Press the button to halt the test run. ° ° * Failure to set this parameter may result in 2, 5 decreased airﬂow and condensation. 12.1.10.3.2 Auto Airflow Volume Control Operations and External Static Pressure Setting-Check Operation 1. Press and hold down the button for 4 or more seconds.
Page 134  After Cleaning 12.1.11 Appendix 1. After the air ﬁlter is cleaned, reinstall it in its  original position. Care and Cleaning Be sure to reinstall in reverse order. 2. [In the case of Timer Remote Controller] WARNING Press the Filter reset button. (Filter) indicator on the display goes ...
Page 135 <How to remove the filter> Remove the filter in reverse order of the section “12.1.3.2.2. Install the Filter”.  In case of Installing the Duct (field supply) Type Period (Depends on filter’s specifications) When cleaning the air filter, consult your dealer or service center. CAUTION ...
Page 136  Troubleshooting If your air conditioner does not work properly, first check the following points before requesting service. If it still does not work properly, contact your dealer or a service center.  Indoor unit Symptom Cause Noise Sound like streaming water during ...
Page 137  Check Before Requiring Services Symptom Cause Remedy Air conditioner does not run at all Power failure or after power failure Press ON/OFF operation button on remote although power is turned on. controller again. Operation button is turned off.  Switch on power if breaker is turned off. ...
Page 138 12.1.12 Indoor Floor Area Requirement The refrigerant (R32), which is used in the air conditioner, is a flammable refrigerant. So the requirements for installation space of appliance are determined according to the refrigerant charge amount [m ] used in the appliance. Regarding the refrigerant charge amount [m ] used in the appliance, refer to the installation instructions for the outdoor unit.
Page 139 Table II – Minimum floor area Minimum floor area (Amin) m Minimum floor area (Amin) m ] kg ] kg H=0.6m H=1.8m H=2.0m H=2.2m H=0.6m H=1.8m H=2.0m H=2.2m 1.84 28.81 4.44 4.00 3.63 2.54 54.91 6.13 5.52 5.01 1.86 29.44 4.49 4.04 3.67...
Page 140 SUPPLEMENT Contents of Remote Controller Switch Alarm Display Blinking: OFF: Wireless remote controller receiver display Abnormal Alarm contents Error location display  Replace the remote controller Faulty remote controller Disconnection / Contact failure of remote  Correct the remote controller wiring controller wiring CHK (check) pins on the indoor unit control ...
Page 141 Blinking: OFF: Wireless remote controller receiver display Abnormal Alarm contents Error location display Operating and timer lamp blinking  Check the indoor unit EEPROM Indoor unit EEPROM trouble simultaneously  Check the indoor unit control PCB  Address re-setting after correcting the Setting error, indoor / outdoor unit type / model miss-matched combination of units...
Page 142 Blinking: OFF: Wireless remote controller receiver display Abnormal Alarm contents Error location display  Check the inter-unit control wiring  Check the indoor and outdoor unit control The total capacity of indoor units are too low  Address re-setting after correcting the Automatic combination of units address...
Page 143 Blinking: OFF: Wireless remote controller receiver display Abnormal Alarm contents Error location display  Check the inter-unit control wiring Duplication of outdoor unit address  Replace the outdoor unit EEPROM Outdoor unit capacity is not set or setting error  Capacity value re-setting ...
Page 144: Wired Remote Control Installation (Optional Part)
12.2 Wired Remote Control Installation (Optional Part) 12.2.1 CZ-RTC4 12.2.1.1 Supplied Accessories Screw M3.8 x 16 Operating Instructions Quick Reference *Remote control wiring is not supplied. (field supplied item) 12.2.1.2 Dimensions 12.2.1.3 Installation Location  Install at the height of 1 to 1.5 m from the floor (Location where average room temperature can be detected).
Page 145 12.2.1.4 Remote Control Wiring  Wiring diagram  Type of wiring Use cables of 0.5 to 1.25 mm  Total wire length: 500 m or less (The wire length between indoor units should be 200 m or less.)  Number of connectable units Remote controller: Max.
Page 146 12.2.1.5 Mounting 1. Remove the bottom case. Insert the driver and slightly turn. *Do not insert the screw driver too deep. Doing so may cause the claw to be broken. Attention  Mounting the bottom case Tighten the screws securely until the screw heads touch the bottom case. (Otherwise, loose screw heads may hit the PCB and cause malfunction when mounting the top case.) Do not over-tighten the screws.
Page 147 2. Mount to the wall.  Exposed type Top case Bottom case (Back side) (Back side) Claw (2 places) Terminal board 150 mm Hole for screw Claw (2 places) Screw (supplied) 6 mm ① Make 2 holes for screws using a driver. ②...
Page 148 12.2.1.6 Setting / Test Operation Setting Test operation  Turn on the circuit breaker beforehand, referring to the Clock operating instructions for the unit. The remote  RC. setting mode (Main/sub, Clock type) controller starts.  Detailed setting mode (Ventilation fan output setting, Room temperature sensor, Temperature 1.
Page 149 12.2.2 CZ-RTC5B 12.2.2.1 Supplied Accessories Screw Instructions Quick Clamper M3.8 x 16 Reference *Remote control wiring is not supplied. (field supplied item) 12.2.2.2 Dimensions 5-5x9 (mm) 12.2.2.3 Installation Precautions 12.2.2.3.1 Installation Location 5 mm or more  Install at the height of 1 to 1.5 m from the floor (Location where average room temperature can be detected).
Page 150 12.2.2.3.2 Remote Control Wiring  Wiring diagram Indoor unit RC wiring (field supply) • No polarity Terminals for RC wiring  Type of wiring Use cables of 0.5 to 1.25 mm  Total wire length: 500 m or less (The wire length between indoor units should be 200 m or less.) ...
Page 151 12.2.2.4 Mounting 1. Remove the bottom case. Attention  Mounting the bottom case Tighten the screws securely until the screw heads touch the bottom case. (Otherwise, loose screw heads may hit the PCB and cause malfunction when mounting the top case.) Do not over-tighten the screws.
Page 152  Embedded type Preparation: Make 2 holes for screws using a driver. Mount the top case. Mount the bottom case to the wall.  Align the claws of the top  Pass the wire through the hole in the centre case and then align the of the bottom case.
Page 153 12.2.2.5 Setting Preparation: Turn on the circuit breaker of units and then turn the power on. The remote controller starts, and wait until the [Assigning] display disappears. (If [Assigning] continues to blink for 10 minutes or more, check the address setting of indoor units.) Note To return to the previous screen Press...
Page 154 ■ Press and hold the 3 buttons for 4 seconds or more simultaneously. , ► Select the item to set. ▲ ▼ → Service contact Select. (Name) ▲ ▼ → Name Contact number ▲ ▼ ◄ ► → (Repeat the same procedure for all characters.) •...
Page 155 ■ RC. setting mode ■ Detailed settings ■ Auto address ■ Set elec. consumption Press and hold the 3 buttons for 4 seconds or more simultaneously. , ► Select the item to set. ▲ ▼ → RC. setting mode Set. (Select the Code no.
Page 156 Auto address Set. (Select the Code no. [A1] and O/D unit no.) ▲ ▼ → ► → (Repeat) Press Code no. O/D unit no. ● After Selecting [YES], the unit restarts. Code no. O/D unit no. Set the Auto address for each O/D unit no. ●...
Page 157 12.2.2.6 Confirming Information ■ Sensor info. ■ Service check Press and hold the 3 buttons for 4 seconds or more simultaneously. , ► Select the item to set. ▲ ▼ → Sensor info. This displays each sensor temperature of the remote controller, indoor units. Select.
