Seaga JDL-2 COMBO Service And Parts Manual page 16

Figure 15 – Loaded Product with Retainers Secured
Retainer
Adjusted within ½"
of product
Locking Arm Secured
Refer to Figure 16 below for alternate product requirements and the accessories needed to properly vend
these items.
Size Description
20 oz
Bottle
519 ml
14 oz
Bottle
414 ml
18.5 oz
Bottle
547 ml
20 oz
Bottle
519 ml
16 oz
Can
473 ml
15 oz
Can
443 ml
JDL V1.0 8 2022
Product
Aquafina Water,
Country Time
Lemonade, Lip-
ton Iced or Green Side Spacer, Small, LH
Tea, Coke, Pep-
si, and Various
Brands
Nesquik Side Spacer, Small, LH
Pure Leaf Tea Side Spacer, Small, LH
Gatorade, Sobe,
Vitamin Water
Monster, Rock Side Spacer, Small, LH,
Star
Starbucks Dou- Side Spacer, Small, LH,
bleshot Coffee
Setup/Accessory
Not Required
Back Spacer
Back Spacer
16
Load
Tops to Back
Tops to Back
Alternate top and
bottom
Tops to Back
Alternate top and
bottom
Alternate top and
bottom
Capacity Group
10 1
10 1
10 2
10 3
10 4
10 4
