d. Inspect and remove jammed bill.
e. Replace lower unit to resume normal operation
Your Beverage unit incorporates a high efficiency refrigeration system having two air circulation fans to chill the
cans and bottles. The refrigeration unit can be easily accessed by opening the beverage unit door and sliding
the front grill up and out. Remove the single blue thumbscrew from the center floor of the refrigeration deck
and remove the partition wall. Remove the two screws holding the handles in place (Figure 24).
Figure 24 – Refrigeration deck
Condenser
Gently clean
fins on a regular
basis
JDL V1.0 8 2022
REFRIGERATION DECK
Remove three
screws
61
Compressor