Page 158 12.2.2.7 Test Operation Press and hold the 3 buttons for 4 seconds or more simultaneously. , ► Select [Test run]. ▲ ▼ → Select [ON]. (The unit enters the test operation mode. Then, [TEST] turns on.) ▲ ▼ → Press Perform the test operation.
Page 159 12.2.3 CZ-RTC6 Series 12.2.3.1 Installation Location  Install at the height of 1 to 1.5 m from the floor (Location where average room temperature can be detected).  Install vertically against a wall or suitable supporting structure.  Keep a space around the remote controller as detailed on the figure shown left.
Page 160 Wiring as shown below is prohibited. R1 R2 R1 R2 R1 R2 When setting both the main and sub remote controllers Regarding the contents of the installation, please scan the matrix two-dimensional (2D) barcode and refer to the detailed manuals. After installation, set one remote controller to [Main] and the other to [Sub] for [Main/sub] for “Setting”.
Page 161 2. Mount to the wall. There are 2 types of wall-mounting methods: Exposed type and Embedded type. Attention Mounting the bottom case  Tighten the screws securely until the screw heads touch the bottom case. (Otherwise, loose screw heads may hit the PCB and cause malfunction when mounting the top case.) ...
Page 162 12.2.3.5 Embedded Type A protective film is attached on the Control panel.
Page 163: Operation Instructions
12.3 Operation Instructions 12.3.1 Wired Remote Control (Optional part) Operation indicator Illuminates during operation. Blinks during alarm. Start/Stop button Starts/Stops operation. Fan speed Changing the fan speed. Swing/Air direction Use this button to set the auto swing or air direction to a specific angle. Unit select When more than one indoor unit is operated by one remote control unit, this button is used to select a unit when adjusting the air direction.
Page 164 12.3.1.1 CZ-RTC5B LCD screen Menu button Displays the menu Return button 20:30 screen. Returns to the previous screen. Cross key buttons Selects an item. Enter button (◄Left / ▼Down / ►Right / ▲Up) Fixes the selected content. Start/Stop button Energy saving Starts/Stops operation.
Page 165: Installation Instruction (Cu-2Wz71Ybe5)
13. Installation Instruction (CU-2WZ71YBE5) 13.1 Installation Information 13.1.1 Check Points 30A switch (circuit breaker, Outdoor unit power supply: included in tank unit) Single-phase 230V, 50Hz Power supply cable from tank unit to outdoor unit (Port A) 4.0mm or more × 3 core 4.0mm or more ×...
Page 166: Select The Best Location
13.2 Select The Best Location 13.2.1 Outdoor Unit  If an awning is built over the unit to prevent direct Installation parts you should purchase ( ) sunlight or rain, be careful that heat radiation from Outdoor Unit Installation Diagram the condenser is not obstructed.
Page 167: Install The Outdoor Unit
Outdoor unit located Outdoor unit located otherwise on upper side Outdoor unit Outdoor unit Outdoor unit -Indoor unit (Tank or Duct unit) Outdoor Unit Installation Guidelines  Where a wall or other obstacle is in the path of outdoor unit’s intake or exhaust airflow, follow the installation guidelines below.
Page 168 Spanner or Wrench Torque wrench Be sure to use two spanners to tighten. (If the nuts are overtightened, it may cause the ﬂares to break or leak.) Piping connection A for Tank unit Piping connection C for Duct unit...
Page 169: Air Tightness Test On The Refrigerating System
AIR PURGING METHOD IS PROHIBITED FOR R32 SYSTEM 13.5 Air Tightness Test on the Refrigerating System Do not purge the air with refrigerants but use a vacuum pump to vacuum the installation. There is no extra refrigerant in the outdoor unit for air purging. Air evacuation and tightness test shall be carried out separately for Tank unit and Duct unit piping connection with respective 3-way valve (shown below).
Page 170  Before system is charged with refrigerant and before the refrigerating system is put into operation, below site test procedure and acceptance criteria shall be veriﬁed by the certiﬁed technicians, and/or the installer.  Be sure to check whole system for gas leakage. Connect a charging hose with a push pin to the Low side of a charging set and the service port of the 3-way valve.
Page 171: Connect The Cable To The Outdoor Unit
13.6 Connect The Cable To The Outdoor Unit 1. Remove the Particular plate from the unit by loosening the two screws. 2. Connecting cable between all units shall be approved polychloroprene sheathed ﬂexible cable, Cable clamper type designation 60245 IEC 57 or heavier cable. Other detail shall refer to table below: Screws Cable Connection...
Page 172: Heat Insulation
13.7 Heat Insulation 1. Please carry out insulation at pipe connection portion as mentioned in Indoor/Outdoor Unit Installation Diagram. Please wrap the insulated piping end to prevent water from going inside the piping. 2. If drain hose or connecting piping is in the room (where dew may form), please increase the insulation by using POLY-E FOAM with thickness 6 mm or above.
Page 173 13.7.3 Cooling only Operation  Setting of Cooling only operation (Duct unit). The Duct unit can be set to cooling only operation by setting the JP line on the outdoor unit display circuit board. [Setting method] Switch off power supply to the outdoor unit, cut JP1 (COOL ONLY) as shown in Figure 1. After cut off the wire, switch ON the equipment power.
Page 174: Operation Control (Wh-Adf0309J3E5Cm)
14. Operation Control (WH-ADF0309J3E5CM) 14.1 Basic Function Inverter control, which equipped with a microcomputer in determining the most suitable operating mode as time passes, automatically adjusts output power for maximum comfort always. In order to achieve the suitable operating mode, the microcomputer maintains the set temperature by measuring the temperature of the environment and performing temperature shifting.
Page 175 14.1.3 Target Water Temperature Setting 14.1.3.1 Target Water Temperature Control of Standard System (Optional PCB not connected) There are 2 types of temperature control selection which are Compensation and Direct.  Temperature control type selection by installer: 1. Compensation : Wlo, WHi, ODLo, ODHi can be set at installer menu. 2.
Page 176  Outdoor ambient is updated every 5 minutes when operation ON.  Setting water outlet temperature always follow W or W whenever is higher if outdoor ambient sensor or (LO) (HI) indoor communication error happen.  Compensation curve set shift value: Tw_Hi Tw_Lo Shift value...
Page 177 14.1.5 Target Zone Water Temperature Control Purpose:- To control zone mixing and zone pump according to the zone sensor temperature 14.1.5.1 Target Zone 1 water temperature setting control  Start condition Heating zone 1 is ON by remote control or Timer. ...
Page 178 14.1.5.2 Target Zone 2 water temperature setting control  Start condition Heating zone 2 is ON by remote control or Timer.  Cancel condition Heating zone 2 is OFF by remote control or Timer.  Target Zone 2 water temperature is calculated as below condition. Target Zone 2 water temperature = A (Base temperature) + B (shift temperature) Compensation Direct...
Page 179 14.1.5.3 Zone Temperature Control Contents  During Standard System (Optional PCB not connected) Only 1 zone temperature control is available This zone room temperature is control by either one of the 4 room sensor (Room Th, Int/Ext Room Thermostat, Water temperature) Target Zone Water Temperature is calculated based on selected temperature control type (Compensation or Direct) and selected room sensor.
Page 180 14.1.6 Tank Mode Operation  3 ways valve direction 3 ways valve switch to tank side during Tank Thermo ON condition. Switch 3 ways valve to room side when tank achieve Tank Thermo OFF temperature.  Tank Thermo ON/OFF Characteristic Tank Thermo OFF Case 1: Internal Tank Heater is select and Tank Heater ON Tank temperature >...
Page 181 Thermo ON/OFF for Heat Pump in Tank Operation: When tank temperature achieve heat pump OFF condition, refer below condition: Conditon 1 : Tank Heater ON (Internal Tank Heater)  Heat pump will turn OFF, water pump continue ON and room heater will continue ON if tank temperature below tank heater thermo ON condition.
Page 182: Water Pump
During Tank heat-up interval Tank interval is the first mode running when heat + tank mode is select.  Switch to room interval only when tank achieve tank thermo OFF OR tank heat-up interval timer is  complete. Heat pump operates according to normal tank mode operation. ...
Page 183 2) When pump flowrate setting is Max. Duty Indoor water pump speed will operate at the maximum pump speed setting at room side operation. The maximum pump speed setting can be adjusted by the installer according to water circuit pressure drop condition. However, the following sequences do not follow maximum pump duty setting by remote control.
Page 184  Zone 1 and Zone 2 water pump start condition: Zone room request ON (eg. Zone 1 thermo ON, only zone 1 pump will turn ON)  Zone 1 and Zone 2 water pump stop condition: Zone room request OFF ...
Page 185: Indoor Unit Safety
14.3 Indoor Unit Safety 14.3.1 Indoor Unit Safety Control 1. When water pump is ON, the system will start checking flow switch status (ON/OFF). 2. If the flow switch ON for 10 seconds, the system will check on the water inlet temperature for 10 seconds. If the water inlet temperature not exceeds 80°C, the water pump shall be continuously running with normal mode.
Page 186: Indoor Back-Up Heater Control
14.6 Indoor Back-Up Heater Control 14.6.1 Indoor Electric Heater Control 1. Normal Heating Mode Heater On condition: a. Heater switch is ON b. After Heatpump thermo ON for Remote Control Set Delay Time mins c. After water pump operate [3] mins d.
Page 187 14.6.2 Room Heater Operation during Deice Purpose:  To protect the indoor Heat Exchanger from ice forming and prevent heat exchanger plate breakage. Control content:  This Heater protection control will activate only if the backup heater is enable at custom setup by remote controller.
Page 188: Tank Heater Control
14.7 Tank Heater Control 14.7.1 Tank Heater Remote Control Setting Tank heater selection: Internal: - Backup Heater use to heat up tank when select internal Heater Delay ON Timer need to set. (range 20 min ~ 3 hrs) Tank Heater ON/OFF selection by user. The remote control Tank set Temperature range will change according to the External and Internal Tank Heater use.
Page 189: Force Heater Mode
14.8 Force Heater Mode Purpose of Force Heater Mode:  As a backup heat source when heat pump error. Force heater Mode only control backup heater to heat up the room circuit, and turn ON back up heater or booster heater to boil up tank water base on the tank heater selection (internal or external).
Page 190: Quiet Operation
Tank side (Tank mode):  When tank mode select and force heater bit received, turn ON backup heater (INTERNAL) or Booster Heater (External) depend on the tank heater selection.  If tank heater selection is INTERNAL, follow normal thermo judgement to switch 3 ways valve to tank side and room side.
Page 191: Outdoor Ambient Thermo Off Control
 Control content: During sterilization function activation time, target tank set temperature will internally change to boiling set temperature. During sterilization activates, heat pump and heater (external or internal) will operate as normal tank mode to achieve the boiling set temperature. Sterilization operation will end when stop condition is fulfill.
Page 192: Smart Dhw Mode
14.13 SMART DHW mode Panasonic All In One model provide the option to choose STANDARD DHW Mode or SMART DHW Mode for Tank Heat Up according to requirement. SMART DHW mode comparatively consume lower tank heat up power but longer re-heat time than STANDARD DHW Mode.
Page 193: Anti Freeze Control
14.15 Anti Freeze Control  Anti freeze protection control menu can be set YES or NO by control panel.  In heatpump system, there are 3 types of anti freeze control: 1. Expansion tank anti-freeze control  Expansion tank anti freeze heater ON condition: Outdoor ambient temp.
Page 194: Solar Operation (Optional)
14.16 Solar Operation (Optional) 14.16.1 Solar Operation: Solar function:  This function allow user to control the solar pump to operate depend on the solar sensor reading compare to the tank installed. Solar pump will circulate the hot water energy store at solar panel to heat up the DHW Tank or Buffer Tank.
Page 195: Boiler Bivalent Control
14.16.2 Solar Operation Control  Solar function can only be activate if the solar function selection “YES” from remote control. To achieve hot water from solar panel, indoor need to control the solar pump and circulate hot water from solar panel. Under normal case: Solar pump start condition: ...
Page 196  Parallel Mode Parallel mode allows heat pump and boiler ON at the same time. Boiler operates as an additional heating capacity when low heat pump capacity at low ambient condition. Control detail: During operation ON at Heat mode or Tank mode or Heat + Tank mode Boiler signal turns ON when: ...
Page 197: External Room Thermostat Control (Optional)
Boiler signal turns OFF when  Outdoor ambient > Outdoor Ambient Set + [2°C] OR  Heat pump not operates at tank side. OR  Boiler prohibit flag = 1 Boiler prohibit flag control Purpose: For product safety. Boiler signal is OFF when water temperature is too high. Start condition: Water outlet ≥...
Page 198: Three Ways Valve Control
Indoor Unit L (label) Siemen RAA20 Cooling Y1 (label) Heating Y2 (label) 9 : Terminal Board No. Connect only heating line for heating only model. And connect both heating and cooling line for heat + cool model. Control Content:  External room thermostat control activate only when remote thermostat connection select YES by Indoor control panel.
Page 199: External Off/On Control
14.20 External OFF/ON Control  Communication circuit between indoor unit and external controller is as per below. External Controller mico Panasonic CN-THERMO  Maximum length of communication cable is 50 meter.  Control content: External Control Switch Control Panel OFF/ON...
Page 200: External Compressor Switch (Optional Pcb)
14.21 External Compressor Switch (Optional PCB) External compressor switch port can have two purpose of control as below:  Heat source ON/OFF function (Dip switch Pin 3 on PCB "OFF")  Heater ON/OFF function (Dip switch Pin 3 on PCB "ON") ...
Page 201: Sg Ready Control (Optional Pcb)
14.22 SG Ready Control (Optional PCB) Purpose:  To set ON/OFF of heat pump and target temperature by digital input of third party device if necessary in field. Optional PCB Remote Station + DI2 Com + DI1 Com - Com Remote control setting For this function, following items need to be set on Remote Control (installer menu) –...
Page 202: Holiday Mode
DHW Tank side New Tank Set Temperature = Tank Set Temperature * Remote Control setting for DHW ("Capacity 1) % * (Max regulation depend on the tank max setting limit) If Buffer selection is “NO” Room side New Target Zone Water Temperature = Current Target Zone Water Temperature * Remote Control Setting (*Capacity 1) % (Zone 1 and Zone 2 will change according to its own target zone water temperature.) (Max regulation depend on the temperature control type select)
Page 203: Dry Concrete
After days of holiday have been set, heat pump will stop and only resume operation at the end of holiday countdown.  Start condition: Holiday timer set and the holiday timer start * The day holiday mode was set is counted as day 1. ...
Page 204: Operation Control (S-71Wf3E)
15. Operation Control (S-71WF3E) 15.1 Cooling Operation  Cooling operation can be set using remote control.  This operation is applied to cool down the room temperature reaches the setting temperature set on the remote control.  Cooling Operation Time Diagram. OFF/ON switch Thermostat between OFF/ON >...
Page 205: Fan Operation
15.3 Fan Operation  Fan operation can be set using remote control.  The indoor fan is operated according to remote control setting and to enables air circulation in the room. 15.4 Thermostat Control  Depending on differences between room temperature, setting temperature and outdoor temperature, compressor operation is decided and starts operation.
Page 206: Nanoe Tmx Operation
15.5 nanoe X Operation  Generate nanoe X (water wrapped ion particle) to moisturize skin, provide deodorization & sterilization effect.  nanoe X operation start condition During unit running at any operation mode, if nanoe X operation is activated, combination operation (operation mode + nanoe X operation) starts.
Page 207: Operation Control (Cu-2Wz71Ybe5)
16. Operation Control (CU-2WZ71YBE5) 16.1 Cooling Operation 16.1.1 Outdoor fan control  When cooling operation is enabled, based on outdoor ambient temperature, fan motor control will be adjusted according to figure below: RPM free 15°C 13°C RPM controlled -12°C Stopped OD temp.
Page 208 16.1.3 Outdoor Cooling Quiet Operation Control  Purpose Provide quiet cooling operation when only 1 indoor in operation.  Start Condition Indoor fan speed is lower than Lo fan. Only 1 operation indoor unit. Not in any cooling overload zone. Not during annual cooling Not initial frequency operation.
Page 209: Heating Operation (Room Heating / Tank Heating)
16.2 Heating Operation (Room Heating / Tank Heating) 16.2.1 Outdoor fan control  When heating operation is enabled, based on outdoor ambient temperature, fan motor control will be adjusted according to figure below for Heating overload control: 16.2.2 Powerful Operation 2 ...
Page 210: Simultaneous Operation Control
17. Simultaneous Operation Control 17.1 Simultaneous Operation (Multiple Indoor Units)  Operation modes which can be selected using the remote control unit: Automatic, Cooling, Dry, Heating and nanoe operation mode.  Types of operation modes which can be performed simultaneously Cooling operation and Cooling, Dry or nanoe operation.
Page 211: Simultaneous Operation (Indoor Unit + Tank Unit)
17.2 Simultaneous Operation (Indoor Unit + Tank Unit) Category Room Tank Mode Cooling Cooling Cooling Cooling Heating Heat Recovery Heating Heating Heating Heating Tank Heating Heating Heating Bi-Heating When different combination of operation setting is set at indoor unit and tank unit, different mode is carried out. 17.2.1 Heat Recovery Mode This mode is to utilise the waste energy to heat up the tank unit, instead of wasted to outdoor ambient.
Page 212: Protection Control (Wh-Adf0309J3E5Cm)
18. Protection Control (WH-ADF0309J3E5CM) 18.1 Protection Control for Heating Operation 18.1.1 Force Defrost Operation Force defrost can be set through remote control.  If force defrost request from quick menu of remote control, outdoor will run force defrost at heat mode if fulfilled...
Page 213: Protection Control (Cu-2Wz71Ybe5)
19. Protection Control (CU-2WZ71YBE5) 19.1 Freeze Prevention control (Cool)  When received freeze prevention signal from indoor unit, the compressor frequency changes according to indoor heat exchanger temperature.  When indoor unit request capability OFF due to freeze condition, immediately the capability supply to targeted indoor unit stops.
Page 214: Cooling Overload Control (Cool)
19.4 Cooling overload control (Cool)  This control detect compressor discharge pressure and perform the compressor frequency restriction during cooling operation. Comp stop 40.0kgf/cm Comp freq restricted 37.0kgf/cm 35.0kgf/cm Comp freq free High Pressure * The high pressure value may be lower by 0 ~ 6kgf/cm .
Page 215: Deice Control
19.7 Deice Control  When outdoor pipe temperature and outdoor air temperature is low, deice operation starts where indoor fan motor and outdoor fan motor stop, indoor unit horizontal vane close and operation LED blink with compressor ON. 19.8 Time Delay Safety Control (Restart Control) ...
Page 216: Ipm (Power Transistor) Protection Control
19.11 IPM (power transistor) Protection Control  Overheating Prevention Control If IPM temperature rises to 80°C, outdoor fan speed will be increased. When the IPM temperature rises to 95°C, compressor operation will stop immediately. Compressor operation restarts when temperature decreases to 90°C. If IPM temperature detected less than -30°C, IPM is judged as open circuit (“F96”...
Page 217: Compressor Discharge High Pressure Protection Control
19.15 Compressor discharge high pressure protection control  This control protect by using high pressure switch during operation.  Start conditions High pressure switch is activated (from normally close to open) when outdoor operation mode is cooling or heating during compressor running. ...
Page 218: Servicing Mode
20. Servicing Mode Fig. 1 SW1 (PUMP DOWN) SW2 (OPERATION TEST) OFF ON OFF ON (COOL ONLY) 20.1.1 Pump Down Operation  Operate the pump down according to the following procedures. 1. Conﬁrm all the 4pcs of 3-way valve on liquid and gas side are open. 2.
Page 219 20.1.3 Power Save Mode  Power Save Mode can be enabled by pushing POWER SAVE switch (SW4) to ON before power supply ON.  When Power Save Mode is ON, the unit can be operate at lower running current where the breaker capacity not achieve the requirement.
Page 220: Servicing Guide (Wh-Adc0309J3E5Cm)
21. Servicing Guide (WH-ADC0309J3E5CM) 21.1 How to Take out Front Plate Hook Open and Close Front Plate ⑯ Remove the 2 mounting screws of Front Plate ⑯. CAUTION Slide it upwards to unhook the Front Plate ⑯ Open or close the Front Plate carefully. hook.
Page 221: How To Adjust Pump Speed
21.4 How To Adjust Pump Speed 11 : 00am, M on Press & scroll to “Installer setup” [Screen 4] - Press SW to select & conﬁrm maximum duty. (Range: 0 x40~0xFF) [Screen 5] - Range (0.1~99.9)L/min [Screen 6] Press SW to select & conﬁrm operation NOTE: Whenever at [Screen 5], if press SW to OFF, pump operation should be turned OFF.
Page 222: Eeprom Factory Default Data Setup Procedure
21.5 EEPROM Factory Default Data Setup Procedure - EEPROM default data setup is only possible during initialization process. - Press simultaneously for 5secs continuously, initialization process will stop & EEPROM default data setup process will start. During EEPROM default data setup process, display should be as shown below. 0.2s Later 0.2s...
Page 223: Dry Concrete Setup
21.6 Dry Concrete Setup 11 : 00am, M on Press & scroll to “Installer setup” [Screen 4] [Screen 6] Once ‘ON’ is confirm, stage 1 setup will start Every day stage will increment with its respective setup Next Page...
Page 224 - Press button to select no. of stages. - Press to store latest status. - Press button, display will return to [Screen 6]. - If suppose to select 10 stages, then setup will start from stage 1/10. - Press button to select set temperature. - Press button to store latest status.
Page 225: Maintenance Guide
22. Maintenance Guide In order to ensure safety and optimal performance of the Tank Unit, seasonal inspections on the Tank Unit, functional check of RCCB/ELCB, field wiring and piping have to be carried out at regular intervals. This maintenance should be carried out by authorized dealer.
Page 226 Discharge the Water  For Domestic Hot Water Tank a. Turn OFF power supply. ○ b. Set the Domestic Hot Water Tank Discharge (Drain Tap) g to “OPEN”. c. Open Tap / Shower to allow air inlet. d. Turn the Safety Relief Valve knob counterclockwise slightly and hold it until all air is released from this pipeline.
Page 227 Service Valve Discharge port Magnet Bar Open Close Maintenance for Pressure Relief Valve ⑬ It is strongly recommended to operate the valve by turning the lever up & release it down a few times to ensure free water flow through discharge hose at regular intervals to ensure it is not blocked and to remove lime deposit.
Page 228: Maintenance For Magnetic Water Filter Set
22.1 Maintenance for Magnetic Water Filter Set 22.1.1 Service and maintenance 22.1.3 Custom menu If forget Password and cannot operate remote controller Setting method of Custom menu Press for 5 sec. 12:00am,Mon Custom menu Password unlock screen appears, press Conﬁrm and it shall reset.
Page 229 22.1.4 Specifications 22.1.4.1 Specifications of fresh water was heat transfer medium in brazed heat exchanger Parameter Quality Limits for Tap Water on the Secondary Side Temperature Below 60°C 7 to 9 Alkalinity 60mg/l < HCO₃ < 300mg/l Conductivity < 500μS/cm Hardness [Ca⁺, Mg⁺] / [HCO₃⁻] >...
Page 230: Breakdown Self Diagnosis Function (Wh-Adf0309J3E5Cm)
23. Breakdown Self Diagnosis Function (WH-ADF0309J3E5CM) 23.1 Self Diagnosis Function (Three Digits Alphanumeric Code)  When abnormality occur during operation, the system will stop operation, and OFF/ON control panel LED will blink and error code will display on the control panel.
Page 231 Press button and select “System Check” Press SW to select [Screen 4] “Error history” Display last 4 error retrieved from EEPROM...
Page 232: Error Codes Table
23.2 Error Codes Table Diagnosis display Abnormality/Protection control Abnormality judgement Primary location to verify No abnormality detected — —  Total indoor capability more than maximum limit or less than minimum Indoor/Outdoor capacity unmatched 90s after power supply limit, or number of indoor unit less than two.
Page 233 Diagnosis display Abnormality/Protection control Abnormality judgement Primary location to verify Indoor/Outdoor wrong connection —  Indoor/Outdoor supply voltage  Outdoor high pressure sensor  Water pump or water leakage Outdoor high pressure overload  Clogged expansion valve or strainer protection H98 / F95 —...
Page 234: Troubleshooting Guide (S-71Wf3E)
24. Troubleshooting Guide (S-71WF3E) 24.1 Self-Diagnosis Error Code Table SUPPLEMENT Contents of Remote Controller Switch Alarm Display Blinking: OFF: Wireless remote controller receiver display Abnormal Alarm contents Error location display  Replace the remote controller Faulty remote controller Disconnection / Contact failure of remote ...
Page 235 Blinking: OFF: Wireless remote controller receiver display Abnormal Alarm contents Error location display  Check the indoor unit heat exchanger Indoor heat exchanger temperature sensor temperature sensor (E1) (E1) trouble  Check the indoor unit control PCB Operating and timer ...
Page 236 Blinking: OFF: Wireless remote controller receiver display Abnormal Alarm contents Error location display Operating lamp  Check the inter-unit control wiring Auto address setting start is prohibited blinking  Check the inter-unit control wiring Duplication of main unit in group control ...
Page 237 Blinking: OFF: Wireless remote controller receiver display Abnormal Alarm contents Error location display  Check the refrigerant cycle (abnormal overload operation) Primary (input) overcurrent detected  Check the outdoor unit control PCB  Check the power supply  Check the outdoor unit control PCB ...
Page 238 Blinking: OFF: Wireless remote controller receiver display Abnormal Alarm contents Error location display  Check the refrigerant cycle (gas leak)  Trouble with the electronic expansion valve Insufﬁcient gas level detected  Valve (or refrigerant circuit) blockage  Layer short on the compressor ...
Page 239: Self-Diagnostics Method (S-71Wf3E)
24.2 Self-Diagnostics Method (S-71WF3E) 24.2.1 Error Code Definition Error Code Code Definition Communication Error (Communication between indoor and outdoor; Communication between wired remote controller & Wired remote controller improper setting) Improper setting from outdoor & indoor unit and wired remote controller ...
Page 240 24.2.2 E01 & E02 E01 - Remote Controller Reception Error E02 - Remote Controller Transmission Error When remote controller is set to sub (Slave) remote controller:  If only one remote controller is connected to indoor unit, this remote controller must set to main remote controller.
Page 241 24.2.3 E04 - Error in Indoor Unit Receiving Signal from Outdoor Unit Wiring/Power Supply issue:  No communication from outdoor unit within 3 minutes or no signal from outdoor unit Outdoor Unit main power supply turned OFF. No proper set for indoor unit resistance impedance terminal (CN045) Communication cable is lose/opened/improper install.
Page 242 24.2.4 E04 - Communication Issue (Outdoor Unit) Error Detection Method:  Faulty of indoor or outdoor unit PCB.  Signal transmission fail due to wrong wiring/improper connect  Signal transmission fail due to breaking of communication wire between indoor and outdoor unit. ...
Page 243 24.2.5 E15 - Total Capacity of Indoor Unit is Too Low Error Detection Method:  When indoor unit capacity is lower than outdoor unit.  CHK pin (CN062/CN071) and/or TEST pin (CN064) shorted when power is turned ON. 24.2.6 E16 - Total Capacity of Indoor Unit is Too High Setting Related: ...
Page 244: Troubleshooting Guide (Cu-2Wz71Ybe5)
25. Troubleshooting Guide (CU-2WZ71YBE5) 25.1 Self Diagnosis Function (Outdoor LED Diagnosis Table)  The display screen of wireless remote control unit and the self-diagnosis LEDs (green) on the outdoor printed circuit board in the outdoor unit can be used to identify the location of the problem. Refer to the table below to identify and solve the cause of the problem, and then re-start the air conditioner system.
Page 245 Diagnosis display Abnormality (Indoor Abnormality Protection model: Problem Check location protection judgement operation CS-XX / control S-XX / WH-XX)  Outdoor gas H36 / F23 / Outdoor gas pipe ○ ○ Continuous Heating Outdoor gas pipe temperature for 5s protection temperature pipe sensor...
Page 246 Diagnosis display Abnormality (Indoor Abnormality Protection model: Problem Check location protection judgement operation CS-XX / control S-XX / WH-XX)  Power transistor F93 / P29 / Compressor ○ ○ ○ 4 times Compressor abnormal happen abnormal module faulty or revolution within 20 revolution compressor lock...
Page 247: Self-Diagnosis Method
25.2 Self-diagnosis Method 25.2.1 Indoor/Outdoor Capacity Rank Mismatched (E16 / H12) Malfunction Decision Conditions  During startup, error code appears when different types of indoor and outdoor units are interconnected. Malfunction Caused  Wrong models interconnected.  Wrong indoor unit or outdoor unit PCBs mounted. ...
Page 248 25.2.2 Compressor Tank Temperature Sensor Abnormality (H15 / F04 / H15) Malfunction Decision Conditions: During startup and operation of cooling and heating, the temperatures detected by the compressor tank temperature sensor are used to determine sensor error. Malfunction Caused: 1. Faulty connector connection. 2.
Page 249 25.2.3 Water Pump Abnormality (- / - / H20) Malfunction Decision Conditions: During startup and operation of cooling and heating, the rotation speed detected by the IPM of water pump motor during water pump operation is used to determine abnormal water pump (feedback of rotation > 6,000rpm or < 1,000rpm).
Page 250 25.2.4 Indoor Refrigerant Liquid Temperature Sensor Abnormality (- / - / H23) Malfunction Decision Conditions: During startup and operation of cooling and heating, the temperatures detected by the indoor refrigerant liquid temperature sensor are used to determine sensor error. Malfunction Caused: 1.
Page 251 25.2.5 Abnormal Solar Sensor (- / - / H28) Malfunction Caused: Faulty connector connection. Faulty solar sensor. Faulty indoor sub PCB. Abnormality Judgment: Continue for 5 seconds. For safety reason and to prevent Abnormal solar sensor component breakdown, always switch Caution off the power before remove and connect the component.
Page 252 25.2.6 Abnormal Swimming Pool Sensor (- / - / H31) Malfunction Caused: Faulty connector connection. Faulty swimming pool sensor. Faulty indoor sub PCB. Abnormality Judgment: Continue for 5 seconds. For safety reason and to prevent Abnormal swimming pool sensor component breakdown, always switch Caution off the power before remove and connect the component.
Page 253 25.2.7 Abnormal Buffer Tank Sensor (- / - / H36) Malfunction Caused: Faulty connector connection. Faulty buffer tank sensor. Faulty indoor sub PCB. Abnormality Judgment: Continue for 5 seconds. For safety reason and to prevent Abnormal buffer tank sensor component breakdown, always switch Caution off the power before remove and connect the component.
Page 254 Brand code not match component breakdown, always switch Caution off the power before remove and connect the component. ● Use only Panasonic units. Check the brand of indoor and outdoor unit both Panasonic? ● Change to Panasonic unit. Change PCB outdoor...
Page 255 25.2.9 Abnormal Zone 1 Sensor (- / - / H43) Malfunction Caused: Faulty connector connection. Faulty buffer tank sensor. Faulty indoor sub PCB. Abnormality Judgment: Continue for 5 seconds. For safety reason and to prevent Abnormal zone 1 sensor component breakdown, always switch Caution off the power before remove and connect the component.
Page 256 25.2.10 Abnormal Zone 2 Sensor (- / - / H44) Malfunction Caused: Faulty connector connection. Faulty buffer tank sensor. Faulty indoor sub PCB. Abnormality Judgment: Continue for 5 seconds. For safety reason and to prevent Abnormal zone 2 sensor component breakdown, always switch Caution off the power before remove and connect the component.
Page 257 25.2.11 Water Flow Switch Abnormality (- / - / H62) Malfunction Decision Conditions: During operation of cooling and heating, the water flow detected by the indoor water flow switch is used to determine water flow error. Malfunction Caused: 1. Faulty water pump. 2.
Page 258 25.2.12 Outdoor High Pressure Abnormality (H89 / F16 / H64) Malfunction Decision Conditions: During operation of cooling and heating, when the outdoor high pressure sensor output signal is 0 Vdc or 5 Vdc. Malfunction Caused: 1. Faulty connector connection. 2. Faulty sensor. 3.
Page 259 25.2.13 Abnormal External Thermistor 1 (- / - / H67) Malfunction Caused: Faulty connector connection. Faulty room temperature zone 1 sensor. Faulty indoor sub PCB. Abnormality Judgment: Continue for 5 seconds. For safety reason and to prevent Abnormal external thermistor 1 component breakdown, always switch Caution off the power before remove and...
Page 260 25.2.14 Abnormal External Thermistor 2 (- / - / H68) Malfunction Caused: Faulty connector connection. Faulty room temperature zone 2 sensor. Faulty indoor sub PCB. Abnormality Judgment: Continue for 5 seconds. For safety reason and to prevent Abnormal external thermistor 2 component breakdown, always switch Caution off the power before remove and...
Page 261 25.2.15 Indoor Backup Heater OLP Abnormality (- / - / H70) Malfunction Decision Conditions: During operation of indoor backup heater, when no power supplies to indoor backup heater or OLP open circuit. Malfunction Caused: 1. Faulty power supply connector connection. 2.
Page 262 25.2.16 Tank Temperature Sensor Abnormality (- / - / H72) Malfunction Decision Conditions: When tank connection is set to ON, the temperatures detected by the tank temperature sensor are used to determine sensor error. Malfunction Caused: 1. Faulty connector connection. 2.
Page 263 25.2.17 PCB Communication Error (- / - / H74) Malfunction Decision Conditions: When External PCB connection is select “YES” and no communication with External PCB micon for 10 seconds and above. Malfunction Caused: Faulty connector connection. Faulty indoor PCB. Faulty indoor sub PCB. Abnormality Judgment: After 1 minute operation started.
Page 264 25.2.18 Indoor-Control Panel Communication Abnormality (- / - / H76) Malfunction Decision Conditions: During standby and operation of cooling and heating, indoor-control panel error occur. Malfunction Caused: 1. Faulty connector connection. 2. Faulty control panel. 3. Faulty indoor unit PCB (main). For safety reason and to prevent component breakdown, Troubleshooting: always switch off the power before remove and connect the component.
Page 265 25.2.19 Indoor/Outdoor Abnormal Communication (H11 / E04 / H90) Malfunction Decision Conditions: During operation of cooling and heating, the data received from outdoor unit in indoor unit signal transmission is checked whether it is normal. Malfunction Caused: 1. Faulty outdoor unit PCB (main). 2.
Page 266 25.2.20 Unspecified Voltage between Indoor and Outdoor (H33 / P05 / H95) Malfunction Decision Conditions  The supply power is detected for its requirement by the indoor/outdoor transmission. Malfunction Caused  Wrong models interconnected.  Wrong indoor unit and outdoor unit PCBs used. ...
Page 267 25.2.21 Outdoor High Pressure Error (H98 / - / H98) Malfunction Decision Conditions: During operation of heating, when pressure 4.0 MPa and above is detected by outdoor high pressure sensor. Malfunction Caused: 1. Faulty water pump. 2. Insufficient water flow rate in system. 3.
Page 268 Troubleshooting (Room air Conditioning unit) When abnormality indication starts again For safety reason and to prevent component breakdown, always switch Caution off the power before remove and Check the indoor unit intake air filter connect the component. Is the air filter dirty? ●...
Page 269 25.2.22 Outdoor High Pressure Protection: Cooling or Soft Dry (F95 / P04 / F95) Malfunction Decision Conditions  During operation of cooling or soft dry, when outdoor unit heat exchanger high temperature data is detected by the outdoor unit heat exchanger thermistor. Malfunction Caused ...
Page 270 25.2.23 Indoor Freeze-up Protection (H99) Error Code will not display (no Timer LED blinking) but store in EEPROM Malfunction Decision Conditions  Freeze prevention control takes place (when indoor pipe temperature is lower than 2°C) Malfunction Caused  Air short circuit at indoor unit ...
Page 271 25.2.24 Outdoor High Pressure Switch Activate (F94 / P04 / F12) Malfunction Decision Conditions: During operation of cooling and heating, when pressure 4.5 MPa and above is detected by outdoor high pressure switch. Malfunction Caused: 1. Dust accumulation on the outdoor unit heat exchanger. 2.
Page 272 25.2.25 Compressor Rotation Failure (F93 / P29 / F14) Malfunction Decision Conditions  A compressor rotation failure is detected by checking the compressor running condition through the position detection circuit. Malfunction Caused  Compressor terminal disconnect  Faulty Outdoor PCB ...
Page 273 25.2.26 Outdoor Fan Motor (DC Motor) Mechanism Locked (H97 / P22 / F15) Malfunction Decision Conditions  The rotation speed detected by the Hall IC during fan motor operation is used to determine abnormal fan motor. Malfunction Caused  Operation stops due to short circuit inside the fan motor winding. ...
Page 274 25.2.27 Input Over Current Detection (F98 / H01 / F16) Malfunction Decision Conditions  During operation of cooling and heating, when an input over-current (X value in Total Running Current Control) is detected by checking the input current value being detected by current transformer (CT) with the compressor running.
Page 275 25.2.28 Compressor Overheating (F97 / P03 / F20) Malfunction Decision Conditions: During operation of cooling and heating, when temperature above 112°C is detected by the compressor tank temperature sensor. Malfunction Caused: 1. Faulty compressor tank temperature sensor. 2. 2/3 way valve closed. 3.
Page 276 25.2.29 IPM Overheating (F96 / P07 / F22) Malfunction Decision Conditions  During operating of cooling and heating, when IPM temperature data (100°C) is detected by the IPM temperature sensor. Multi Models only Compressor Overheating: During operation of cooling and heating, when the compressor OL is activated. Heat Sink Overheating: During operation of cooling and heating, when heat sink temperature data (90°C) is detected by the heat sink temperature sensor.
Page 277 25.2.30 Output Over Current Detection (F99 / P16 / F23) Malfunction Decision Conditions: During operation of cooling and heating, when outdoor DC current is above set valve is detected by the IPM DC Peak sensing circuitry in the outdoor unit PCB (main). Malfunction Caused: 1.
Page 278 25.2.31 Refrigeration Cycle Abnormality (F91 / P15 / F24) Malfunction Decision Conditions  The input current is low while the compressor is running at higher than the setting frequency. Malfunction Caused  Lack of gas.  3-way valve close. Troubleshooting When F91 indication happens For safety reason and to prevent component breakdown, always switch...
Page 279 25.2.32 Four Way Valve Abnormality (F11 / L18 / F25) Malfunction Decision Conditions  When indoor heat exchanger is cold during heating (except deice) or when indoor heat exchanger is hot during cooling and compressor operating, the 4-way valve is detected as malfunction. Malfunction Caused ...
Page 280 25.2.33 Outdoor High Pressure Switch Abnormal (H64 / P04 / F27) Malfunction Decision Conditions: During compressor stop, and outdoor high pressure switch is remain opened. Malfunction Caused: 1. Faulty connector connection. 2. Faulty switch. 3. Faulty outdoor unit PCB (main). Abnormality Judgment: Continue for 1 minute.
Page 281 25.2.34 Indoor Water Outlet Temperature Sensor 2 Abnormality (- / - / F30) Malfunction Decision Conditions: During startup and operation of cooling and heating, the temperatures detected by the indoor water outlet temperature sensor 2 are used to determine sensor error. Malfunction Caused: 1.
Page 282 25.2.35 Outdoor Air Temperature Sensor Abnormality (H27 / F08 / F36) Malfunction Decision Conditions: During startup and operation of cooling and heating, the temperatures detected by the outdoor air temperature sensor are used to determine sensor error. Malfunction Caused: 1. Faulty connector connection. 2.
Page 283 25.2.36 Indoor Water Inlet Temperature Sensor Abnormality (- / - / F37) Malfunction Decision Conditions: During startup and operation of cooling and heating, the temperatures detected by the indoor water inlet temperature sensor are used to determine sensor error. Malfunction Caused: 1.
Page 284 25.2.37 Outdoor Discharge Pipe Temperature Sensor Abnormality (H30 / F04 / F40) Malfunction Decision Conditions  During startup and operation of cooling and heating, the temperatures detected by the outdoor compressor temperature sensor are used to determine sensor errors. Malfunction Caused ...
Page 285 25.2.38 Power Factor Correction (PFC) Abnormality (F90 / H02 / F41) Malfunction Decision Conditions  To maintain DC voltage level supply to power transistor.  To detect high DC voltage level after rectification. Malfunction Caused  During startup and operation of cooling and heating, when Power Factor Correction (PFC) protection circuitry at the outdoor unit main PCB senses abnormal DC voltage level for power transistors.
Page 286 25.2.39 Outdoor Pipe Temperature Sensor Abnormality (H28 / F06 / F42) Malfunction Decision Conditions  During startup and operation of cooling and heating, the temperatures detected by the outdoor pipe temperature sensor are used to determine sensor errors. Malfunction Caused ...
Page 287 25.2.40 Outdoor Defrost Temperature Sensor Abnormality (H32 / F07 / F43) Malfunction Decision Conditions  During startup and operation of cooling and heating, the temperatures detected by the outdoor heat exchanger temperature sensor are used to determine sensor errors. Malfunction Caused ...
Page 288 25.2.41 Indoor Water Outlet Temperature Sensor Abnormality (- / - / F45) Malfunction Decision Conditions: During startup and operation of cooling and heating, the temperatures detected by the indoor water outlet temperature sensor are used to determine sensor errors. Malfunction Caused: 1.
Page 289 25.2.42 Outdoor Current Transformer Open Circuit (H16 / H03 / F46) Malfunction Decision Conditions  An input current, detected by Current Transformer CT, is below threshold value when the compressor is operating at certain frequency value for 3 minutes. Malfunction Caused ...
Page 290: Disassembly And Assembly Instructions (Wh-Adf0309J3E5Cm)
26. Disassembly and Assembly Instructions (WH-ADF0309J3E5CM) WARNING High Voltage are generated in the electrical parts area by the capacitor. Ensure that the capacitor has discharged sufficiently before proceeding with repair work. Failure to heed this caution may result in electric shocks.
Page 291: To Remove Pressure Gauge
26.2 To Remove Pressure Gauge 2. Use spanner to release nut of Pressure Gauge. 1. Remove 2 screws to remove the Particular Plate. 26.3 To Remove Remote Control 3. Remove 3 screws then take out the bottom case. Claw (2 places) Insert the driver and slightly turn.
Page 292: To Remove Rccb
26.4 To Remove RCCB 2. Disconnect lead wires (Black and White) from the RCCB. 3. Remove screw to remove the RCCB. RCCB Control Board Cover 1. Remove 6 screws to remove the Control Board Cover. 26.5 To Remove Electronic Controller 1.
Page 293: To Remove Flow Switch And Air Purge Valve
26.6 To Remove Flow Switch and Air Purge Valve 1. Turn the Air Purge Valve anti-clockwise then remove. 2. Detach the flow sensor lead wire. Air Purge Valve 3. Remove 2 retaining rings, then remove the Flow Sensor. When reinstall Flow Switch, ensure the arrow on the flow switch is parallel with the pipe shaft and is facing in the direction of flow.
Page 294: To Remove Bottle Complete
26.8 To Remove Bottle Complete 1. Disconnect the connector CN-OLP1 from the Electronic Controller and detached the lead wire HT1-L3 (Red) and AC2-L3 (Black). 2. Remove Air Purge Valve. 3. Disconnect 2 pipe connection. 4. Remove 4 screw from bracket. 26.9 To Remove Water Filter Filter...
Page 295: Disassembly And Assembly Instructions (S-71Wf3E)
27. Disassembly and Assembly Instructions (S-71WF3E) WARNING High Voltage is generated in the electrical parts area by the capacitor. Ensure that the capacitor has discharged sufficiently before proceeding with repair work. Failure to heed this caution may result in electric shocks. 27.1 Indoor Electronic Controller Removal Procedures Remove the 1 screw of the Rain Cover.
Page 296: Disassembly And Assembly Instructions (Cu-2Wz71Ybe5)
28. Disassembly and Assembly Instructions (CU-2WZ71YBE5) WARNING High Voltage is generated in the electrical parts area by the capacitor. Ensure that the capacitor has discharged sufficiently before proceeding with repair work. Failure to heed this caution may result in electric shocks. 28.1 Outdoor Unit Removal Procedure Caution! When handling electronic controller, be careful of electrostatic discharge.
Page 297 3. Remove the particular plate (remove the 3 screws). Fig. 3 4. Remove the particular plate (remove the 5 screws). Fig. 4 28.1.3 Removing the Cabinet Front Plate 5. Remove the cabinet front plate (remove the 7 screws). Fig. 5...
Page 298 28.1.4 Removing the Control P.C. Board 6. Remove the cover by release the screw. Fig. 6 7. Disconnect the connectors (lead wires of the compressor, sensors, and others). 8. Release the Control P.C. Board tab to remove the Control P.C. Board. Fig.
Page 299: Technical Data (Wh-Adf0309J3E5Cm)
29. Technical Data (WH-ADF0309J3E5CM) 29.1 Operation Characteristics Heating Characteristics at Different Outdoor Air Temperature Condition Outdoor air temperature : 7°C (DBT), 6°C (WBT) Indoor water inlet temperature : 30°C Indoor water outlet temperature : 35°C Piping length : 7 m 8.200...
Page 300: Technical Data (S-71Wf3E)
30. Technical Data (S-71WF3E) 30.1 Fan Performance Power level Power level S-71WF3E Cooling IVDS AF dB(A) Heating IVDS AF dB(A) 22.70 57.00 34.00 22.70 57.00 34.00 19.80 19.80 15.00 49.00 26.00 15.00 49.00 26.00...
Page 301: Indoor Fan Performance
30.2 Indoor Fan Performance PQ Diagram External static pressure 150Pa, 90Pa External static pressure 120Pa, 30Pa Airflow Volume (m /minute) Airflow Volume (m /minute) External static pressure 140Pa, 70Pa External static pressure 110Pa, 10Pa Airflow Volume (m /minute) Airflow Volume (m /minute) External static pressure 130Pa, 50Pa Airflow Volume (m...
Page 302: Technical Data (Cu-2Wz71Ybe5)
31. Technical Data (CU-2WZ71YBE5) Technical data provided are based on the air conditioner running under free frequency. 31.1 Air Cool Mode Performance Data Unit setting: Standard piping length, Hi Fan, Cool mode at 16°C Voltage: 230V, 50Hz Indoor Air Temp. °C Outdoor Air Temp.
Page 303: Exploded View And Replacement Parts List
32. Exploded View and Replacement Parts List 32.1 WH-ADF0309J3E5CM ETIHW ELCB LEAD WIRE REACTOR FIXING FOR RCCB/ELCB TERMINAL 230V 30A In=30mA BOARD AC1-L3 (BLK) FUSE1 T6.3A L250V FUSE 3 (WHT) (GRN) (WHT) HEATER 80±3°C 230V 30A~40A I n=30mA (L 1 )
Page 304 Note: The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts.
Page 305 SAFETY REF. NO. DESCRIPTION & NAME QTY. WH-ADF0309J3E5CM REMARK CHASSIS - COMPLETE ACXD50C03830 VALVE - COMPLETE ACXB65C00111 SENSOR - COMPLETE (CN-TH2) ACXA50C16520 FILTER COMPLETE ACXB51C00110 HOT WATER COIL - COMPLETE ACXB90C01561 RECEIVER CWB141039 ELECTRIC LIQUID PUMP (VOLUTE PUMP) ACXB53-00390 LEAD WIRE - COMPLETE (CN-PUMP1)
Page 306 SAFETY REF. NO. DESCRIPTION & NAME QTY. WH-ADF0309J3E5CM REMARK PACKING ACXB81-06531 PACKING ACXB81-00010 RETAINING RING CWH581007 TANK COMPLETE ACXB56C00952 PARTICULAR PIECE CWD934023 STRAIGHT TUBE CWT102044 PLATE SPRING CWH711010 FOAMED POLYSTYRENE ACXG07-06740 FOAMED POLYSTYRENE ACXG07-06750 FOAMED POLYSTYRENE ACXG07-06760 FOAMED POLYSTYRENE ACXG07-06770...
Page 307 SAFETY REF. NO. DESCRIPTION & NAME QTY. WH-ADF0309J3E5CM REMARK SPACER CWH54294 SPACER CWH54295 SELF TAPPING SCREW XTN4+25CFJ LEAD WIRE - COMPLETE (L, N) ACXA60C90150 HINGE CWH611006 WIRING DIAGRAM ACXF29-00770 BRACKET - UNIT MOUNTING ACXD57-03030 BASE PAN ACXD52-06061 BAG - COMPLETE (L-TUBE)
Page 308: S-71Wf3E
32.2 S-71WF3E Note: The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts.
Page 309 SAFETY REF. NO. PART NAME & DESCRIPTION QTY. S-71WF3E REMARK CABINET TOP PLATE - COMPLETE ACXE03C01870 BULKHEAD ACXD53-01781 PARTICULAR PLATE ACXD90-23740 PARTICULAR PLATE ACXD90-23700 FAN MOTOR BRACKET ACXD54-04010A DC MOTORS (BRUSHLESS GENERAL USE) L6CBYYYL0331 FAN MOTOR BRACKET ACXD54-04020 FAN MOTOR BRACKET ACXD54-04110 AIR GUIDER B.W.
Page 310 SAFETY REF. NO. PART NAME & DESCRIPTION QTY. S-71WF3E REMARK CABINET BOTTOM PLATE ACXE05-01620 ELECTRONIC CONTROLLER - COMPLETE ACXA73C80480 TERMINAL BOARD ACXA28-00140 RAIN COVER ACXH81-01510 CABINET BOTTOM PLATE - COMPLETE ACXE05C00350 CABINET SIDE PLATE - COMPLETE ACXE04C06590 CONTROL BOARD COVER - COMPLETE ACXH13C05400 DRAIN PAN - COMPLETE ACXH40C01471...
Page 311: Cu-2Wz71Ybe5
32.3 CU-2WZ71YBE5 Note The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts.
Page 312 SAFETY REF. NO. DESCRIPTION & NAME QTY. CU-2WZ71YBE5 REMARK BASE PAN ASS'Y CWD52K1345A SOUND - PROOF BOARD CWH151367 FAN MOTOR BRACKET ACXD54K02270 SCREW - BRACKET FAN MOTOR CWH551040J CONDENSER COMPLETE ACXB32C25400 FAN MOTOR L6CBYYYL0098 SCREW - FAN MOTOR MOUNT CWH551323 PROPELLER FAN ASSY CWH03K1075 CWH561092...
Page 313 ACXF60-45860 INSTALLATION INSTRUCTION ACXF60-45870 INSTALLATION INSTRUCTION ACXF60-45880 INSTALLATION INSTRUCTION ACXF60-45890 ACCESSORY CO. (DRAIN ELBOW) ACXH82C21740 BADGE PANASONIC CWE373439 LEAD WIRE - COMPRESSOR CWA68C1395 V-COIL CO. (4 WAY VALVE CN-HOT2) ACXA43C07380 SENSOR - COMPLETE (CN-TANK) ACXA50C18300 SENSOR - COMPLETE (CN-TH5) ACXA50C18310...

This manual is also suitable for:

S-71wf3e Cu-2wz71ybe5

Panasonic WH-ADF0309J3E5CM Service Manual

Quick Links

Troubleshooting

Related Manuals for Panasonic WH-ADF0309J3E5CM

Summary of Contents for Panasonic WH-ADF0309J3E5CM

This manual is also suitable for:

Table of Contents
